Maintenance Information (except Typhoon) GMC Jimmy Typhoon

Procedures 7 illustrations ~1454 words

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

SERVICE PARTS IDENTIFICATION LABEL

Label is located inside glove box door and has the vehicle's VIN, wheelbase, paint information, and a list of all production options and special equipment.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 21

Scheme 21: VIN Code ID Explanation
Scheme 21: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Note. Use the Severe Service schedule if the vehicle to be serviced is operated under ANY (one or more) of these conditions

Service is recommended at mileage intervals based on vehicle operation and time in service. Manufacturer's Schedules identify items to be serviced based on type of operation. Service schedules are based on the following primary operating conditions

Severe Service

  1. Short Trips (4 Miles Or Less)
  2. Freezing Temperatures
  3. Towing Or Heavily Loaded
  4. Severe Dust Conditions
  5. Hot Weather, Stop-And-Go Driving
  6. Extensive Idling Conditions (Taxi Or Delivery Type Service)

Normal Service

  1. No Severe Service Operating Conditions

Scheme 22

Scheme 22: SERVICE POINT LOCATIONS
Scheme 22: SERVICE POINT LOCATIONS

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Note. For more information regarding jacking or hoisting the vehicle, refer to the JACKING & HOISTING article in the WHEEL ALIGNMENT section.

SERVICE LABOR TIMES

Note. Labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

WHEEL & TIRE SPECIFICATIONS

Wheel and tire information can be found on the Certification/Tire label attached to rear of driver's door or door pillar.

Note. DO NOT use chains with P235/75R15 size tires. Vehicle damage may result.

WHEEL SIZE

Replacement wheels should match originals in load limit, diameter, width, offset, and mounting configuration. The wrong wheel can cause difficulty with bearing life, brake cooling, speedometer/odometer calibration, stopping ability, headlight aim, bumper height, vehicle ground clearance and tire or tire chain clearance to body and chassis.

WHEEL TIGHTENING

Tighten lug nuts on 1991-92 models with steel wheels to 80 ft. lbs. (108 N.m). Tighten lug nuts on models with aluminum wheels to 90 ft. lbs. (122 N.m). 1993-94 models should be tightened to 95-100 ft. lbs. (130-140 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM

Note. See the AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT Section.

The SRS has no user-servicable parts. Always have servicing done by an authorized dealer.

When performing maintenance on air bag equipped vehicles always observe proper safety precautions.

WARNINGTo avoid injury from accidental air bag deployment, read and carefully follow all warnings and service precautions. See appropriate AIR BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT section.
CAUTIONDisconnect negative battery cable before servicing any air bag system, steering column or passenger side dash component. After any repair, turn ignition key to the ON position from passenger's side of vehicle in case of accidental air bag inflation

ANTI-LOCK BRAKE SYSTEM (ABS)

CAUTIONNever mix different diameter tires. On loose or uneven surfaces, the ABS system may require longer stopping distances than conventional brake systems. Exercise caution when removing mud or snow from the wheels so as not to damage the ABS wiring or speed sensors.

BATTERY WARNING

WARNINGWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See appropriate COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section below.

REPLACING BLOWN FUSES

CAUTIONBefore replacing a blown fuse, remove ignition key, turn off all lights and accessories to avoid damaging the electrical system. Be sure to use fuse with the correct indicated amperage rating. The use of an incorrect amperage rating fuse may result in a dangerous electrical system overload.

BRAKE PAD WEAR INDICATOR

CAUTIONIndicator will cause a squealing or scraping noise, warning that brake pads need replacement.

CATALYTIC CONVERTER

CAUTIONContinued operation of vehicle with a severe malfunction could cause converter to overheat, resulting in possible damage to converter and vehicle.

COOLANT (PROPYLENE-GLYCOL FORMULATIONS)

CAUTIONTo avoid possible damage to vehicle use only ethylene-glycol based coolants with a mixture ratio from 44-68% anti-freeze. DO NOT use 100% anti-freeze as it will cause the formation of cooling system deposits. This results in coolant temperatures of over 300° F (149°C) which can melt plastics. 100% anti-freeze has a freeze point of only -8° F (-22°C).
CAUTIONPropylene-Glycol Mixtures has a smaller temperature range than Ethylene-Glycol. The temperature range (freeze-boil) of a 50/50 Anti-Freeze/Water Mix is as follows: Propylene-Glycol -26° F (-32°C) - 257° F (125°C) Ethylene-Glycol -35° F (-37°C) - 263° F (128°C)
CAUTIONPropylene-Glycol/Ethylene-Glycol Mixtures can cause the destabilization of various corrosion inhibitors. Also Propylene-Glycol/Ethylene-Glycol has a different specific gravity than Ethylene-Glycol coolant, which will result in inaccurate freeze point calculations.

