GMC Sierra 2500 (2000-2004) driver window/ door lock switch right up right down Wiring diagrams
This page contains all the electrical diagrams for the component. driver window/ door lock switch right up right down, in which he is found in the car GMC Sierra 2500 (2000-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver window/ door lock switch right up right down (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER WINDOW MOTOR
DRIVER WINDOW/ DOOR LOCK SWITCH RIGHT UP RIGHT DOWN
FUSE BLOCK (ON LOWER LEFT SIDE OF DASH)
HOT IN ACC, RUN, BULB TEST, START, WITH RAP RELAY ENERGIZED
I/P JUNCTION BLOCK (ON LOWER RIGHT SIDE OF DASH)
LEFT DOWN
LEFT UP
PASSENGER WINDOW MOTOR
PASSENGER WINDOW/ DOOR LOCK SWITCH
PWR WDO CIRCUIT BREAKER
SPLICE PACK
TAN WIRE
UP DOWN
WDO DN RELAY
WDO UP RELAY
Go to component -> Power window circuit -> DRIVER WINDOW/ DOOR LOCK SWITCH RIGHT UP RIGHT DOWN
Wiring diagram driver window/ door lock switch right up right down (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER WINDOW MOTOR
DRIVER WINDOW/ DOOR LOCK SWITCH RIGHT UP RIGHT DOWN
HOT IN ACC, RUN, BULB TEST, START, WITH RAP RELAY ENERGIZED
LEFT DOWN
LEFT I/P FUSE BLOCK (LEFT SIDE OF I/P)
LEFT UP
PASSENGER WINDOW MOTOR
PASSENGER WINDOW/ DOOR LOCK SWITCH
PWR WDO CIRCUIT BREAKER
RIGHT I/P FUSE BLOCK (ON LOWER RIGHT SIDE OF DASH)
SPLICE PACK
TAN WIRE
UP DOWN
WDO DN RELAY
WDO UP RELAY
Go to component -> Power window circuit, 2 door -> DRIVER WINDOW/ DOOR LOCK SWITCH RIGHT UP RIGHT DOWN
