ENGINE IDENTIFICATION

Note. For engine repair procedures not covered in this article, see ENGINE OVERHAUL PROCEDURES - GENERAL INFORMATION article in the GENERAL INFORMATION section.

The engine identification number is stamped on a machined pad on front of cylinder block to rear of engine front cover. The Vehicle Identification Number (VIN) is located on left side of dash panel at base of windshield. The eighth character of VIN denotes engine type.

ENGINE IDENTIFICATION CODES

Valve Arrangement

Left Bank - E-I-I-E-I-E (Front-to-rear).

Right Bank - E-I-E-I-I-E (Front-to-rear).

1. Rotate crankshaft to bring No. 1 piston to TDC of compression stroke. Both No. 1 valves will be closed. Back off adjusting nut until lash (play) is felt at push rod. (Scheme 24)
2. Tighten nut until all lash is removed. Tighten adjusting nut an additional 1 1/2 turns. Adjust valves using sequence listed in VALVE CLEARANCE ADJUSTMENT table.
3. Rotate crankshaft 360 degrees to bring No. 4 piston to TDC of compression stroke. Adjust remaining valves and replace rocker arm covers.

VALVE CLEARANCE ADJUSTMENT SEQUENCE

Scheme 24

TROUBLE SHOOTING

Note. To trouble shoot engine mechanical components, see appropriate table in TROUBLE SHOOTING article in GENERAL INFORMATION.

FUEL PRESSURE RELIEF

Place transmission gear selector in Park (Neutral on manual transmissions). Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines.

"S" Series - 2WD

1. Place transmission gear selector in Park (Neutral on manual transmissions). Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines. WARNING: To avoid possible personal injury and fire danger, fuel pressure must be relieved as outlined in step 1).
2. Disconnect battery. Remove hood and air cleaner. Drain cooling system. Remove radiator hoses, transmission cooler lines (if equipped) and upper fan shroud. Remove radiator and fan and heater hoses. Label and disconnect all vacuum hoses at engine. Disconnect throttle cable and cruise control cables (if equipped).
3. Disconnect ground wires and cables, main feed wires and any necessary wiring at firewall. Remove distributor cap. Raise vehicle. Disconnect exhaust pipe at converter and both manifolds. Remove strut rods, flywheel inspection cover and torque converter bolts.
4. Remove converter hanger at exhaust pipe and rear shield. Disconnect fuel lines and hoses. Remove 2 outer air dam bolts and lower fan shroud. Remove left body mount bolts and raise body to remove bellhousing bolts. Lower body and remove motor mount through bolts.
5. Disconnect A/C compressor and power steering pump from engine and set aside (if equipped). Attach lift equipment to engine. Support transmission and carefully remove engine from vehicle.

"T" Series - 4WD (Automatic Transmission)

1. Place transmission gear selector in Park. Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines. WARNING: To avoid possible personal injury and fire danger, fuel pressure must be relieved as outlined in step 1).
2. Remove hood. Disconnect battery and underhood light. Raise vehicle. On utility vehicles, remove body mounts. On chassis cab models, loosen and remove 2 front body mounts. On all models, remove front air dam end bolts.
3. Raise body above frame and remove top transmission-to-engine bolts. Lower body to frame. Remove remaining transmission-to-engine bolts. Unbolt and remove No. 2 crossmember. Disconnect exhaust pipe at manifolds. Disconnect catalytic converter hanger.
4. Remove front drive shaft at differential. Remove bellhousing cover. Unclip automatic transmission cooler lines at engine. Remove motor mount bolts and flex plate-to-converter bolts. Remove front splash shield (if equipped) and lower fan shroud. Lower vehicle.
5. Drain cooling system. Remove upper fan shroud and radiator hoses. Disconnect automatic transmission cooler lines at radiator. Remove radiator, fan, and air cleaner. Remove A/C compressor and power steering pump from engine and set aside (if equipped).
6. Disconnect fuel lines and hoses. Disconnect vacuum and emission hoses from engine. Disconnect accelerator, throttle valve, and cruise control cables (if equipped). Disconnect engine wiring harness at firewall.
7. Disconnect heater hoses at engine. Disconnect any remaining wiring from engine. Attach hoist to engine and support transmission securely. Remove engine.