ELECTROSTATIC DISCHARGE SENSITIVE (ESD) PARTS

WARNINGMany solid state electrical components can be damaged by static electricity (ESD). Some will display a warning label, but many will not. Discharge personal static electricity by touching a metal ground point on the vehicle prior to servicing any ESD sensitive component.

ENGINE OIL

CAUTIONNever use non-detergent or straight mineral oil.

FUEL SYSTEM SERVICE

WARNINGRelieve fuel system pressure prior to servicing any fuel system component (fuel injection models).

HALOGEN BULBS

WARNINGHalogen bulbs contain pressurized gas which may explode if overheated. DO NOT touch glass portion of bulb with bare hands. Eye protection should be worn when handling or working around halogen bulbs.

RADIATOR CAP

CAUTIONAlways disconnect the fan motor when working near the radiator fan. The fan is temperature controlled and could start at any time even when the ignition key is in the OFF position. DO NOT loosen or remove radiator cap when cooling system is hot.

RADIATOR FAN

WARNINGKeep hands away from radiator fan. Fan is controlled by a thermostatic switch which may come on or run for up to 15 minutes even after engine is turned off.

WARRANTY INFORMATION

CAUTIONDue to the different warranties offered in various regions and the variety of after-market extended warranties available, please refer to the warranty package that came with the vehicle to verify all warranty options.

BUMPER-TO-BUMPER PLUS COVERAGE LIMITED WARRANTY

Entire vehicle (except battery) is covered for 3 years or 50,000 miles, whichever occurs first. Covered by this warranty are any repairs to vehicle components which have proven defective in material and workmanship under normal use (tires excluded). Warranty repairs (parts and labor) will be made by the Dealer at no charge using new or remanufactured parts. This warranty is subject to a 100 deductible for each repair visit after the first year or 12,000 miles, whichever occurs first.

Note. 1992-93 Models are covered for 3 years or 36,000 miles, whichever occurs first, with no deductible.

BATTERY COVERAGE

Covers replacement cost of battery for 3 years or 50,000 miles (36,000 miles on 1992 models), whichever occurs first. A prorated charge applies after first 12 months or 12,000 miles, whichever occurs first.

CORROSION COVERAGE

Covers any body sheet metal panel that is perforated due to corrosion. Coverage is for 6 years or 100,000 miles, whichever occurs first.

EMISSIONS "DEFECT" & "PERFORMANCE" WARRANTIES (FEDERAL)

Defect Warranty ensures vehicle meets applicable EPA regulations and that emission control system is free from defects in materials and workmanship. Coverage is for a period of 5 years or 50,000 miles, whichever occurs first.

Performance Warranty covers all costs of repairing or adjusting any components or parts as needed in order for the vehicle to pass a federally-required state or local emissions test. Other emission control parts related to these components are covered by the Performance Warranty, where applicable. If another part fails due to the failure of one of these components, both parts are covered. See customer's copy of warranty information for specific items covered.

EMISSION "PERFORMANCE" WARRANTY (CALIFORNIA)

If vehicle fails a Smog Check inspection, all necessary repairs and adjustments will be made by manufacturer to ensure vehicle passes inspection. Coverage is for 3 years or 50,000 miles, whichever occurs first.

EMISSION "DEFECT" WARRANTY (CALIFORNIA)

If any emission-related part on the vehicle is defective, the part will be repaired or replaced by manufacturer. Coverage is for 3 years or 50,000 miles, whichever occurs first.

Some emission-related parts are covered for 7 years or 70,000 miles, whichever occurs first, and will be repaired or replaced by manufacturer if found to be defective in material or workmanship. See customer's copy of warranty information for specific items covered.

FUSE PANEL LOCATIONS

The fuse block is located under the instrument panel to the left of the steering column.

Scheme 27

Scheme 27: FUSE PANEL IDENTIFICATION (1991-92)
Scheme 27: FUSE PANEL IDENTIFICATION (1991-92)

