Application Procedure
| IMPORTANT | The striping material highlights vehicle surface imperfections. Eliminate all of the following before applying the stripe or the decal: Dings Rough metal Paint defects Uneven 2-tone paint breaklines |
| IMPORTANT | Apply stripes and decals in a clean environment where dust and fibers do not interfere with proper adhesion. |
- Clean the area where you will mount the decal. Use the suitable solvents flash naptha, or a mixture of 50 percent isopropyl alcohol and 50 percent water. Dry the area thoroughly. Repaint the area. Feather the paint in, if the paint is chipped.
- Warm the body surface to 27-38°C (80-100°F).
- Mount the stripes or the decals that wrap into the body openings or mount on flexible surfaces wet.
Use the following procedure for wet application of stripes and decals
- Use Dupont Duponal WA or the equivalent for a wetting agent. Do not use a soap solution. Spray a mist of solution onto the body area.
- Peel the backing away from the decal. Spray the adhesive backing of the decal in hot, humid weather with a mist of the wetting solution.
- Use a squeegee, starting at the center of the decal. Squeegee the decal onto the body, removing air bubbles and the wetting solution.
- Pull the decal back onto itself in order to remove the premask from the decal.
- Squeegee the decal again.
- Prick any air bubbles with a pin, if present.
Scheme 93
Scheme 93: Radiator Grille Emblem Replacement (GMC)
| Callout | Component Name |
| 1 | Emblem Assembly (GMC) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all adhesive from grille and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Using the palm of the hand, wet out the emblem to the grille and ensure full adhesion of the emblem is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Radiator Grille Emblem Replacement (GMC)
Scheme 94
Scheme 94: Door Emblem and Nameplate Replacement (Chevrolet Silverado)
| Callout | Component Name |
| 1 | Front Side Door Nameplate/Emblem (Silverado) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the door. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the door and press to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (Chevrolet Silverado)
Scheme 95
Scheme 95: Door Emblem and Nameplate Replacement (GMC Sierra)
| Callout | Component Name |
| 1 | Front Side Door Nameplate/Emblem (Sierra) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the door. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the door and press to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (GMC Sierra)
Scheme 96
Scheme 96: Door Emblem and Nameplate Replacement (Silverado Sierra 2500)
| Callout | Component Name |
| 1 | Front Side Door Nameplate/Emblem (2500) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the door. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the door and press to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (Silverado Sierra 2500)
Scheme 97
Scheme 97: Door Emblem and Nameplate Replacement (GME)
| Callout | Component Name |
| 1 | Front Side Door Nameplate (GM) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing the new GM nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Press the nameplate firmly to the front side door to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (GME)
Scheme 98
Scheme 98: Door Emblem and Nameplate Replacement (GMC Denali)
| Callout | Component Name |
| 1 | Front Side Door Nameplate/Emblem (Denali) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the door. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the door and press to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (GMC Denali)
Scheme 99
Scheme 99: Door Emblem and Nameplate Replacement (GMC Allison Transmission)
| Callout | Component Name |
| 1 | Front Side Door Nameplate/Emblem (Allison Duramax) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the door. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the door and press to ensure full adhesion is made to the door. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Door Emblem and Nameplate Replacement (GMC Allison Transmission)
Scheme 100
Scheme 100: Endgate Emblem and Nameplate Replacement (Cheyenne LT LS)
| Callout | Component Name |
| 1 | Endgate Nameplate/Emblem (LT) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| 2 | Endgate Nameplate/Emblem (LS) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate/emblem. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates/emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (Cheyenne LT LS)
Scheme 101
Scheme 101: Endgate Emblem and Nameplate Replacement (Cheyenne or Silverado)
