Power and Grounding Schematic Icons
Power and Grounding Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs
Scheme 134
Scheme 134: Power Distribution Schematics
Scheme 135
Scheme 136
Scheme 137
Scheme 138
Scheme 139
Scheme 140
Scheme 141
Scheme 142
Scheme 143
Scheme 144
Scheme 145
Scheme 146
Scheme 147
Scheme 148
Scheme 149
Scheme 150
Scheme 151
Scheme 152
Scheme 153
Scheme 153: Ground Distribution Schematics
Scheme 154
Scheme 155
Scheme 156
Scheme 157
Scheme 158
Scheme 159
Scheme 160
Scheme 161
Scheme 162
Scheme 163
Scheme 164
Scheme 165
Scheme 165: Harness Routing Views
| Callout | Component Name |
|---|
| 1 | C105 |
| 2 | Fuse Block - Underhood C4 |
| 3 | Park/Turn Signal Lamp - LF |
| 4 | C102 |
| 5 | Horn Assembly |
| 6 | C118 |
| 7 | Windshield Washer Fluid Level Switch (U68) |
| 8 | Headlamp Washer Fluid Pump (CE4) |
| 9 | Windshield Washer Fluid Pump |
| 10 | A/C Low Pressure Switch |
| 11 | S104 (W49) |
| 12 | S103 |
| 13 | G103 |
| 14 | Park/Turn Signal Lamp - RF |
| 15 | Marker Lamp - RF |
| 16 | Cornering Lamp - Right |
| 17 | Fog Lamp - RF |
| 18 | C103 |
| 19 | Rear Window Washer Fluid Pump (CD6) |
| 20 | S113 |
| 21 | Ambient Air Temperature Sensor (CJ3) |
| 22 | S107 |
| 23 | Fog Lamp - LF |
| 24 | S106 (W49) |
| 25 | Cornering Lamp - Left |
| 26 | Marker Lamp - LF |
Scheme 166
| Callout | Component Name |
|---|
| 1 | Cooling Fan |
| 2 | C118 |
Scheme 167
| Callout | Component Name |
|---|
| 1 | Engine Coolant Temperature (ECT) Sensor |
| 2 | Evaporative Emission (EVAP) Canister Purge Solenoid |
| 3 | Powertrain Control Module (PCM) C3 |
| 4 | Throttle Body |
| 5 | Manifold Absolute Pressure (MAP) Sensor |
| 6 | Powertrain Control Module (PCM) C2 |
| 7 | C100 |
| 8 | Starter |
| 9 | Fuse Block - Underhood C1 |
| 10 | S110 |
| 11 | Knock Sensor (KS) 2 - Rear |
| 12 | Crankshaft Position (CKP) Sensor |
| 13 | G109 |
| 14 | G101 |
| 15 | G110 |
| 16 | A/C Compressor Clutch Assembly |
| 17 | A/C Refrigerant Pressure Sensor |
| 18 | Knock Sensor (KS) 1 - Front |
| 19 | G107 |
| 20 | Generator |
Scheme 168
| Callout | Component Name |
|---|
| 1 | Park/Neutral Position (PNP) Switch |
| 2 | Heated Oxygen Sensor (HO2S) 2 |
| 3 | C104 |
| 4 | Ignition Coil 5 |
| 5 | Ignition Coil 4 |
| 6 | Ignition Coil 3 |
| 7 | Ignition Coil 2 |
| 8 | Ignition Coil 1 |
| 9 | Camshaft Actuator Solenoid Assembly |
| 10 | Camshaft Position (CMP) Sensor |
| 11 | Engine Oil Pressure (EOP) Switch |
| 12 | Heated Oxygen Sensor (HO2S) 1 |
| 13 | Secondary Air Injection (AIR) Solenoid (K18) |
| 14 | Intake Air temperature (IAT) Sensor |
| 15 | Ignition Coil 6 |
| 16 | C175 |
| 17 | Vehicle Speed Sensor (2WD)/C310 (4WD) |
Scheme 169
