Removal Procedure
- Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-278014-S01448585812008012100000) .
- Remove the mounting bolts for the oil pan skid plate.
- Remove the oil pan skid plate.
- Remove the mounting bolts for the oil pan skid plate.
- Remove the oil pan skid plate.
Installation Procedure
- Position the oil skid plate on the frame.
- Install the oil skid plate mounting bolts. NOTE: Refer to «Fastener Notice»(ref-277992-S11872939162008012100000) . Tighten: Tighten the bolts to 25 N.m (18 lb ft).
- Position the oil pan skid plate on the frame.
- Install the oil skid plate mounting bolts. NOTE: Refer to «Fastener Notice»(ref-277992-S11872939162008012100000) . Tighten: Tighten the bolts to 28 N.m (21 lb ft).
- Lower the vehicle.
Scheme 3
Scheme 3: Engine Shield Replacement
| Callout | Component Name |
| 1 | Engine Shield Bolts (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 20 N.m (15 lb ft) |
| 2 | Engine Shield |
| NOTE |
| Refer to Fastener Notice . |
Engine Shield Replacement
Scheme 4
Scheme 4: Drivetrain and Front Suspension Frame Front Crossmember Replacement (1500, 2500 LD)
| Callout | Component Name |
| Preliminary Procedure Raise the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the oil pan skid plate. Refer to Oil Pan Skid Plate Replacement . |
| 1 | Engine Front Crossmember Nut (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 120 N.m (89 lb ft) |
| 2 | Engine Front Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 3 | Lower Control Arm Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Drivetrain and Front Suspension Frame Front Crossmember Replacement (1500, 2500 LD)
Scheme 5
Scheme 5: Drivetrain and Front Suspension Frame Front Crossmember Replacement (2WD 2500 HD, 3500)
| Callout | Component Name |
| Preliminary Procedure Raise the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the oil pan skid plate. Refer to Oil Pan Skid Plate Replacement . |
| 1 | Engine Front Crossmember Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 120 N.m (89 lb ft) |
| 2 | Engine Front Crossmember Bolt (Qty: 2) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 3 | Engine Front Crossmember Nut (Qty: 2) Tighten: 120 N.m (89 lb ft) |
| 4 | Engine Front Crossmember Bolt (Qty: 2) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 5 | Lower Control Arm Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Drivetrain and Front Suspension Frame Front Crossmember Replacement (2WD 2500 HD, 3500)
Scheme 6
Scheme 6: Drivetrain and Front Suspension Frame Front Crossmember Replacement (4WD 2500 HD, 3500)
| Callout | Component Name |
| Preliminary Procedure: Raise the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Engine Front Crossmember Nut (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 120 N.m (89 lb ft) |
| 2 | Engine Front Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 3 | Lower Control Arm Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Drivetrain and Front Suspension Frame Front Crossmember Replacement (4WD 2500 HD, 3500)
Scheme 7
Scheme 7: Transmission Support Crossmember Replacement (2WD 1500/2500)
| Callout | Component Name |
| Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Support the transmission with a transmission jack. |
| 1 | Transmission Mount to Crossmember Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 40 N.m (30 lb ft) |
| 2 | Transmission Crossmember Nut (Qty: 4) Tighten: 97 N.m (70 lb ft) |
| 3 | Transmission Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 4 | Transmission Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Transmission Support Crossmember Replacement (2WD 1500/2500)
Scheme 8
Scheme 8: Transmission Support Crossmember Replacement (2WD 2500 HD/3500)
| Callout | Component Name |
| Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Support the transmission with a transmission jack. |
| 1 | Transmission Mount to Crossmember Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 40 N.m (30 lb ft) |
| 2 | Transmission Crossmember Nut (Qty: 4) Tighten: 97 N.m (70 lb ft) |
| 3 | Transmission Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 4 | Transmission Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Transmission Support Crossmember Replacement (2WD 2500 HD/3500)
Scheme 9
Scheme 9: Transmission Support Crossmember Replacement (4WD 1500/2500)
| Callout | Component Name |
| Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Support the transmission with a transmission jack. |
| 1 | Transmission Mount to Crossmember Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 40 N.m (30 lb ft) |
| 2 | Transmission Crossmember Nut (Qty: 4) Tighten: 97 N.m (70 lb ft) |
| 3 | Transmission Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 4 | Transmission Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Transmission Support Crossmember Replacement (4WD 1500/2500)
Scheme 10
Scheme 10: Transmission Support Crossmember Replacement (4WD 2500 HD/3500)
| Callout | Component Name |
| Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Support the transmission with a transmission jack. |
| 1 | Transmission Mount to Crossmember Nut (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 40 N.m (30 lb ft) |
| 2 | Transmission Crossmember Nut (Qty: 4) Tighten: 97 N.m (70 lb ft) |
| 3 | Transmission Crossmember Bolt (Qty: 4) Tip: Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply threadlocker GM P/N 12345493 (Canadian P/N 10953488). |
| 4 | Transmission Crossmember |
| NOTE |
| Refer to Fastener Notice . |
Transmission Support Crossmember Replacement (4WD 2500 HD/3500)
- Remove the master cylinder. Perform the following steps: Remove the nuts retaining the master cylinder to the brake booster. Remove the master cylinder from the brake booster. Secure the cylinder away from the booster.