| Callout | Component Name |
| 1 | Endgate Nameplate/Emblem (Silverado) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| 2 | Endgate Nameplate/Emblem (Cheyenne) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate/emblem. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates/emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (Cheyenne or Silverado)
Scheme 102
Scheme 102: Endgate Emblem and Nameplate Replacement (GMC)
| Callout | Component Name |
| 1 | Endgate Nameplate/Emblem (Sierra) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| 2 | Endgate Nameplate/Emblem (GMC) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate/emblem. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates/emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (GMC)
Scheme 103
Scheme 103: Endgate Emblem and Nameplate Replacement (GMC SLE SLT)
| Callout | Component Name |
| 1 | Endgate Nameplate/Emblem (SLT) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| 2 | Endgate Nameplate/Emblem (SLE) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate/emblem. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates/emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (GMC SLE SLT)
Scheme 104
Scheme 104: Endgate Emblem and Nameplate Replacement (Z71)
| Callout | Component Name |
| 1 | Endgate Nameplate/Emblem (Z71) NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure Use a J 25070 or equivalent to remove the old nameplate. See Special Tools . Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the endgate prior to installing the new nameplate/emblem to the endgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the endgate and press to ensure full adhesion is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (Z71)
Scheme 105
Scheme 105: Endgate Emblem and Nameplate Replacement (Chevrolet)
| Callout | Component Name |
| 1 | Endgate Nameplate NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all adhesive from bodyside panel and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Using the palm of the hand, wet out the name plate to the body side and ensure full adhesion of the nameplate is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (Chevrolet)
Scheme 106
Scheme 106: Endgate Emblem and Nameplate Replacement (Chevrolet FFU)
| Callout | Component Name |
| 1 | Flex Fuel Badge NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all adhesive from end gate panel and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Using the palm of the hand, wet out the name plate to the end gate and ensure full adhesion of the name plate is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (Chevrolet FFU)
Scheme 107
Scheme 107: Endgate Emblem and Nameplate Replacement (GMC FFU)
| Callout | Component Name |
| 1 | Flex Fuel Badge NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all adhesive from end gate panel and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Using the palm of the hand, wet out the name plate to the end gate and ensure full adhesion of the name plate is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (GMC FFU)
Scheme 108
Scheme 108: Endgate Emblem and Nameplate Replacement (TUF)
| Callout | Component Name |
| 1 | Endgate Nameplate NOTE: Refer to Exterior Trim Emblem Removal Notice . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 Heat Gun or equivalent to remove the old nameplate. See Special Tools . Clean all adhesive from the endgate and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Using the palm of the hand, wet out the name plate to the endgate and ensure full adhesion of the nameplate is made. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Endgate Emblem and Nameplate Replacement (TUF)
Scheme 109
Scheme 109: Radiator Grille Replacement (GMC)
| Callout | Component Name |
| Preliminary Procedure: Remove the radiator air upper baffle/deflector. Refer to Radiator Air Upper Baffle and Deflector Replacement . |
| 1 | Radiator Grille Bolt (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 7 N.m (62 lb in) |
| 2 | Radiator Grille Tip: Separate the clips holding the radiator grille to the hood stop and hood bumper brackets. Separate the radiator grille from the front bumper fascia trim cap by pushing the radiator grille towards the vehicle while pulling the front bumper fascia trim cap away from the vehicle. |
| NOTE |
| Refer to Fastener Notice . |
Radiator Grille Replacement (GMC)
Scheme 110
Scheme 110: Radiator Grille Replacement (Chevrolet)
| Callout | Component Name |
| Preliminary Procedure: Remove the radiator air upper baffle/deflector. Refer to Radiator Air Upper Baffle and Deflector Replacement . |
