Wiring diagram: Computer data lines 6.5l — 6.5l (vin y), data link connector circuit GMC Forward Control P3500
All systems — 40 systems
- Air conditioning 2
- Air conditioning 4.3l 4
- Air conditioning 5.7l 4
- Air conditioning 6.5l 8
- Air conditioning 7.4l 6
- Anti-lock brakes 2
- Computer data lines 2
- Computer data lines 4.3l 4
- Computer data lines 5.7l 4
- Computer data lines 6.5l 4
- Computer data lines 7.4l 4
- Cooling fan
- Cooling fan 6.5l 2
- Cooling fan 7.4l 2
- Cruise control 2
- Cruise control 4.3l
- Cruise control 5.7l
- Cruise control 6.5l 3
- Cruise control 7.4l 3
- Engine performance 4.3l 7
- Engine performance 5.7l 11
- Engine performance 6.5l 12
- Engine performance 7.4l 11
- Exterior lights 11
- Ground distribution 4
- Headlights 18
- Horn 5
- Instrument cluster 4
- Interior lights 4
- Power distribution 8
- Power door locks
- Power windows 2
- Shift interlocks 5
- Starting/charging 11
- Transmission 4.3l 5
- Transmission 5.7l 5
- Transmission 6.5l 8
- Transmission 7.4l 5
- Warning systems 4
- Wiper/washer 7
Computer data lines 6.5l
# 6.5l (vin y), data link connector circuit
