# Instrument illumination circuit

# Instrument illumination circuit

Interior lights — Instrument illumination circuit — Instrument illumination circuit. GMC Pickup C1500 (1985-1999)
Components on the diagram

    # Instrument illumination circuit (1 of 2)

    Interior lights — Instrument illumination circuit — Instrument illumination circuit (1 of 2). GMC Pickup C1500 (1985-1999)
    Components on the diagram

      # Instrument illumination circuit (2 of 2)

      Interior lights — Instrument illumination circuit — Instrument illumination circuit (2 of 2). GMC Pickup C1500 (1985-1999)
      Components on the diagram
