GMC Sierra 2500 (2000-2004) right front right front door speaker tweeter speaker Wiring diagram
This page shows the only wiring diagram for the component.right front right front door speaker tweeter speaker, which is found in the car GMC Sierra 2500 (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front right front door speaker tweeter speaker (1 of 1)
10 11 12 13 14 15 16 AUD OUT - DRAIN WIRE
AUDIO AMPLIFIER
BARE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COAX ANTENNA
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
GROUND
GROUND R SPK OUT+
GRY WIRE
HOT AT ALL TIMES
L SPK OUT- L SPK OUT+
LEFT FRONT RIGHT REAR DOOR SPEAKER SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT I/P FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
LEFT REAR SPEAKER
LEFT SUBWOOFER
LF AUD + RT AUD +
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NOISE COMPENSATION MICROPHONE
ORG/ WIRE
ORG/BLK WIRE
R SPK OUT- B+
RADIO AMP FUSE
RIGHT FRONT RIGHT FRONT DOOR SPEAKER TWEETER SPEAKER
RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH)
RIGHT SUBWOOFER
SERIAL DATA
SUBWOOFER SPEAKER
TAN WIRE
UNDERHOOD FUSE BLOCK (AT LEFT SIDE OF ENGINE COMPARTMENT)
YEL WIRE
Go to component -> Premium sound radio circuit, with digital radio receiver (2 of 2) -> RIGHT FRONT RIGHT FRONT DOOR SPEAKER TWEETER SPEAKER