"T" Series - 4WD (Manual Transmission)

1. Place transmission gear selector in Neutral. Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines. WARNING: To avoid possible personal injury and fire danger, fuel pressure must be relieved as outlined in step 1).
2. Remove hood and air cleaner. Disconnect battery and underhood light. Drain cooling system and remove upper fan shroud. Remove radiator hoses, fan and clutch. Remove radiator.
3. Remove A/C compressor and power steering pump (if equipped). Disconnect fuel lines and hoses. Remove vacuum and heater hoses at engine. Disconnect accelerator and cruise control cables. Disconnect engine wiring harness, main feed wire, and ground strap at firewall.
4. Remove lower fan shroud. Disconnect battery ground at engine. Remove distributor cap and diverted valve. Remove shifter boot and console cover. Remove transfer case shifter and transmission shifter.
5. Raise vehicle. Remove front and rear skid plates. Remove front splash shield. Drain transfer case and transmission. Remove rear drive shaft. Disconnect speedometer cable and front drive shaft. Disconnect shift linkage and vacuum hoses at transfer case.
6. Disconnect parking brake cable. Remove rear mount and converter bracket. Support transfer case. Unbolt transfer case and remove from vehicle. Remove crossmember. Disconnect back-up light wiring and clip. Unbolt slave cylinder and hang to side. Remove transmission. Remove clutch release bearing and flywheel inspection cover.
7. Remove left side body mounting bolts. Lift left side of body and remove bellhousing. Disconnect exhaust at manifolds and converter. Disconnect clutch cross shaft at frame. Remove starter. Remove motor mount bolts. Lower vehicle. Attach lifting device and remove engine.

Removal

1. Place transmission gear selector in park (neutral on manual transmissions). Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines. WARNING: To avoid possible personal injury and fire danger, fuel pressure must be relieved as outlined in step 1).
2. Remove air cleaner and negative battery cable. Drain cooling system. Disconnect and label all electrical connectors, vacuum hoses and cables at distributor, intake manifold and TBI unit.
3. Disconnect fuel line(s), distributor cap and ignition wires. Mark position of rotor and remove distributor. Remove rocker arm brackets and rocker arm covers.
4. Remove upper radiator hose and heater hose from engine. Remove drive belt and rotate A/C compressor away from work area. Remove intake manifold and discard gaskets.

Installation

1. Clean gasket mating surfaces. Apply 3/16" bead of silicone sealant to front and rear sealing ridges of cylinder block. Remove carbon from exhaust and EGR ports.
2. Install new manifold gaskets, following instructions included in gasket set. Secure ends with silicone sealant. Cut new side gaskets for installation behind push rods.
3. Install intake manifold. Install and tighten manifold attaching bolts and nuts. (Scheme 25) To complete installation, reverse removal procedure.

Remove negative battery cable. Raise vehicle and separate exhaust pipe from manifold. On left side, remove 4 rear manifold bolts and one nut. Lower vehicle. On both sides, disconnect air diverter valve, hoses and wires. Where necessary, remove power steering pump, air pump and/or alternator, including brackets. Remove right side exhaust heat shield. Remove left side heat stove. Remove manifold bolts and manifold.

To install, clean manifold-to-head mating surfaces and reverse removal procedure.

1. Place transmission gear selector in park (neutral on manual transmissions). Set parking brake and block drive wheels. Although fuel pressure drops to zero when ignition is turned off, loosen fuel filler cap to relieve tank pressure. To further minimize risk of fire and personal injury, cover surrounding areas with a shop rag while removing fuel lines.
2. Remove intake manifold as previously described. Raise vehicle. Disconnect exhaust pipe from manifold. Lower vehicle. Remove oil dipstick and tube assembly. Remove alternator with bracket. Remove ground strap from rear of cylinder head and sensor connector from front of head.
3. Remove rocker arms and push rods in sequence for reinstallation in original locations. Remove power steering pump, air pump and A/C compressor (if equipped), with mounting brackets. Remove cylinder head bolts and separate cylinder head from engine.

