Adhesives, Fluids, Lubricants, and Sealers
| Application | Type of Material | GM Part Number | |
|---|---|---|---|
| United States | Canada | ||
| Balancer Shaft Driven Gear Bolt | Threadlock | 12345382 | 10953489 |
| Camshaft Retainer Bolt | Threadlock | 12345382 | 10953489 |
| Crankshaft Balancer Keyway | Adhesive | 12346141 | 10953433 |
| Cylinder Head Bolt | Sealant | 12346004 | 10953480 |
| Engine Block to the Crankshaft Rear Oil Seal Housing Junction at the Oil Pan Sealing Surfaces | Adhesive | 12346141 | 10953433 |
| Engine Block to the Engine Front Cover Junction at the Oil Pan Sealing Surfaces | Adhesive | 12346141 | 10953433 |
| Engine Block at the Lower Intake Manifold Sealing Surfaces | Adhesive | 12346141 | 10953433 |
| Engine Block Coolant Drain Hole Plug | Sealant | 12346004 | 10953480 |
| Engine Block Core Hole Plug | Threadlock | 12345382 | 10953489 |
| Engine Block Oil Gallery Plug | Sealant | 12346004 | 10953480 |
| Engine Coolant Temperature (ECT) Gage Sensor | Sealant | 12346004 | 10953480 |
| Engine Coolant Temperature (ECT) Sensor | Sealant | 12346004 | 10953480 |
| Engine Oil | SAE 5W-30 Oil | 12345610 | 993193 |
| Engine Oil Pressure Sensor | Sealant | 12346004 | 10953480 |
| Engine Oil Pressure Sensor Fitting | Sealant | 12346004 | 10953480 |
| Engine Oil Supplement | Lubricant | 1052367 | 992367 |
| Evaporative Emission (EVAP) Canister Purge Solenoid Valve Stud | Threadlock | 12345382 | 10953489 |
| Exhaust Manifold Bolt/Stud | Threadlock | 12345493 | 10953488 |
| Expansion Cup Plug - Balance Shaft Rear Bearing Hole | Sealant | 12346004 | 10953480 |
| Expansion Cup Plug - Camshaft Rear Bearing Hole | Sealant | 12346004 | 10953480 |
| Fuel Meter Body Bracket Bolt | Threadlock | 12345382 | 10953489 |
| Fuel Pipe Bolt | Threadlock | 12345382 | 10953489 |
| Lower Intake Manifold Bolt | Threadlock | 12345382 | 10953489 |
| Oil Level Indicator Tube | Sealant | 12346004 | 10953480 |
| Oil Pump Screen Tube | Sealant | 12346004 | 10953480 |
| Throttle Body Stud | Threadlock | 12345382 | 10953489 |
| Upper Intake Manifold Stud | Threadlock | 12345382 | 10953489 |
| Valve Train Component Prelube | Lubricant | 12345501 | 992704 |
| Water Pump Bolt | Sealant | 12346004 | 10953480 |
Scheme 8
| Callout | Component Name |
|---|---|
| 1 | Throttle Body |
| 2 | Throttle Body Stud |
| 3 | Idle Air Control Valve Seal |
| 4 | Idle Air Control Valve |
| 5 | Idle Air Control Valve Bolt |
| 6 | O-ring |
| 7 | Spacer |
| 8 | Fuel Injection Fuel Feed and Return Pipe Retainer Nut |
| 9 | Fuel Injection Fuel Feed and Return Pipe Retainer |
| 10 | Fuel Injection Fuel Feed and Return Pipe |
| 11 | Fuel Service Port Cap |
| 12 | Fuel Schrader Valve |
| 13 | Engine Wiring Harness Bracket Nut |
| 14 | Engine Wiring Harness Bracket |
| 15 | Fuel Injection Fuel Feed and Return Pipe Bolt |
| 16 | Fuel Injector Fuel Meter Fuel Passage Plug |
| 17 | Spacer |
| 18 | O-ring |
| 19 | Upper Intake Manifold Stud |
| 20 | Positive Crankcase Ventilation Valve Cover |
| 21 | Positive Crankcase Ventilation Valve Cover Seal |
| 22 | Upper Intake Manifold |
| 23 | Upper Intake Manifold Gasket |
| 24 | Fuel Injector Fuel Meter Body Seal |
| 25 | Fuel Injector Fuel Meter Body |
| 26 | Lower Intake Manifold |
| 27 | Heater Hose Fitting |
| 28 | Engine Coolant Thermostat |