Fuse & Circuit Breaker Identification

  1. 1 - Inst-Lps 5 Amp Instrument Panel Lights, Headlight Warning Buzzer, Rear Defogger Switch Light, Ashtray Light, 4WD Indicator Light, Rear Wiper Switch Light, Foglight Switch Light
  2. 2 - Pwr-Accy 30 Amp (Circuit Breaker) Power Door Locks & Rear Defogger, Console Accy. Receptacles (Bravada), CD Player (If Equipped), Power Seat (If Equipped), Elec. Shift Transfer Case (If Equipped)
  3. 3 - Horn-Dim 20 Amp Horn, Clock & Lighter, Dome & Glove Box Lights, Courtesy & Vanity Mirror Lights, Liftgate Release Solenoid, Compass (Bravada), Fog Lights (1991-92), Power Mirrors
  4. 4 - Ign-Gau 20 Amp Indicator Lights & Gauges, Rear Defogger Relay & Timer, A/T Converter Clutch & Cruise Control, RWAL Brake Signal, Seat Belt Timer, A/C Compressor Timer (If Equipped), 4WD Indicator Light (If Equipped)
  5. 5 - Brake 15 Amp Rear/Four Wheel Anti-Lock, Brake Module, Digital Radio Adapter Module, Speedometer, Auto. Trans. Converter Clutch
  6. 6 - Stop-Haz 15 Amp Stoplights & Hazard Warning Lights, Chime Module (1991-92)
  7. 7 - T/L-Ctsy 20 Amp Light Switch, Taillights & Parking Lights, Courtesy Lights, Electronic Cluster (If Equipped)
  8. 8 - Turn-B/U 15 Amp Turn Signal & Back-Up Lights
  9. 9 - Htr-A/C 25 Amp Heating & A/C
  10. 10 - Radio 15 Amp Radio, Tachometer, Rearview Mirror Map Lights, Rear Wiper & Washer
  11. 11 - ECM B 10 Amp Electronic Control Module, Fuel Pump
  12. 12 - ECM I 10 Amp Electronic Control Module
  13. 13 - Pwr Wdo 30 Amp (Circuit Breaker) Power Windows
  14. 14 - Wiper 25 Amp Windshield Wipers & Washers
  15. 15 - Crank 3 Amp Electronic Control Module
  16. 16 - TCCM 5 Amp (1992) Elec. Shift Transfer Case Module
  17. 17 - DRL 10 Amp (1991-92) Daytime Running Lights (Canada)

In-Line Fuse Identification

  1. Trailer 30 Amp Trailer Wiring Harness (If Equipped with Tow Package)
  2. CD Player (1992) 10 Amp CD Player (If Equipped)
  3. AUX PWR OUTLET 10 Amp Auxiliary Power (If Equipped)
  1. 1 - Inst-Lps 5 Amp Instrument Panel Lights, Headlight Warning Buzzer, Ashtray Light, 4WD Indicator Light, Foglight Switch Light
  2. 2 - Pwr-Accy 30 Amp (Circuit Breaker) Power Door Locks, Console Accessory Receptacles, CD Player (If Equipped), Power Seat (If Equipped), Elec. Shift Transfer Case (If Equipped)
  3. 3 - Horn-Dim 20 Amp Horn, Clock & Lighter, Dome & Glove Box Lights, Courtesy & Vanity Mirror Lights, Fog Lights, Power Mirrors
  4. 4 - Ign-Gau 20 Amp Ignition (1985-87), Indicator Lights & Gauges, A/T Converter Clutch & Cruise Control, RWAL Brake Signal (If Equipped), Seat Belt Timer, A/C Compressor Timer (If Equipped), 4WD Indicator Light (If Equipped)
  5. 5 - Brake 15 Amp Rear/Four Wheel Anti-Lock Brake Module, Speedometer, Digital Radio Adapter Module, Auto. Trans. Converter Clutch
  6. 6 - Stop-Haz 15 Amp Stoplights & Hazard Warning Lights, Chime Module
  7. 7 - T/L-Ctsy 20 Amp Light Switch, Taillights & Parking Lights, Courtesy Lights, Electronic Cluster (If Equipped)
  8. 8 - Turn-B/U 15 Amp Turn Signal & Back-Up Lights
  9. 9 - Htr-A/C 25 Amp Heating & A/C
  10. 10 - Radio 15 Amp Radio, Tachometer, Rearview Mirror Map Lights, Compass
  11. 11 - ECM B 15 Amp Electronic Control Module, Fuel Pump
  12. 12 - ECM I 10 Amp Electronic Control Module
  13. 13 - Pwr Wdo 30 Amp (Circuit Breaker) Power Windows
  14. 14 - Wiper 25 Amp Windshield Wipers & Washers
  15. 15 - Crank 3 Amp Electronic Control Module
  16. 16 - TCCM 5 Amp Elec. Shift Transfer Case Module
  17. 17 - DRL 10 Amp Daytime Running Lights (Canada)
  18. 18 - CD PLAYER 10 Amp CD Player
  19. 19 - AUX PWR OUTLET 10 Amp Auxiliary Power

In-Line Fuse Identification

  1. Trailer 30 Amp Trailer Wiring Harness (If Equipped with Tow Package)
