Steering Wheel & Steering Column: Specifications GMC Savana G2500

Ignition Switch/steering Lock 4 illustrations

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Column Support Bracket Nuts	30 N.m	22 lb ft
Cruise Control Module Mounting Nuts	5 N.m	44 lb in
Horn Contact Plate Screws	5.5 N.m	49 lb in
Ignition Lock Cylinder Case Screws	7 N.m	62 lb in
Intermediate Shaft Bearing Bracket Retaining Nuts	30 N.m	22 lb ft
Intermediate Shaft Bearing Lower Brace Retaining Nut	30 N.m	22 lb ft
Intermediate Shaft Seal Bolts	2 N.m	18 lb in
Intermediate Shaft to the Steering Column Pinch Bolt	64 N.m	47 lb ft
Intermediate Shaft to the Steering Gear Pinch Bolt	61 N.m	45 lb ft
Linear Shift Assembly to Steering Column Mounting Screws	10 N.m	89 lb in
Lower Intermediate Shaft to Intermediate Shaft Bearing Retaining Bolt	30 N.m	22 lb ft
Power Steering Reservoir Mounting Nuts	6.5 N.m	58 lb in
Shift Lever Screw	1.5 N.m	13 lb in
Steering Column Bulkhead Connector Screw	6 N.m	53 lb in
Steering Column Support Screws	17 N.m	13 lb ft
Steering Column Trim Cover Screws Lower	3.5 N.m	31 lb in
Steering Column Trim Cover Screws Lower	2 N.m	18 lb in
Steering Column Trim Cover Screw Upper	1.5 N.m	13 lb in
Steering Wheel Nut	41 N.m	30 lb ft
Turn Signal Multifunction Switch Screws Side	7 N.m	62 lb in
Turn Signal Multifunction Switch Screws Top	3 N.m	27 lb in
Upper Intermediate Shaft to Intermediate Shaft Bearing Retaining Bolt	30 N.m	22 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Steering Column Disassembled View (Column Shift and Floor Shift Tilt)

Scheme 1: Steering Column Disassembled View (Column Shift and Floor Shift Tilt)

Callout	Component Name
1	Upper Trim Cover
2	Lower Trim Cover
3	Shift Lever Assembly
4	Shift Lever Screw
5	Shift Lever Seal
6	Flanged Prevailing Torque Nut
7	Retaining Ring
8	SIR Coil
9	Wave Washer
10	Bearing Retainer
11	Shaft Lock Shield Assembly
12	Turn Signal Cancel Cam Assembly
13	Upper Bearing Spring
14	Upper Bearing Inner Race Seat
15	Inner Race
16	Pan Head Tapping Screws
17	TORX® Head Screw
18	Ignition Lock Cylinder Case
19	Pan Head Tapping Screw
20	Ignition Switch Assembly
21	Lock Bolt Spring
22	Lock Bolt Assembly
23	Steering Column Tilt Head Assembly
24	Tilt Spring
25	Spring Guide
26	TORX® Head Screw
27	Tilt Lever Assembly
28	Pan Head Tapping Screws
29	Pan Head Tapping Screws
30	Turn Signal and Multifunction Switch Assembly
31	Wire Harness Straps
32	Axial Position Assurance Connector
33	Race and Upper Shaft Assembly
34	Centering Sphere
35	Joint Preload Spring
36	Lower Steering Shaft Assembly
37	Shift Lever Clevis
38	Cam Bushing
39	Linear Shift Shaft Assembly
40	Flat Head Tapping Screws
41	Shift Lever Gate
42	Oval Head 6-Lobed Socket Tapping Screws
43	Gear Shift Lever Support Bracket
44	Actuator Bushing
45	Cable Shift Cam Assembly
46	Actuator Bushing
47	Hexagon Flange Head Bolt
48	Park Lock Cable Assembly
49	Linear Shift Assembly
50	Hexagon Flange Head Bolt
51	Ball and Actuator Assembly
52	Actuator Bushing
53	TORX® Head Screws
54	Pivot Pins
55	Steering Column Support Assembly
56	Steering Column Jacket Assembly
57	Adapter and Bearing Assembly
58	Shaft Seal Retainer
59	Steering Shaft Seal
60	Inner Boot Seal
61	Automatic Transmission Shift Lock Control
62	Coupling and Steering Shaft Assembly
63	Large Flange Hexagon Nut
64	Round Head Locking Bolt

