Special Tools Ordering Information
The special service tools shown in this service manual that have product numbers beginning with J, SA or BT are available for worldwide distribution from
OE Tool and Equipment Group
Kent-Moore
28635 Mound Road
Warren
MI, U.S.A.
48092-3499
Phone: 1-800-345-2233 or 586-574-2332
Monday through Friday
8:00 am-7:00 pm Eastern Standard Time
Fax: 1-800-578-7375 or 586-578-7321
The TECH 2 scan tool and accessories can be purchased through
Dealer Equipment and Services
5775 Enterprise Dr.
Warren
MI, U.S.A.
48092-3463
Phone: 1-800-GM-TOOLS or 586-574-2332
Monday through Friday
8:00 am-6:00 pm EST
Fax: 1-586-578-7205
Engine ID & VIN Derivative Location - 4.2L
Refer to Engine Identification in Engine Mechanical - 4.2L.
Engine ID & VIN Derivative Location - 5.3L
Refer to Engine Identification in Engine Mechanical - 5.3L.
4L60-E/4T65-E Transmission ID & VIN Derivative Location
Refer to Transmission Identification Information in Automatic Transmission - 4L60-E/4T65-E.
Scheme 2
| Callout | Description |
|---|---|
| Vehicle Certification Label The vehicle certification label is located on the driver door and displays the following assessments: Gross Vehicle Weight Rating (GVWR) Gross Axle Weight Rating (GAWR), front and rear The gross vehicle weight (GVW) is the weight of the vehicle and everything it carries. The GVW must not exceed the GVWR. Include the following items when figuring the GVW: The base vehicle weight (factory weight) The weight of all vehicle accessories The weight of the driver and the passengers The weight of the cargo | |
| 1 | Name of Manufacturer |
| 2 | Gross Vehicle Weight Rating |
| 3 | Gross Axle Weight Rating (Front, Rear) |
| 4 | Canadian Safety Mark (w/RPO Z49) |
| 5 | Certification Statement |
| 6 | Vehicle Class Type (Pass Car, etc.) |
| 7 | Vehicle Identification Number |
| 8 | Date of Manufacture (Mo/Yr) |
| Tire Placard The tire placard label is located on the driver door and displays the following assessments | |
| 9 | Specified Occupant Seating Positions |
| 10 | Maximum Vehicle Capacity Weight |
| 11 | Original Equipment Tire Size |
| 12 | Tire Pressure, Front, Rear, and Spare (Cold) |
| Service Parts ID Label The vehicle service parts identification label is located in the instrument panel (I/P) compartment. The label is use to help identify the vehicle original parts and options. | |
| 13 | Vehicle Identification Number |
| 14 | Engineering Model Number (Vehicle Division, Line and Body Style) |
| 15 | Interior Trim Level and Decor |
| 16 | Exterior (Paint Color) WA Number |
| 17 | Paint Technology |
| 18 | Special Order Paint Colors and Numbers |
| 19 | Vehicle Option Content |
| Anti-Theft Label | |
| 20 | The Federal law requires that General Motors label certain body parts on this vehicle with the VIN. The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and recovery of parts from stolen vehicles. Labels are permanently affixed to an interior surface of the part. The label on the replacement part contains the letter R, the manufacturer's logo, and the DOT symbol. The anti-theft label must be covered before any painting, and rustproofing procedures, and uncovered after the procedures. Failure to follow the precautionary steps may result in liability for violation of the Federal Vehicle Theft Prevention Standard and possible suspicion to the owner that the part was stolen. |
Label - Vehicle Certification, Tire Place Card, Anti-Theft & Service Parts ID
Special Tools
Special Tools Illustration Tool Number/ Description J 41340 Ignition Lock Cylinder Staking and Holding Fixture
