GMC Sierra 2500 (2000-2004) window lock out Wiring diagram
This page shows the only wiring diagram for the component.window lock out, which is found in the car GMC Sierra 2500 (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window lock out (1 of 1)
6.0L
AUTO- ECC HVAC CONTROL MODULE
AUXILIARY POWER OUTLET (CONSOLE) SECONDARY FUEL PUMP/ SENDER
BLK WIRE
BLOWER MOTOR RESISTOR/ RELAY ASSEMBLY
DOOR LOCK SWITCH
DRIVER HEATED SEAT RELAY
DRIVER POWER SEAT SWITCH
DRIVER SEAT BOLSTER SWITCH
DRIVER SEAT HEATING ELEMENT
DRIVER SEAT LUMBAR MOTOR MEMORY SEAT MODULE
DRIVER SEAT POWER SWITCH DRIVER SEAT BELT SWITCH
DRIVER SEAT THERMISTOR
ELEMENT
FULL FEATURE SEAT
I/P COMPARTMENT LAMP
I/P WIRING HARNESS JUNCTION BLOCK (LOWER RIGHT SIDE OF DASH)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
LEFT BACK-UP LAMP LEFT TURN LAMP LEFT LICENSE LAMP
LEFT FRONT SHOCK SOLENOID VALVE
LEFT REAR SHOCK SOLENOID VALVE
LEFT TAIL/ STOPLAMP
NCA WIRE
PASSENGER HEATED SEAT RELAY
PASSENGER HEATED SEAT SWITCH
PASSENGER PASSENGER SEAT THERMISTOR SEAT HEATING ELEMENT
PASSENGER POWER SEAT SWITCH
PASSENGER SEAT BOLSTER SWITCH
PASSENGER SEAT LUMBAR MOTOR PASSENGER SEAT SWITCH
POWER SEAT
POWER WINDOW SWITCH
PRIMARY FUEL PUMP/ SENDER
RAP 2 RELAY
REAR LAMPS BUSSING BLOCK (FRONT OF REAR BUMPER, ON CROSSMEMBER)
REAR WINDOW
RIGHT FRONT SHOCK SOLENOID VALVE
RIGHT MINI WEDGE (DOOR JAMB SWITCH)
RIGHT OUTSIDE POWER MIRROR
RIGHT POWER WINDOW/ DOOR LOCK SWITCH
RIGHT REAR SHOCK SOLENOID VALVE (HEAVY DUTY) TRAILER CONNECTOR
RIGHT TAIL/ STOPLAMP RIGHT LICENSE LAMP RIGHT BACK-UP LAMP RIGHT TURN LAMP
ROOF BEACON GROUND
ROOF BEACON RELAY
ROOF MARKER LAMPS
SEAT BELT SWITCH
UPLEVEL ONLY
WHT WIRE
WINDOW LOCK OUT
Go to component -> Ground distribution circuit (3 of 3) -> WINDOW LOCK OUT