Scheme 25

1. Clean gasket mating surfaces, head bolts and cylinder block threads. Position head gaskets and cylinder heads on cylinder block. Apply sealant to head bolt threads and install bolts. Tighten bolts in sequence to 40 ft. lbs. (55 N.m). Using a crayon, mark tops of bolts with a vertical line. Tighten bolts in sequence an additional 90 degrees. (Scheme 25)
2. Coat rocker arm balls and rocker arm mating surfaces with assembly lubricant before installing. To complete installation, reverse removal procedure and adjust valves.

1. Remove rocker arm cover, spark plug, rocker arm and push rod of cylinder to be serviced. Install air hose and adapter to spark plug hole. Apply constant air pressure of 90 psi (6.3 kg/cm 2 ).
2. Using a valve spring compressor, compress valve spring and remove valve retainer locks and oil seal. Release compressor and remove retainer/rotator, oil shield (exhaust only), and valve spring damper. On intake valves, remove Teflon oil seal.

Inspection

Check valve spring tension. Springs (without dampers) should test within 10 lbs. of specification.

1. Position valve spring and damper on cylinder head. Install Teflon oil seal on intake valve and oil shield on exhaust valve. Install retainer/rotator on valve spring.
2. Coat "O" ring type seal and valve stem with engine oil. Compress spring and install seal in lower groove of valve stem. Ensure seal is not twisted in groove. Install retainer locks and release compressor. Ensure retainer locks are properly seated in upper groove of valve stem.

Remove negative battery cable and drive belt. Drain cooling system and remove water pump. Remove A/C compressor and power steering pump and their mounting bracket (if equipped). Remove vibration damper. Disconnect lower radiator hose at front cover. Remove front cover retaining bolts. Remove front cover.

To install, reverse removal procedure using new gaskets. Ensure water pump bolts are coated with sealant. See TORQUE SPECIFICATIONS at end of this article.

Oil seal may be replaced with front cover installed. Remove drive belt. Remove vibration damper bolt. Remove vibration damper. Using large screwdriver, pry seal out of cover. Use care not to damage crankshaft sealing area or front cover.

Lubricate and install new seal with open side of seal toward inside of front cover. Use Seal Installer (J-35468) to drive seal into position. Install vibration damper. Tighten to specification. See TORQUE SPECIFICATIONS at end of this article. Install drive belt.

1. Remove front cover as previously described. Rotate crankshaft so timing marks on camshaft and crankshaft sprockets are aligned. No. 1 piston will be at TDC of exhaust stroke and No. 4 piston will be TDC of compression stroke. (Scheme 26)
2. Remove camshaft sprocket bolts, sprocket and chain. If camshaft sprocket resists removal, use a soft faced hammer and lightly tap lower area of sprocket. Avoid letting camshaft or crankshaft turn.

Install timing chain and camshaft sprocket. Timing marks must be aligned. (Scheme 26) Install remaining components in reverse order of removal.

Scheme 26

Drain cooling system. Remove radiator. Remove fuel pump, front cover and intake manifold as previously described. Remove rocker arm assemblies, push rods and valve lifters in sequence for installation in original locations. Remove timing chain and sprocket. Carefully remove camshaft.

Measure camshaft journal diameter and lobe lift. Replace camshaft and lifters if not within specification.

Lubricate journals with oil and camshaft lobes with assembly lubricant. Carefully install camshaft. If new camshaft is being installed, new lifters should also be used. Lubricate rocker arm ball and valve contact surface. To complete installation, reverse removal procedure.

Removal & Installation

All General Motors vehicles require the engine to be lifted or completely removed from the engine compartment. Remove or disconnect all necessary components for engine removal. Label all hoses and wires for proper reassembly.

Scheme 27

On 2-wheel drive vehicles, remove engine from vehicle. On all vehicles, remove oil pan and oil pump. Remove cylinder heads as previously described. Place piston at lower end of stroke and cover with cloth to collect cuttings. Clean ridge or deposits from cylinder bore. Mark connecting rod and cap for installation in original location and remove. For inspection procedure see ENGINE OVERHAUL PROCEDURES article in this section.