- Raise the vehicle on the hoist. Refer to «Lifting and Jacking the Vehicle»(ref-278014-S01448585812008012100000) .
- Remove the park brake equalizer intermediate cable. Perform the following steps: Remove the nut from the park brake equalizer intermediate cable. Remove the intermediate cable from the equalizer. Depress the retaining tabs that secure the park brake cable to the frame. Pull slightly on the cable from the mounting area in order to provide slack for body movement without binding the cable.
- Remove the body mount bolts.
- Properly support the body in the area that the mounts will be replaced.
- Lower the chassis accordingly in order to remove the cushions (1) as necessary.
- Install the cushions (1) as necessary and raise the chassis accordingly.
- Perform the following procedure before installing the bolts. Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply Threadlocker GM P/N 12345493 (Canadian P/N 10953488).
- Install the body mount bolts. Tighten: Tighten the bolts to 100 N.m (74 lb ft).
- Install the park brake equalizer intermediate cable. Perform the following steps: Pull rearward on the park brake cable to the original position. Secure the cable retaining tabs to the frame. Install the intermediate cable end to the equalizer. Install the nut to the threaded end of the intermediate cable. Tighten: Tighten the nut to 4 N.m (35 lb in).
- Lower the vehicle.
- Install the master cylinder. Perform the following steps: Mount the master cylinder to the brake booster. Install the master cylinder mounting nuts. Tighten: Tighten the nuts to 36 N.m (27 lb ft).
- Remove the master cylinder. Perform the following steps: Remove the nuts retaining the master cylinder to the brake booster. Remove the master cylinder from the brake booster. Secure the cylinder away from the booster.
- Raise the vehicle on the hoist. Refer to «Lifting and Jacking the Vehicle»(ref-278014-S01448585812008012100000) .
- Remove the park brake equalizer intermediate cable. Perform the following steps: Remove the nut from the park brake equalizer intermediate cable. Remove the intermediate cable from the equalizer. Depress the retaining tabs that secure the park brake cable to the frame. Pull slightly on the cable from the mounting area in order to provide slack for body movement without binding the cable.
- Remove the body mount bolts.
- Properly support the body in the area that the mounts will be replaced.
- Lower the chassis accordingly in order to remove the cushions (1) as necessary.
- Install the cushions (1) as necessary and raise the chassis accordingly.
- Perform the following procedure before installing the bolts. Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply Threadlocker GM P/N 12345493 (Canadian P/N 10953488).
- Install the body mount bolts. Tighten: Tighten the bolts to 100 N.m (74 lb ft).
- Install the park brake equalizer intermediate cable. Perform the following steps: Pull rearward on the park brake cable to the original position. Secure the cable retaining tabs to the frame. Install the intermediate cable end to the equalizer. Install the nut to the threaded end of the intermediate cable. Tighten: Tighten the nut to 4 N.m (35 lb in).
- Lower the vehicle.
- Install the master cylinder. Perform the following steps: Mount the master cylinder to the brake booster. Install the master cylinder mounting nuts. Tighten: Tighten the nuts to 36 N.m (27 lb ft).