| 29 | Engine Coolant Thermostat Seal |
| 30 | Water Outlet |
| 31 | Water Outlet Stud |
| 32 | Throttle Body Seal |
| 33 | Throttle Position Sensor Bolt |
| 34 | Throttle Position Sensor |
Scheme 9
| Callout | Component Name |
|---|---|
| 1 | Spark Plug Wire Retainer |
| 2 | Spark Plug Wire Harness |
| 3 | Oil Pump Drive Shaft Clamp Bolt |
| 4 | Oil Pump Drive Shaft |
| 5 | Spark Plug Wire Harness |
| 6 | Spark Plug Wire Retainer |
| 7 | Spark Plug Wire Retainer |
| 8 | Spark Plug Wire Retainer |
| 9 | Spark Plug |
| 10 | Oil Pump Drive Shaft Gasket |
| 11 | Spark Plug Wire Retainer |
| 12 | Manifold Absolute Pressure Sensor |
| 13 | Manifold Absolute Pressure Sensor Seal |
| 14 | Lower Intake Manifold Bolt |
| 15 | Lower Intake Manifold Gasket |
| 16 | Intake Manifold Assembly |
| 17 | Accelerator Control Cable Bracket Stud |
| 18 | Accelerator Control Cable Bracket Bolt |
| 19 | Accelerator Control Cable Bracket |
| 20 | Accelerator Control Cable Bracket Nut |
| 21 | Ignition Coil Bracket |
| 22 | Ignition Coil Bracket Bolt |
| 23 | Ignition Coil Assembly to Bracket Bolt |
| 24 | Ignition Coil Assembly |
| 25 | Ignition Coil Module |
| 26 | Ignition Coil Module Bolt |
| 27 | EVAP Purge Valve Seal |
| 28 | EVAP Purge Valve |
| 29 | EVAP Purge Valve Hose |
| 30 | EVAP Purge Valve Bolt |
| 31 | Spark Plug Wire Retainer |
Scheme 10
| Callout | Component Name |
|---|---|
| 1 | Oil Filler Cap |
| 2 | Oil Filler Cap Seal |
| 3 | Oil Filler Tube |
| 4 | Oil Filler Tube Seal |
| 5 | Valve Rocker Arm Cover |
| 6 | Valve Push Rod |
| 7 | Valve Lifter Guide Bolt |
| 8 | Valve Stem Oil Seal |
| 9 | Valve Spring |
| 10 | Valve Spring Cap |
| 11 | Valve Stem Key |
| 12 | Valve Rocker Arm Cover |
| 13 | Positive Crankcase Ventilation Tube |
| 14 | Valve Rocker Arm Cover Bolt |
| 15 | Valve Rocker Arm Cover Bolt Grommet |
| 16 | Valve Rocker Arm Cover Gasket |
| 17 | Valve Rocker Arm Bolt |
| 18 | Valve Rocker Arm |
| 19 | Valve Rocker Arm Pivot Support |
| 20 | Cylinder Head Bolt |
| 21 | Spark Plug Wire Support |
| 22 | Spark Plug Wire Support Bolt |
| 23 | Cylinder Head Bolt |
| 24 | Cylinder Head Bolt |
| 25 | Exhaust Manifold Gasket |
| 26 | Exhaust Manifold |
| 27 | Exhaust Manifold Heat Shield Bolt |
| 28 | Spark Plug Wire Shield |
| 29 | Exhaust Manifold Bolt |
| 30 | Exhaust Manifold Stud |
| 31 | Spark Plug Wire Shield |
| 32 | Exhaust Manifold Heat Shield |
| 33 | Exhaust Manifold Gasket |
| 34 | Engine Coolant Temperature Sensor |
| 35 | Valve |
| 36 | Cylinder Head |
| 37 | Valve Lifter Guide |
| 38 | Cylinder Head Gasket |
| 39 | Cylinder Head Location Pin |
| 40 | Valve Lifter |
| 41 | Positive Crankcase Ventilation Tube Grommet |
| 42 | Positive Crankcase Ventilation Tube |
Scheme 11
| Callout | Component Name |
|---|---|
| 1 | Thermostat Bypass Hose |
| 2 | Thermostat Bypass Pipe Clamp |
| 3 | Water Pump |
| 4 | Water Pump Gasket |
| 5 | Balance Shaft Gear Bolt |
| 6 | Balancer Shaft Driven Gear |
| 7 | Balance Shaft Retainer Bolt |
| 8 | Balancer Shaft Retainer |
| 9 | Balancer Shaft Front Bearing |
| 10 | Balance Shaft |
| 11 | Piston Ring Set |
| 12 | Piston |
| 13 | Piston Pin |
| 14 | Connecting Rod |
| 15 | Connecting Rod Bearing Cap |
| 16 | Connecting Rod Bolt |
| 17 | Connecting Rod Bearing |
| 18 | Oil Level Indicator |