1. Install rings on piston and position ring gaps. Refer to Fig. (Scheme 29). Apply a light coat of engine oil to piston, rings and cylinder bore. Compress piston rings with ring compressor.
2. Cover rod bolts with protective rubber hose. Install piston with notch (or machined hole) in piston head, toward front of engine. Rod bearing tang slot must be positioned away from camshaft. Install rod caps with bearings and tighten to 39 ft. lbs. (53 N.m).

Remove piston compression and oil rings. Using Piston Pin Tool (J-24086), press pin from piston and connecting rod.

Replace piston and pin assembly if not within specification. Use Piston Pin Tool (J-24086) to press piston pin into place.

CONNECTING ROD BEARINGS

1. Use Plastigage method to check rod bearing clearance. Clean crankshaft journal and bearing seat in rod and cap. Insert bearings in rod and cap and coat with engine oil. Pull piston and rod assembly onto crankshaft and install rod cap.
2. After all rods are installed, check side play. Replacement bearings are available in standard, .0005" (.013 mm) and .0010" (.026 mm) undersizes for use with standard size crankshaft.

MAIN BEARINGS

1. Use Plastigage method to check bearings. New bearings are available in standard, .006" (.15 mm) and .012" (.30 mm) undersizes. Always replace upper and lower bearing halves as a set.
2. Remove main bearings from cylinder block by inserting bearing Remover/Installer (J-8080) in crankshaft oil hole and rotating crankshaft clockwise. Bearing will be forced from upper bearing saddle. If remover/installer is unavailable, use a bent cotter pin.
3. Lubricate journal and bearing. Insert plain end of bearing between crankshaft and notched side of block. With bearing remover/installer in crankshaft oil hole, rotate crankshaft counterclockwise to install bearing.
4. Install lower bearing half into cap and lubricate with engine oil. Install and tighten main bearing cap with arrow pointing toward front of engine.

THRUST BEARING ALIGNMENT

1. Install and tighten all main bearing cap bolts, except No. 3, to specification. Tighten No. 3 thrust bearing cap bolts to 11 ft. lbs. (15 N.m).
2. Tap end of crankshaft back and forth to line up main bearing and crankshaft thrust surfaces. Tighten thrust bearing cap. Retighten all main bearing cap bolts to specification, including No. 3 thrust bearing. Rotate crankshaft to conform free movement.

CRANKSHAFT END PLAY

Crankshaft end play after aligning thrust bearing should be .002-.008" (.06-.21 mm).

Remove transmission and flexplate. Insert a screwdriver through seal dust lip at an angle. Carefully pry out seal.

1. Apply a light coat of oil to inside diameter of new seal. Install new seal over mandrel of Seal Installer (J-34686) until dust lip bottoms against collar of tool. Install seal installer to crankshaft and tighten attaching screws by hand. Ensure dowel pin of seal installer is aligned with dowel pin hole in crankshaft. Refer to Fig. (Scheme 28).
2. Apply light coat of oil to outside diameter of seal. Install seal into bore using seal installer. To complete installation, reverse removal procedure.

Scheme 28

Disconnect negative battery cable. Drain cooling system. Remove hoses from water pump. Remove fan shroud, drive belt, fan and pulley. Remove water pump bolts and nut.

Apply 3/32" bead of anaerobic sealer to water pump sealing surface. Coat bolt threads with pipe thread sealer. Install water pump. Tighten water pump bolts and nut to specification. Install remaining components in reverse order of removal.

Note. For further information on cooling systems, see ENGINE COOLING SYSTEMS article in ENGINE section.

FITTING PISTONS

Cylinder bore taper and out-of-round must not exceed specifications. See ENGINE SPECIFICATIONS tables at end of this article. If taper or out-of-round are not within limits, rebore cylinders. Replacement pistons are available in standard, .020" (.50 mm) and .040" (1.0 mm) oversizes. When reboring cylinders, all main bearing caps must be installed and tightened to specification.

