Maintenance Information (C & K Series): Component Locations GMC Pickup C2500

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE PANEL LOCATION

The fuse block is located behind a cover in the dash to the left of the steering column.

Scheme 11

Fuse & Circuit Breaker Identification

1. 1 - Gauges 20 Amp Cruise Control, Rear Window Defogger Timer, 4-Wheel Drive Display Illumination, Auxiliary Battery Relay, Seat Belt Reminder, Cluster Ignition Feed
2. 2 - Turn-B/U 15 Amp Back-Up Lights, Turn Signals
3. 3 - EMC/Ign 10 Amp Torque Converter Clutch, Air Injection Reactor Diverter, Electronic Spark Control, EGR, Electronic Control Module, Anti-Lock Switch
4. 4 - Inj A 10 Amp Throttle Body Injectors
5. 5 - Brake 15 Amp Anti-Lock Brakes, Cluster Speedometer
6. 6 - A/C Htr 25 Amp HVAC, 4-Wheel Drive, Auxiliary Battery
7. 7 - Ctsy 20 Amp Courtesy Lights, Glove Box Light, Radio
8. 8 - Park Lt 20 Amp Horn Relay, Horn Feed, Cigarette Lighter, Parking Lights
9. 9 - P Lps 5 Amp 20 Amp ("C" & "K" Series) C49 Switch Illumination, Headlight ON Warning, Radio Illumination, Heater & A/C Illumination, Rear Window Defogger
10. 10 - Stop/Haz 15 Amp Hazard Flasher, Seat Belt Reminder, Stoplights, Rear Anti-lock Memory
11. 11 - Wiper 25 Amp Windshield Washer/Wiper
12. 12 - Radio 10 Amp Radio Feed
13. 13 - Acc/Ign 30 Amp (Circuit Breaker) Power Windows
14. 14 - Acc/Batt 30 Amp (Circuit Breaker) Door Locks, Rear Window Defogger
15. 15 - Crank 5 Amp Discreet Crank
16. 16 - 4WD 25 Amp 4WD 15 Amp ("C" & "K" Series) Speedometer
17. 17 - 15 Amp DRL (Canada)