| 19 | Oil Level Indicator Tube |
| 20 | Oil Level Indicator Tube Bolt |
| 21 | Knock Sensor Bolt |
| 22 | Knock Sensor |
| 23 | Engine Block |
| 24 | Engine Oil Pressure Indicator Switch Fitting |
| 25 | Engine Oil Pressure Indicator Switch |
| 26 | Balancer Shaft Rear Bearing |
| 27 | Engine Block Coolant Hole Plug |
| 28 | Engine Block Oil Gallery Plug |
| 29 | Engine Block Oil Gallery Plug |
| 30 | Engine Block Oil Gallery Plug |
| 31 | Transmission Locating Pin |
| 32 | Engine Block Oil Gallery Plug |
| 33 | Oil Filter Bypass Valve |
| 34 | Engine Oil Cooler Adapter Gasket |
| 35 | Engine Oil Cooler Adapter Seal |
| 36 | Engine Oil Cooler Adapter |
| 37 | Engine Oil Cooler Adapter Bolt |
| 38 | Oil Filter |
| 39 | Oil Pressure Relief Valve Spring Seat Pin |
| 40 | Block Heater |
| 41 | Knock Sensor Bolt |
| 42 | Knock Sensor |
| 43 | Engine Block Coolant Hole Plug |
| 44 | Cylinder Head Location Pin |
| 45 | Engine Block Oil Gallery Plug |
| 46 | Engine Lift Front Bracket |
| 47 | Engine Lift Front Bracket Bolt |
| 48 | Engine Lift Front Bracket Bolt |
| 49 | Camshaft Bearing |
| 50 | Camshaft Thrust Bearing Bolt |
| 51 | Camshaft Thrust Plate |
| 52 | Camshaft |
| 53 | Engine Block Oil Gallery Plug |
| 54 | Timing Chain Tensioner Bracket |
| 55 | Timing Chain Tensioner Shoe |
| 56 | Timing Chain Tensioner Bolt |
| 57 | Camshaft Sprocket Bolt |
| 58 | Timing Chain |
| 59 | Camshaft Sprocket |
| 60 | Balancer Shaft Drive Gear |
| 61 | Camshaft Sprocket Location Pin |
| 62 | Water Pump Bolt |
| 63 | Water Pump Pulley |
| 64 | Water Pump Pulley Bolt |
Scheme 12
| Callout | Component Name |
|---|---|
| 1 | Crankshaft Balancer Bolt |
| 2 | Crankshaft Balancer Washer |
| 3 | Drive Belt Pulley |
| 4 | Crankshaft Balancer |
| 5 | Crankshaft Front Oil Seal |
| 6 | Camshaft Sensor Bolt |
| 7 | Camshaft Position Sensor Assembly |
| 8 | Camshaft Sensor Seal |
| 9 | Engine Front Cover Bolt |
| 10 | Engine Front Cover |
| 11 | Crankshaft Sprocket |
| 12 | Crankshaft |
| 13 | Crankshaft Balancer Key |
| 14 | Crankshaft Lower Bearing |
| 15 | Crankshaft Upper Bearing |
| 16 | Crankshaft Rear Oil Seal Housing Gasket |
| 17 | Crankshaft Rear Oil Seal Retainer Stud |
| 18 | Crankshaft Rear Oil Seal Housing |
| 19 | Crankshaft Rear Oil Seal Housing Bolt |
| 20 | Crankshaft Rear Oil Seal |
| 21 | Flywheel |
| 22 | Flywheel Bolt |
| 23 | Crankshaft Rear Oil Seal Housing Bolt |
| 24 | Crankshaft Rear Oil Seal Housing Bolt |
| 25 | Crankshaft Rear Oil Seal Housing Stud |
| 26 | Oil Pan Nut |
| 27 | Crankshaft Rear Oil Seal Housing Locating Pin |
| 28 | Crankshaft Upper Bearing |
| 29 | Crankshaft Bearing Cap |
| 30 | Oil Pump Location Pin |
| 31 | Oil Pump Drive Shaft |
| 32 | Oil Pump Drive Clamp Bolt |
| 33 | Oil Pump Bolt |
| 34 | Oil Pan Gasket |
| 35 | Oil Pan Baffle Bolt |
| 36 | Oil Pan Baffle |
| 37 | Oil Pan |
| 38 | Oil Pan Drain Plug |
| 39 | Oil Pan Drain Plug Seal |
| 40 | Oil Pan Bolt |
| 41 | Oil Pump Screen |
| 42 | Oil Pump |
| 43 | Crankshaft Bearing Cap Bolt |
| 44 | Crankshaft Bearing Cap |
| 45 | Crankshaft Lower Bearing |
| 46 | Crankshaft Position Sensor Reluctor Ring |
| 47 | Crankshaft Position Sensor Seal |
| 48 | Crankshaft Position Sensor |
| 49 | Crankshaft Position Sensor Bolt |
| 50 | Crankshaft Balancer Weight |
| 51 | Drive Belt Pulley Bolt |
