Wiring diagram: Air conditioning — Manual a/c circuit, up level GMC Sierra 2500 HD

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• A/C Compressor Clutch
• A/C Compressor Clutch Relay
• A/C Fuse
• A/C High Press Sw
• A/C High Pressure Recirculating Switch
• A/C High Pressure Switch
• A/C Low Pressure Switch
• A/C Request
• A/C Switch
• Air Temperature Actuator
• Blower Motor
• Blower Motor Resistor Assembly
• Blower Relay
• Htr A/C Fuse
• Hvac 1 Fuse
• Hvac Control Module
• Hvac Module
• Ign E Fuse
• Left I/P Fuse Block
• Lo Off
• Mode Actuator
• Powertrain Control Module
• Rear Defog Rly Ign 3 Vol A/C Request Act Pos Sig
• Recirc Door Ctrl
• Recirculation Actuator
• Relay Ctrl A/C Comp
• Right I/P Fuse Block
• Underhood Fuse Block