| 1 | Radiator Grille Bolts (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 7 N.m (62 lb in) |
| 2 | Radiator Grille Tip: Separate the clips holding the radiator grille to the hood stop and hood bumper brackets and pull forward. |
| NOTE |
| Refer to Fastener Notice . |
Radiator Grille Replacement (Chevrolet)
Scheme 111
Scheme 111: Door Body Side Molding Replacement (Chevrolet)
| Callout | Component Name |
| 1 | Front Side Door Molding Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Using a J 25070 Heat Gun in a circular motion, warm the front side door molding prior to removal. See Special Tools . Carefully clean the body panel thoroughly prior to bonding the new front body side molding to the door. Ensure the front door is in the closed position prior to installing the new front side door molding. Remove the protective liner from the backside of the molding adhesive tape. Position the pin on the backside of the molding to the round hole at the rear edge of the front door first, then to the oval hole at the front edge of the door. Ensure full adhesion of the molding to the door using the palm of the hand with a clean dry towel working from the rear edge of the door to the front, down the entire molding. |
Door Body Side Molding Replacement (Chevrolet)
Scheme 112
Scheme 112: Door Body Side Molding Replacement (GMC)
| Callout | Component Name |
| 1 | Rear Side Door Molding Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Using a J 25070 Heat Gun in a circular motion, warm the front side door molding prior to removal. See Special Tools . Carefully clean the body panel thoroughly prior to bonding the new front body side molding to the door. Ensure the rear door is in the closed position prior to installing the new rear side door moldings. Remove the protective liner from the backside of the molding adhesive tape. Position the pin on the backside of the molding to the round hole at the front edge of the rear door first, then to the oval hole at the rear edge of the door. Ensure full adhesion of the molding to the door using the palm of the hand with a clean dry towel working from the rear edge of the door to the front, down the entire molding. |
Door Body Side Molding Replacement (GMC)
Scheme 113
Scheme 113: Door Body Side Molding Replacement (Crew Cab)
| Callout | Component Name |
| 1 | Front Side Door Molding Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Using a J 25070 Heat Gun in a circular motion, warm the front side door molding prior to removal. See Special Tools . Carefully clean the body panel thoroughly prior to bonding the new front body side molding to the door. Ensure the front door is in the closed position prior to installing the new front side door moldings. Remove the protective liner from the backside of the molding adhesive tape. Position the pin on the backside of the molding to the round hole at the front edge of the front door first, then to the oval hole at the rear edge of the door. Ensure full adhesion of the molding to the door using the palm of the hand with a clean dry towel working from the rear edge of the door to the front, down the entire molding. |
Door Body Side Molding Replacement (Crew Cab)
Scheme 114
Scheme 114: Door Body Side Molding Replacement (Extended Cab)
| Callout | Component Name |
| 1 | Extended Door Side Molding Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Using a J 25070 Heat Gun in a circular motion, warm the side door molding prior to removal. See Special Tools . Carefully clean the body panel thoroughly prior to bonding the new door body side molding to the door. Ensure the door is in the closed position prior to installing the new side door moldings. Remove the protective liner from the backside of the molding adhesive tape. Position the molding to the edge of the side door, then to the rear edge of the door. Ensure full adhesion of the molding to the door using the palm of the hand with a clean dry towel working from the front edge of the door to the rear, down the entire molding. |
Door Body Side Molding Replacement (Extended Cab)
Scheme 115
Scheme 115: Front Side Door Molding Replacement (GMC Denali)
| Callout | Component Name |
