Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Front Memory Seat Switch Screw | 2 N.m | 18 lb in |
| Front Seat Cushion Frame Nut | 9 N.m | 80 lb in |
| Front Seat Recliner Motor Bolt | 10 N.m | 89 lb in |
| Memory Seat Module Nut | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 66
Scheme 66: Driver Seat Schematics
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 70: Passenger Seat Schematics
Scheme 71
Scheme 72
Scheme 72: Power Seat Component Views
| Callout | Component Name |
|---|
| 1 | Outside Rearview Mirror (OSRVM) - Driver |
| 2 | Memory/Heated Seat Switch (AN3) |
Scheme 73
| Callout | Component Name |
|---|
| 1 | Seat Recline Motor - Driver (AN3) |
| 2 | Seat Lumbar Vertical Motor Position Sensor - Driver (AN3) |
| 3 | Seat Lumbar Vertical Motor - Driver (AN3) |
| 4 | X324 (AN3) |
| 5 | Seat Lumbar Horizontal Motor - Driver (AN3) |
| 6 | Seat Lumbar Horizontal Motor Position Sensor - Driver (AN3) |
| 7 | Seat Recline Position Sensor - Driver (AN3) |
| 8 | Seat Lumbar Switch - Driver (AN3) |
| 9 | Seat Adjuster Switch - Driver |
| 10 | Memory Seat Module (AN3) |
| 11 | Inflatable Restraint Seat Position Sensor (SPS) - Left (10 Series) |
| 12 | Seat Adjuster Assembly - Driver |
| 13 | Seat Belt Buckle - Driver |
Scheme 74
| Callout | Component Name |
|---|
| 1 | Seat Frame |
| 2 | X325 (AN3) |
| 3 | Seat Lumbar Vertical Motor - Passenger (AN3) |
| 4 | Seat Adjuster Switch - Passenger |
| 5 | Seat Lumbar Switch - Passenger (AN3) |
| 6 | Seat Belt Buckle - Passenger |
| 7 | Inflatable Restraint Passenger Presence System (PPS) Module (AL0) |
| 8 | Seat Adjuster Assembly - Passenger |
| 9 | Inflatable Restraint Passenger Presence System (PPS) Sensor (AL0) |
| 10 | Seat Recline Motor - Passenger (AN3) |
| 11 | Seat Lumbar Horizontal Motor - Passenger (AN3) |
Scheme 75
Scheme 75: Memory Seat Module X1 (AN3)
| Connector Part Information OEM: 6098-4611 Service: 15134091 Description: 16-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: 8240-0128/2 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
Memory Seat Module X1 (AN3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1 PU | 2424 | Driver Heated Seat Back Element Control |
| 2-3 | | | Not Used |
| 4 | 1 L-BU | 2433 | Passenger Heated Seat Back Element Control |
| 5 | | | Not Used |
| 6 | 1 D-BU | 2479 | Heated Seat Cushion Element Supply Voltage |
| 7-8 | | | Not Used |
| 9 | 1 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| 10 | 1 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
| 11 | 1 L-GN | 2078 | Ground (Except KB6) |
| 12 | 1 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
| 13 | 1 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
| 14 | 1 PK | 2077 | Heated Seat Cushion Element Supply Voltage |
| 15 | 1 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
| 16 | 1 L-BU | 283 | Driver Seat Rear Vertical Motor Down Control |
Memory Seat Module X1 (AN3) Connector Terminal Identification
Scheme 76
Scheme 76: Memory Seat Module X2 (AN3)
| Connector Part Information OEM: 6098-4607 Service: See Catalog Description: 6-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: 8100-4443/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (PU) |
Memory Seat Module X2 (AN3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.35 GY | 6206 | Low Reference |
| 2 | 0.35 PK | 2426 | Low Reference |
