Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Air Inlet Panel Grille Nuts | 4 N.m | 35 lb in |
| Front Wiper Arm Nuts | 30 N.m | 22 lb ft |
| Front Wiper Motor Cover Screws | 3 N.m | 27 lb in |
| Rear Wiper Arm Nut | 20 N.m | 15 lb ft |
| Rear Wiper Arm Park Ramp Bolts | 9 N.m | 79 lb in |
| Rear Wiper Motor Bolts | 8 N.m | 71 lb in |
| Rear Wiper Motor Shaft Nut | 8 N.m | 71 lb in |
| Washer Solvent Container Assembly Nuts | 10 N.m | 89 lb in |
| Wiper Transmission Assembly Bolts | 8 N.m | 71 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Wiper/Washer System Schematics
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 6: Wiper/Washer System Component Views
| Callout | Component Name |
|---|
| 1 | Windshield Washer Fluid Level Switch |
| 2 | Headlamp Washer Fluid Pump |
| 3 | Windshield Washer Fluid Pump |
| 4 | Rear Window Washer Fluid Pump |
| 5 | Air Cleaner Housing |
Scheme 7
| Callout | Component Name |
|---|
| 1 | Instrument Panel Harness |
| 2 | Windshield Wiper Motor |
Scheme 8
| Callout | Component Name |
|---|
| 1 | Headliner Harness |
| 2 | Inside Rearview Mirror |
| 3 | Outside Moisture Sensor |
Scheme 9
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper/Washer Switch (CD6) |
| 2 | Transfer Case Shift Control Switch (NP8)/Traction Control Switch (NW7) |
| 3 | Instrument Panel Harness |
| 4 | Auxiliary Power Outlet - Front |
| 5 | Cigar Lighter |
Scheme 10
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper/Washer Switch (CD6) |
| 2 | Auxiliary Power Outlet - Front |
| 3 | Cigar Lighter |
| 4 | Auxiliary Power Outlet - Front |
| 5 | Transfer Case Shift Control Switch (NP8)/Traction Control Switch (NW7) |
| 6 | Instrument Panel Harness |
Scheme 11
| Callout | Component Name |
|---|
| 1 | Windshield Wiper/Washer Switch |
| 2 | C201 |
Scheme 12
| Callout | Component Name |
|---|
| 1 | Cigar Lighter |
| 2 | Rear Window Wiper/Washer Switch (CD6) |
| 3 | Instrument Panel Harness |
| 4 | Auxiliary Power Outlet - Front |
Scheme 13
| Callout | Component Name |
|---|
| 1 | Rear Window Defogger Grid C2 |
| 2 | C905 |
| 3 | C902 |
| 4 | C900 |
| 5 | C904 |
| 6 | Rear Window Defogger Grid C1 |
| 7 | S901 |
| 8 | Liftgate Ajar Switch |
| 9 | Liftgate Harness |
| 10 | Liftgate Module (LGM) |
| 11 | C901 |
| 12 | License Lamp Harness |
| 13 | Liftgate Latch Assembly |
| 14 | Cargo Lamp |
| 15 | Rear Window Wiper Motor |
Scheme 14
| Callout | Component Name |
|---|
| 1 | Endgate Actuator - Upper Right |
| 2 | Endgate Key Cylinder |
| 3 | Rear Window Wiper Motor |
| 4 | Endgate Module (EGM) |
| 5 | Endgate Drop Handle Switch |
| 6 | S902 |
| 7 | S909 |
| 8 | License Lamp Harness |
| 9 | C901 |
| 10 | Endgate Actuator - Upper Left |
| 11 | Endgate Swing Handle Switch |
| 12 | S914 |
| 13 | Endgate Latch Relay |
| 14 | S904 |
| 15 | Endgate Actuator - Lower Left |
| 16 | Rear Window Defogger Grid Connector C1 |
| 17 | S915 |
| 18 | License Lamp - Left |
| 19 | S912 |
| 20 | S913 |
| 21 | S911 |
| 22 | S910 |
| 23 | Endgate Window Regulator |
| 24 | Rear Window Defogger Grid Connector C2 |
| 25 | S905 |
| 26 | Endgate Harness |
| 27 | C900 |
