Cellular System, Entertainment System, and Navigation System: Specifications GMC Sierra 3500 HD

Entertainment Systems 12 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Amplifier Screw9 N.m80 lb in
Antenna Assembly Screw5 N.m44 lb in
Antenna Mast6 N.m53 lb in
Antenna Module Bolt9 N.m80 lb in
Front Floor Console Screw9 N.m80 lb in
Front Floor Console Bracket Screw9 N.m80 lb in
Front Floor Console Speaker Nut9 N.m80 lb in
Front Speaker Screw6 N.m53 lb in
Front Door Speaker Screw3 N.m25 lb in
Mobile Telephone Antenna Bolt9 N.m80 lb in
Radio Retaining Screws2 N.m18 lb in
Rear Door Speaker Screw3 N.m25 lb in
Rear Pillar Speaker Screw3 N.m25 lb in
Rear Radio Control Screw1.5 N.m13 lb in
Roof Console Screw2 N.m18 lb in
Video Display Assembly Screw2 N.m18 lb in

Scheme 1

Scheme 1: Radio/Navigation System Schematics
Scheme 1: Radio/Navigation System Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: OnStar Schematics
Scheme 9: OnStar Schematics

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: Video System Schematics
Scheme 11: Video System Schematics

Scheme 12

Scheme 12
Scheme 12