Scheme 11
Scheme 11: Front Wheelhouse Liner Replacement - Right Side (Chevrolet)
| Callout | Component Name |
| Preliminary Procedure: Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . |
| 1 | Right Side Front Wheelhouse Liner Screw (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 2.5 N.m (22 lb in) |
| 2 | Right Side Front Wheelhouse Liner Plastic Retainer (Qty: 8) |
| 3 | Right Side Front Wheelhouse Liner Tip: Disconnect any electrical harnesses/connectors and attached parts from the right side front wheelhouse liner as needed. Use the reverse procedure to install to help with the proper alignment of the right side front wheelhouse liner. |
| NOTE |
| Refer to Fastener Notice . |
Front Wheelhouse Liner Replacement - Right Side (Chevrolet)
Scheme 12
Scheme 12: Front Wheelhouse Liner Replacement - Right Side (GMC)
| Callout | Component Name |
| Preliminary Procedure: Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . |
| 1 | Right Side Front Wheelhouse Liner Screw (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 2.5 N.m (22 lb in) |
| 2 | Right Side Front Wheelhouse Liner Plastic Retainer (Qty: 10) |
| 3 | Right Side Front Wheelhouse Liner Tip: Disconnect any electrical harnesses/connectors and attached parts from the right side front wheelhouse liner as needed. Use the reverse procedure to install to help with the proper alignment of the right side front wheelhouse liner. |
| NOTE |
| Refer to Fastener Notice . |
Front Wheelhouse Liner Replacement - Right Side (GMC)
Scheme 13
Scheme 13: Front Wheelhouse Liner Replacement - Left Side (Chevrolet)
| Callout | Component Name |
| Preliminary Procedure: Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . |
| 1 | Left Side Front Wheelhouse Liner Screw (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 2.5 N.m (22 lb in) |
| 2 | Left Side Front Wheelhouse Liner Plastic Retainer (Qty: 7) |
| 3 | Left Side Front Wheelhouse Liner Tip: Disconnect any electrical harnesses/connectors and attached parts from the left side front wheelhouse liner as needed. Use the reverse procedure to install to help with the proper alignment of the left side front wheelhouse liner. |
| NOTE |
| Refer to Fastener Notice . |
Front Wheelhouse Liner Replacement - Left Side (Chevrolet)
Scheme 14
Scheme 14: Front Wheelhouse Liner Replacement - Left Side (GMC)
| Callout | Component Name |
| Preliminary Procedure: Remove the tire/wheel assembly. Refer to Tire and Wheel Removal and Installation . |
| 1 | Left Side Front Wheelhouse Liner Screw (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 2.5 N.m (22 lb in) |
| 2 | Left Side Front Wheelhouse Liner Plastic Retainer (Qty: 9) |
| 3 | Left Side Front Wheelhouse Liner Tip: Disconnect any electrical harnesses/connectors and attached parts from the left side front wheelhouse liner as needed. Use the reverse procedure to install to help with the proper alignment of the left side front wheelhouse liner. |
| NOTE |
| Refer to Fastener Notice . |
Front Wheelhouse Liner Replacement - Left Side (GMC)
Scheme 15
Scheme 15: Engine Splash Shield Replacement - Left Side
| Callout | Component Name |
| Preliminary Procedure: Remove the left front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement - Left Side (Chevrolet) or Front Wheelhouse Liner Replacement - Left Side (GMC) . |
| 1 | Lower Left Engine Splash Shield Bolts (Qty: 2) NOTE: Refer to Fastener Notice . Tighten: 12 N.m (106 lb in) |
| 2 | Lower Left Engine Splash Shield |
| NOTE |
| Refer to Fastener Notice . |
Engine Splash Shield Replacement - Left Side
Scheme 16
Scheme 16: Engine Splash Shield Replacement - Right Side
| Callout | Component Name |
| Preliminary Procedure: Remove the right front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement - Right Side (Chevrolet) or Front Wheelhouse Liner Replacement - Right Side (GMC) . |
| 1 | Lower Right Engine Splash Shield Plastic Retainers (Qty: 2) |
| 2 | Lower Right Engine Splash Shield |
Engine Splash Shield Replacement - Right Side
Scheme 17
Scheme 17: Assist Step Replacement
| Callout | Component Name |
| Preliminary Procedure: Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Assist Step Assembly |
| 2 | Assist Step Bolt (Qty: 4) NOTE: Refer to Fastener Notice . Tip: Secure the forward and rearward bolts first after the assist step has been installed. Tighten: 18 N.m (13 lb ft) |
| 3 | Assist Step Bracket Nut (Qty: 2) Tighten: 18 N.m (13 lb ft) |
| 4 | Rocker Panel Bolt (Qty: 2) Tighten: 18 N.m (13 lb ft) |
| 5 | Front Fender Extension Screw (Qty: 2) Tip: Do not exceed the recommended torque specification as noted. Tighten: 6 N.m (53 lb in) |
| 6 | Front Fender Extension |
| NOTE |
| Refer to Fastener Notice . |
Scheme 18
Scheme 18: Trailer Hitch Draw Bar Replacement
| Callout | Component Name |
| 1 | Trailer Hitch Draw Bar Bolt (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 90 N.m (66 lb ft) |
| 2 | Trailer Hitch Draw Bar Bolt (Qty: 2) Tighten: 40 N.m (30 lb ft) |
| 3 | Trailer Hitch Draw Bar Bolt (Qty: 2) Tighten: 100 N.m (74 lb ft) |
| 4 | Trailer Hitch Draw Bar Tip: Disconnect any electrical connectors/harnesses before attempting removal. Transfer any parts as needed. |
| NOTE |
| Refer to Fastener Notice . |
Trailer Hitch Draw Bar Replacement
Trailer Hitch Replacement
For Escalade and Denali applications the trailer hitch is part of the impact bar. Refer to Rear Bumper Impact Bar Replacement .
- Disconnect the trailer wiring harness.
- Remove the hitch platform bolts from the frame rails and the rear bumper.
- Remove the hitch platform from the vehicle.
- Position the hitch platform to the vehicle.
- Install the platform hitch bolts to the frame rails and the rear bumper. Tighten: Tighten the bolts to 125 N.m (92 lb ft).
- Connect the trailer wiring harness.
