COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Automatic Transfer Case Shift Control Module | Behind Driver Side Kick Panel. (Scheme 9) |
| Convenience Center | Under Driver Side Of Instrument Panel, Near Driver Side Kick Panel. (Scheme 10) |
| Data Link Connector (DLC) | Under Driver Side Of Instrument Panel. (Scheme 11) |
| Electronic Brake Control Module (EBCM) | Driver Side Frame Rail Near Transmission. (Scheme 12) |
| Inflatable Restraint Sensing & Diagnostic Module (SDM) | Under Driver Front Seat. (Scheme 13) |
| Instrument Panel Fuse Block | Next To Driver Side Kick Panel. (Scheme 10) |
| Passlock Module | Behind Air Duct On Passenger Side Of Instrument Cluster. (Scheme 13) |
| Remote Control Door Lock Receiver (RCDLR) | Behind Air Duct On Passenger Side Of Instrument Cluster. (Scheme 14) |
| Vehicle Control Module (VCM) | Driver Side Of Engine Compartment, Near Battery. (Scheme 15) |
| C100 | Driver Side Of Dash. (Scheme 16) |
| C105 | Driver Side Of Dash, Under Underhood Fuse & Relay Center. (Scheme 17) |
| C200 | Under Driver Side Kick Panel, Near C100. (Scheme 13) |
| C224 | In Convenience Center |
| G105 | On Thermostat Housing. (Scheme 18) |
| G107 | Driver Rear Of Engine Block, Next To Knock Sensor. (Scheme 19) |
| G110 | Driver Side Of Dash, Above Battery. (Scheme 17) |
| P100 | Driver Rear Of Dash, Left Of Bulkhead. (Scheme 16) |
| S113 | Engine Harness, Near Underhood Fuse & Relay Center Breakout. (Scheme 20) |
| S117 | Engine Harness, Near A/C Low Pressure Cutoff Switch Breakout, Towards Engine |
| S204 | Instrument Panel Harness, Near C100 Connector, Towards Passenger Side Of Dash |
| S206 | Instrument Panel Harness, Near C201 Connector, Towards C100. (Scheme 21) |
| S210 | Instrument Panel Harness, Near C201 Connector Breakout, Towards Passenger Side Of Dash. (Scheme 21) |
| S233 | Instrument Panel Harness, Near DLC Breakout, Towards DLC. (Scheme 11) |