| 3 | 0.35 YE | 2080 | Low Reference |
| 4 | | | Not Used |
| 5 | 0.35 TN | 2482 | Low Reference |
| 6 | 0.35 PK | 2435 | Low Reference |
Memory Seat Module X2 (AN3) Connector Terminal Identification
Scheme 77
Scheme 77: Memory Seat Module X3 (AN3)
| Connector Part Information OEM: 6098-4606 Service: See Catalog Description: 6-Way F (BN) |
|---|
| Terminal Part Information Pins: 1, 4-5 Terminal/Tray: 8100-4445/2 Core/Insulation Crimp: F/D Release Tool/Test Probe: 15315247/J-35616-35 (PU) Pins: 3, 6 Terminal/Tray: 8100-4443 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (PU) |
Memory Seat Module X3 (AN3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 3 BK | 1150 | Ground |
| 2 | | | Not Used |
| 3 | 0.35 PU/WH | 6205 | 12-Volt Reference |
| 4 | 3 BK | 1150 | Ground |
| 5 | 3 RD/WH | 5040 | Battery Positive Voltage |
| 6 | 0.5 RD/WH | 1140 | Battery Positive Voltage |
Memory Seat Module X3 (AN3) Connector Terminal Identification
Scheme 78
Scheme 78: Memory Seat Module X4 (AN3)
| Connector Part Information OEM: 6098-4610 Service: See Catalog Description: 16-Way F (GN) |
|---|
| Terminal Part Information Terminal/Tray: 8240-0128/2 Core/Insulation Crimp: C/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
Memory Seat Module X4 (AN3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 1 PU | 767 | Driver Seat Lumbar Motor Down Control |
| 2 | 1 TN | 768 | Driver Seat Lumbar Motor Up Control |
| 3-8 | | | Not Used |
| 9 | 1 PU | 5130 | Adjustable Pedal Motor Forward Control (JF4) |
| 10 | 1 OG/BK | 5129 | Adjustable Pedal Motor Rearward Control (JF4) |
| 11 | | | Not Used |
| 12 | 1 D-BU | 611 | Driver Seat Lumbar Motor Forward Control |
| 13 | 1 PK | 610 | Driver Seat Lumbar Motor Rearward Control |
| 14 | 1 PK | 2480 | Ground (Except KB6) |
| 15 | 1 L-GN | 276 | Driver Seat Recline Motor Forward Control |
| 16 | 1 L-BU | 277 | Driver Seat Recline Motor Rearward Control |
Memory Seat Module X4 (AN3) Connector Terminal Identification
Scheme 79
Scheme 79: Memory Seat Module X5 (AN3)
| Connector Part Information OEM: 31410-1200 Service: See Catalog Description: 20-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4618-02/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215/J-35616-64B (L-BU) |
Memory Seat Module X5 (AN3) Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| 1 | 0.35 YE/BK | 2079 | Driver Heated Seat Cushion Temperature Signal (Except KB6) |
| 2 | 0.35 GY | 2434 | Driver Heated Seat Cushion Temperature Signal (Except KB6) |
| 3 | 0.35 TN | 2436 | Driver Heated Seat Back Temperature Signal (Except KB6) |
| 4 | 0.35 D-BU | 2425 | Driver Heated Seat Back Temperature Signal (Except KB6) |
| 5-9 | | | Not Used |
| 10 | 0.5 PK | 5289 | Adjustable Pedal Sensor Signal (JF4) |
| 11 | 0.35 TN | 6207 | 5-Volt Reference |
| 12-13 | | | Not Used |
| 14 | 0.35 BN/WH | 557 | Seat Front Vertical Motor Position Sensor Signal |
| 15 | 0.35 TN | 568 | Seat Rear Vertical Motor Position Sensor Signal |
| 16 | 0.35 D-GN | 569 | Seat Horizontal Motor Position Sensor Signal |
| 17 | 0.35 WH/BK | 570 | Driver Seat Recline Motor Position Sensor Signal |
| 18 | 0.35 TN/BK | 1062 | Driver Seat Lumbar Vertical Position Sensor Signal |
| 19 | 0.35 YE | 1063 | Driver Seat Lumbar Horizontal Position Sensor Signal |
| 20 | | | Not Used |
Memory Seat Module X5 (AN3) Connector Terminal Identification
