PRE-MEASUREMENT CHECKS
Check tire pressure. Specifications are found on door pillar or in glove box. Place front seats in rearmost position. Cargo compartment must be empty. Fuel tank should be full. Normalize riding height by bouncing vehicle up and down. Measure riding height at locations shown.
Astro/Safari Riding Height Measuring Points. Scheme 2
Scheme 2: Astro/Safari Riding Height Measuring Points
Riding Height Measuring Points ("C", "G", & "P" Series). Scheme 3
Scheme 3: Riding Height Measuring Points ("C", "G", & "P" Series)
Riding Height Measuring Points ("S" Series). Scheme 4
Scheme 4: Riding Height Measuring Points ("S" Series)
SPECIFICATIONS
| Application | Front "A" | Rear "B" |
|---|
| Astro/Safari (1) | 29-30" | 30-31" |
| C10/20 & C30 | 2 1/2-5 3/4" | N/A |
| G10/20/30 | 1 1/2-4 1/2" | N/A |
| K10/20/30 | N/A | N/A |
| P20/30 | 2-4 3/4" | N/A |
| S10/15 (2) | 4 5/8-5" | 6 1/2-7" |
| (1) Measured with approximately 1000 lbs. of cargo or 4-5 passengers. (2) Adjust by turning torsion bar adjustment bolt. |
| (1) | Measured with approximately 1000 lbs. of cargo or 4-5 passengers. |
| (2) | Adjust by turning torsion bar adjustment bolt. |
RIDING HEIGHT SPECIFICATIONS