| 1 | Front Side Door Molding Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Using a J 25070 Heat Gun in a circular motion, warm the front side door molding prior to removal. See Special Tools . Carefully clean the body panel thoroughly prior to bonding the new front body side molding to the door. Ensure the front door is in the closed position prior to installing the new front side door moldings. Remove the protective liner from the backside of the molding adhesive tape. Position the pin on the backside of the molding to the round hole at the front edge of the rear door first, then to the oval hole at the rear edge of the door. Ensure full adhesion of the molding to the door using the palm of the hand with a clean dry towel working from the rear edge of the door to the front, down the entire molding. |
Front Side Door Molding Replacement (GMC Denali)
Scheme 116
Scheme 116: Hood Front Molding Replacement (Chevrolet V22)
| Callout | Component Name |
| Preliminary Procedure: Release the hood in order to access the front hood molding. |
| 1 | Hood Front Molding Locator Tab Tip: Position the locator tab first into the hood panel center hole followed by the remaining retainers. |
| 2 | Hood Front Molding Retainer Clips Tip: Secure the retainer clips working from the center of the molding, outward until all the clips are secure to the hood. |
| 3 | Hood Front Molding |
Hood Front Molding Replacement (Chevrolet V22)
Scheme 117
Scheme 117: Hood Front Molding Replacement (GMC HD)
| Callout | Component Name |
| Preliminary Procedure: Release the hood in order to access the front hood molding. |
| 1 | Hood Front Molding Locator Tab Tip: Position the locator tab first into the hood panel center hole followed by the remaining retainers. |
Hood Front Molding Replacement (GMC HD)
Scheme 118
Scheme 118: Hood Front Molding Replacement (GMC Denali)
| Callout | Component Name |
| Preliminary Procedure: Open the hood in order to access and remove the front hood molding. |
| 1 | Hood Front Molding Assembly Tip: Release the integral retainers from the hood. Upon installation, align the left hand center retainer first into the hood as indicated. Gently secure the remaining retainers working from left to right across the entire hood front molding. |
Hood Front Molding Replacement (GMC Denali)
Scheme 119
Scheme 119: Hood Rear Molding Replacement (Chevrolet HD)
| Callout | Component Name |
| 1 | Hood Rear Molding Screw (Qty: 2) NOTE: Refer to Fastener Notice . Tighten:: 1.5 N.m (13 lb in) |
| 2 | Hood Rear Molding Assembly Nut (Qty: 2) |
| 3 | Hood Rear Molding Integral Clip (Qty: 4) Tip: Ensure all four clips are fully seated prior to installing the hood rear molding screws. |
| 4 | Hood Rear Molding Tip: Gently pry the hood molding upward, in order to remove. |
| NOTE |
| Refer to Fastener Notice . |
Hood Rear Molding Replacement (Chevrolet HD)
Scheme 120
Scheme 120: Pickup Box Side Upper Molding Replacement (HD)
| Callout | Component Name |
| 1 | Pick Up Box Side Upper Molding Locators (Qty: 3) Tip: Upon installation of the new molding, align the 3 locators to the pick up box side rail and secure the retainers. |
| 2 | Pick Up Box Side Upper Molding Retainers (Qty: 23) Tip: Remove the adhesive tape backing from the molding once the molding is in place. |
| 3 | Pick Up Box Side Upper Molding |
Pickup Box Side Upper Molding Replacement (HD)
Scheme 121
Scheme 121: Roof Panel Joint Finish Molding Replacement
| Callout | Component Name |
| 1 | Roof Panel Joint Finish Molding (Rear) NOTE: Refer to Exterior Trim Emblem Removal Notice . Tip: The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Remove the roof panel finish joint from the roof ditch. Use of a heat gun is recommended. Using a 50/50 mixture of isopropyl alcohol and clean drinkable water and a clean towel, remove the left over adhesive residue from the ditch. Wipe the roof ditch clean with a clean dry towel. Peel the adhesive tape backing from the roof panel joint finish molding. Secure the molding starting at the front edge working rearward. Completely wet out the roof panel finish joint molding. |
| NOTE |
| Refer to Exterior Trim Emblem Removal Notice . |
Roof Panel Joint Finish Molding Replacement
Scheme 122
Scheme 122: Rear Spoiler Replacement (901/902)
| Callout | Component Name |
| 1 | Endgate Spoiler Assembly Screws (Qty: 4) NOTE: Refer to Fastener Notice . Tighten: 10 N.m (89 lb in) |
| 2 | Endgate Spoiler Assembly Locator Pin |
| 3 | Endgate Spoiler Assembly Adhesive Tape Liner Tip: The part and surface should be ambient temperature prior to installation. The vehicle should remain ambient temperature for one hour after assembly to allow adhesive to develop sufficient bond strength. Release the liner and wet out once the endgate spoiler is in position and the screws have been installed. |
| 4 | Endgate Spoiler Assembly |
| 5 | Endgate Spoiler Assembly Riv-nuts (Qty: 4) |
| NOTE |
| Refer to Fastener Notice . |
Rear Spoiler Replacement (901/902)