FITTING RINGS

Measure ring end gap with a feeler gauge. See PISTONS, PINS, RINGS table for specifications. Check side clearance of compression rings with feeler gauge inserted between ring and ring groove. Install and properly space rings on piston. Oil ring spacer ends must be butted, not overlapped. Note that oil ring spacer anti-rotation tang is inserted into oil hole (or slot) of piston.

Scheme 29

VALVE SPRING INSTALLED HEIGHT

Installed height of valve springs should be 1.6" (40 mm). If measurement exceeds specified height, install a .030" (.76 mm) shim at spring seat.

VALVE GUIDES

If valve stem-to-guide clearance exceeds specification, ream valve guide to proper oversize.

HYDRAULIC VALVE LIFTERS

If lifters are removed, they must be installed in original positions. Some engines may have both standard and.010" (.25 mm) oversize valve lifters. Engines with oversize lifters will be marked with a dab of White paint and "0.25 O.S." stamped on lifter boss. (Scheme 30)

Scheme 30

CRANKCASE CAPACITY

Crankcase capacity is 4.5 qts. (4.3L) with oil filter replacement, 4.0 qts. (3.8L) without filter replacement.

NORMAL OIL PRESSURE

Normal oil pressure is 10 psi (.7 kg/cm 2 ) at 500 RPM and 50-55 psi (3.5-3.9 kg/cm 2 ) at 2000 RPM. Oil pressure should be measured with engine at operating temperature.

OIL PRESSURE REGULATOR VALVE

Oil pressure regulator valve is located in oil pump body. Valve is nonadjustable.

ENGINE OILING SYSTEM

The main oil galleries supply oil to left and right bank hydraulic lifters, camshaft bearings and crankshaft. All other components are lubricated by splash or nozzle method.

With engine removed from vehicle, remove oil pan. Remove bolt attaching oil pump to rear main bearing cap. Remove oil pump with extension shaft.

Disassembly

1. Remove pump cover. Mark gears at a meshing point so same gear teeth indexing will be present when reassembled. Remove idler gear, drive gear and shaft from pump body.
2. Remove pressure regulator valve retaining pin, valve and spring. Remove oil inlet tube from body. Do not remove screen.

Note. If pump gears or body are damaged or worn, pump must be replaced.

Wash all parts and dry with compressed air. Inspect pump body, pump cover and pump gears for damage or excessive wear. Check drive gear shaft for looseness in pump body. Inspect oil inlet tube and screen for damage. Check pressure regulator valve for fit in bore.

Reassembly

1. Install oil inlet tube and screen. Apply sealer to end of tube. Tap tube into place, using plastic hammer. Install pressure regulator valve, spring and retaining pin.
2. Install idler gear, drive gear and shaft into pump body. Ensure gear teeth previously marked are indexing. Prime oil pump and install pump cover.

Assemble pump and extension shaft (with retainer) to rear main bearing cap. Ensure top end of hexagonal extension shaft engages with hexagonal socket of distributor drive gear. Install and tighten oil pump attaching bolt.

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

GENERAL ENGINE SPECIFICATIONS

GENERAL ENGINE SPECIFICATIONS

PISTONS, PINS & RINGS SPECIFICATIONS

PISTONS, PINS & RINGS SPECIFICATIONS

CRANKSHAFT MAIN & CONNECTING ROD BEARINGS SPECS

CRANKSHAFT MAIN & CONNECTING ROD BEARINGS SPECS

CONNECTING ROD SPECIFICATIONS

CONNECTING ROD SPECIFICATIONS

CYLINDER HEAD SPECIFICATIONS

CYLINDER HEAD SPECIFICATIONS

CYLINDER BLOCK SPECIFICATIONS

CYLINDER BLOCK SPECIFICATIONS

VALVES & VALVE SPRINGS SPECIFICATIONS

VALVES & VALVE SPRINGS SPECIFICATIONS

CAMSHAFT SPECIFICATIONS

CAMSHAFT SPECIFICATIONS