Scheme 2

Scheme 2

Scheme 2

Callout	Component Name
1	Upper Trim Cover
2	Lower Trim Cover
3	Flanged Prevailing Torque Nut
4	Retaining Ring
5	SIR Coil
6	Wave Washer
7	Bearing Retainer
8	Shaft Lock Shield Assembly
9	Turn Signal Cancel Cam Assembly
10	Upper Bearing Spring
11	Upper Bearing Inner Race Seat
12	Inner Race
13	Pan Head Tapping Screws
14	TORX® Head Screw
15	Ignition Lock Cylinder Case
16	Pan Head Tapping Screw
17	Ignition Switch Assembly
18	Lock Bolt Spring
19	Lock Bolt Assembly
20	Steering Column Tilt Head Assembly
21	Tilt Spring
22	Spring Guide
23	TORX® Head Screw
24	Tilt Lever Assembly
25	Pan Head Tapping Screws
26	Pan Head Tapping Screws
27	Turn Signal and Multifunction Switch Assembly
28	Wire Harness Straps
29	Axial Position Assurance Connector
30	Steering Column Electric Park Lock
31	Race and Upper Shaft Assembly
32	Joint Preload Spring
33	Centering Spheres
34	Lower Steering Shaft Assembly
35	Pivot Pins
36	TORX® Head Screws
37	Steering Column Support Assembly
38	Steering Column Jacket Assembly
39	Adapter and Bearing Assembly
40	Sensor Retainer
41	Shaft Seal Retainer
42	Steering Shaft Boot
43	Large Flange Hexagon Nut
44	Coupling and Steering Shaft Assembly
45	Round Head Locking Bolt

Scheme 3

Scheme 3: Steering Column Disassembled View (Column Shift and Floor Shift Standard)

Scheme 3: Steering Column Disassembled View (Column Shift and Floor Shift Standard)

Callout	Component Name
1	Shift Lever Assembly
2	Shift Lever Screw
3	Shift Lever Seal
4	Upper Trim Cover
5	Ignition Switch Assembly
6	Pan Head Tapping Screw
7	Ignition Lock Cylinder Case
8	TORX® Head Screw
9	Pan Head Tapping Screws
10	Steering Column Housing Assembly
11	Lock Bolt Spring
12	Lock Bolt Assembly
13	TORX® Head Screws
14	Thrust Washer
15	Upper Bearing Spring
16	Turn Signal Cancel Cam Assembly
17	Shaft Lock Shield Assembly
18	Bearing Retainer
19	Wave Washer
20	SIR Coil
21	Retaining Ring
22	Flanged Prevailing Torque Nut
23	Lower Trim Cover
24	Pan Head Tapping Screws
25	TORX® Head Screw
26	Wire Harness Strap
27	Pan Head Tapping Screws
28	Turn Signal and Multifunction Switch Assembly
29	Axial Position Assurance Connector
30	Wire Harness Straps
31	Linear Shift Assembly
32	Park Lock Cable Assembly
33	Hexagon Flange Head Bolt
34	Cam Bushing
35	Cable Shift Cam Assembly
36	Cam Bushing
37	Oval Head 6-Lobed Socket Tapping Screws
38	Shift Lever Gate
39	Flat Head Tapping Screws
40	Park Position Switch Assembly
41	Actuator Bushing
42	Shift Lever Clevis
43	Gear Shift Lever Assembly Support Bracket Assembly
44	Actuator Bushing
45	Ball and Actuator Assembly
46	Hex Flange Head Bolt
47	Retaining Ring
48	Steering Shaft Assembly
49	Steering Column Jacket Assembly
50	Adapter and Bearing Assembly
51	Shaft Seal Retainer
52	Steering Shaft Seal
53	Inner Boot Seal
54	Large Flange Hexagon Nut
55	Coupling and Steering Shaft Assembly
56	Round Head Locking Bolt
57	Electrical (BTSI) Actuator

Scheme 4

Scheme 4

Scheme 4

Callout	Component Name
1	Upper Trim Cover
2	Ignition Switch Assembly
3	Pan Head Tapping Screw
4	Ignition Lock Cylinder Case
5	TORX® Head Screw
6	Pan Head Tapping Screws
7	Steering Column Housing Assembly
8	Lock Bolt Spring
9	Lock Bolt Assembly
10	TORX® Head Screws
11	Thrust Washer
12	Upper Bearing Spring
13	Turn Signal Cancel Cam Assembly
14	Shaft Lock Shield Assembly
15	Bearing Retainer
16	Wave Washer
17	SIR Coil
18	Retaining Ring
19	Flanged Prevailing Torque Nut
20	Lower Trim Cover
21	Pan Head Tapping Screws
22	TORX® Head Screw
23	Wire Harness Strap
24	Pan Head Tapping Screws
25	Turn Signal and Multifunction Switch Assembly
26	Axial Position Assurance Connector
27	Wire Harness Straps
28	Bearing Retainer
29	Steering Shaft Assembly
30	Steering Column Jacket Assembly
31	Adapter and Bearing Assembly
32	Shaft Seal Retainer
33	Steering Shaft Seal
34	Inner Boot Seal
35	Large Flange Hexagon Nut
36	Coupling and Steering Shaft Assembly
37	Round Head Locking Bolt

Symptoms - Steering Wheel and Column

Review the system description and operation in order to familiarize yourself with the system functions. Refer to Steering Wheel and Column Description and Operation .
