COMPONENT LOCATIONS
| Component | Location |
|---|---|
| Convenience Center | Under Left Side of Instrument Panel. (Scheme 22) |
| Fuse Block | Lower Left Side of Instrument Panel. (Scheme 23) |
| Master Window Switch | On Left Front Door Trim Panel. (Scheme 24) |
| Window Motor | Behind Respective Door Trim Panel. (Scheme 24) |
| Window Switch | On Respective Door Trim Panel. (Scheme 24) |
| C240 (Crew Cab, Utility & Suburban) | At Convenience Center. (Scheme 25) |
| C244 (Crew Cab, Utility & Suburban) | At Radio. |
| C247 (2-Door, Extended Cab & Suburban) | At Convenience Center. (Scheme 25) |
| C257 | At Convenience Center. (Scheme 25) |
| C325 (2-Door, Extended Cab & Suburban) | Left Body Hinge Pillar. (Scheme 25) |
| C326 (Crew Cab, Utility & Suburban) | Left Body Hinge Pillar. (Scheme 25) |
| C328 (Crew Cab, Utility & Suburban) | Right Body Hinge Pillar. (Scheme 25) |
| C330 (Crew Cab, Utility & Suburban) | Right Body Hinge Pillar. (Scheme 25) |
| C331 (2-Door & Extended Cab) | Right Body Hinge Pillar. (Scheme 25) |
| C332 (Crew Cab, Utility & Suburban) | Left Body Hinge Pillar. (Scheme 25) |
| C341 (Crew Cab, Utility & Suburban) | At Left Center Pillar. (Scheme 26) |
| C342 (Crew Cab, Utility & Suburban) | At Right Center Pillar. (Scheme 26) |
| G202 | At ALDL Connector. (Scheme 27) |
| S207 | Under Left Side Of Instrument Panel. (Scheme 23) |
| S213 (Crew Cab, Utility & Suburban) | Under Left Side Of Instrument Panel. (Scheme 23) |
| S272 (Crew Cab, Utility & Suburban) | In Power Window & Door Locks Harness, Near Convenience Center Leads. (Scheme 25) |
| S277 (Crew Cab, Utility & Suburban) | In Power Window & Door Locks Harness, Near Convenience Center Leads. (Scheme 25) |
| S279 | In Power Window & Door Locks Harness, Near Convenience Center Leads. (Scheme 25) |
| S500 (Crew Cab, Utility & Suburban) | In Power Window & Locks Harness, Left Front Door, Near Power Window Motor Lead. (Scheme 24) |
| S501 | In Power Window & Locks Harness, Left Front Door, Near Power Window Motor Lead. (Scheme 24) |
