# Courtesy lamps circuit

# Courtesy lamps circuit

Interior lights — Courtesy lamps circuit — Courtesy lamps circuit. GMC Savana G1500 (1996-2013)
Components on the diagram

    # Courtesy lamps circuit (1 of 2)

    Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (1 of 2). GMC Savana G1500 (1996-2013)
    Components on the diagram

      # Courtesy lamps circuit (2 of 2)

      Interior lights — Courtesy lamps circuit — Courtesy lamps circuit (2 of 2). GMC Savana G1500 (1996-2013)
      Components on the diagram
