Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Air Spring Compressor to Frame Mounting Bolts | 20 N.m | 15 lb ft |
| Air Spring Leveling Sensor to Frame Mounting Bolts | 8 N.m | 71 lb in |
| Air Supply Lines to Air Spring Compressor | 2.25 N.m | 20 lb in |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Suspension Controls Schematics
Scheme 2
Scheme 2: Suspension Controls Component Views
| Callout | Component Name |
|---|
| 1 | Air Suspension Sensor - LR |
| 2 | Air Suspension Sensor - RR |
| 3 | Air Suspension Compressor Assembly |
| 4 | Air Suspension Inflator Switch |
| 5 | Frame |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Air Suspension Compressor Assembly |
| 2 | Air Suspension Inflator Switch |
| 3 | Air Suspension Sensor - LR |
| 4 | Air Suspension Sensor - RR |
| 5 | Frame |