| Callout | Component Name |
|---|
| 1 | C104 |
| 2 | Fuel Injector 6 |
| 3 | Fuel Injector 5 |
| 4 | Fuel Injector 4 |
| 5 | Fuel Injector 3 |
| 6 | Fuel Injector 2 |
| 7 | Fuel Injector 1 |
Scheme 170
| Callout | Component Name |
|---|
| 1 | Generator |
| 2 | S112 (DoD) |
| 3 | Evaporative Emission (EVAP) Canister Purge Solenoid |
| 4 | C109 |
| 5 | Fuel Injector 3 |
| 6 | Fuel Injector 5 |
| 7 | Fuel Injector 7 |
| 8 | Engine Oil Pressure (EOP) Sensor |
| 9 | Valve Lifter Oil Manifold (VLOM) Assembly (DoD) |
| 10 | Heated Oxygen Sensor (HO2S) Bank 2 Sensor 2 |
| 11 | Heated Oxygen Sensor (HO2S) Bank 1 Sensor 1 |
| 12 | Vehicle Speed Sensor (VSS) (2WD)/C310 (4WD) |
| 13 | Heated Oxygen Sensor (HO2S) Bank 1 Sensor 2 |
| 14 | Park/Neutral Position (PNP) Switch |
| 15 | G109 |
| 16 | Knock Sensor (KS) 1 - Left |
| 17 | G107 |
| 18 | C107 |
| 19 | G108 |
| 20 | Engine Coolant Temperature (ECT) Sensor |
| 21 | Engine Control Module (ECM) C1 |
| 22 | Engine Control Module (ECM) C2 |
| 23 | Engine Control Module (ECM) C3 |
| 24 | Fuse Block - Underhood C1 |
| 25 | S100 |
| 26 | Brake Booster Vacuum Sensor (DoD) |
| 27 | Fuel Injector 1 |
Scheme 171
| Callout | Component Name |
|---|
| 1 | Heated Oxygen Sensor (HO2S) Bank 2 Sensor 1 |
| 2 | Fuel Injector 8 |
| 3 | C108 |
| 4 | Fuel Injector 6 |
| 5 | S102 |
| 6 | Fuel Injector 4 |
| 7 | Fuel Injector 2 |
| 8 | Manifold Absolute Pressure (MAP) Sensor |
| 9 | S105 |
| 10 | S101 |
| 11 | Transmission Control Module (TCM) |
| 12 | Throttle Body |
| 13 | C110 |
| 14 | A/C Compressor Clutch Assembly |
| 15 | A/C Refrigerant Pressure Sensor |
| 16 | Knock Sensor (KS) 2 - Right |
| 17 | Starter |
| 18 | Crankshaft Position (CKP) Sensor |
| 19 | Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor |
| 20 | C175 |
Scheme 172
| Callout | Component Name |
|---|
| 1 | Camshaft Position (CMP) Sensor |
| 2 | C110 |
Scheme 173
| Callout | Component Name |
|---|
| 1 | Ignition Coil 1 |
| 2 | Ignition Coil 3 |
| 3 | C109 |
| 4 | Ignition Coil 2 |
| 5 | Ignition Coil 5 |
| 6 | Ignition Coil 4 |
| 7 | C108 |
| 8 | Ignition Coil 6 |
| 9 | Ignition Coil 7 |
| 10 | Ignition Coil 8 |
Scheme 174
| Callout | Component Name |
|---|
| 1 | Electronic Frontal Sensor (EFS) - Right |
| 2 | Front Axle Actuator (NP8) |
| 3 | Wheel Speed Sensor - RF |
| 4 | Electronic Brake Control Module (EBCM) C1 |
| 5 | Electronic Brake Control Module (EBCM) C2 |
| 6 | Secondary Air Injection (AIR) Pump (4.2L w/K18) |
| 7 | C310 (4WD) |
| 8 | Vehicle Speed Sensor (VSS) (4WD) |
| 9 | S306 |
| 10 | Fuel Pump and Sender Assembly |
| 11 | Evaporative Emission (EVAP) Canister Vent Solenoid |
| 12 | Air Suspension Sensor - RR (G67) |
| 13 | Air Suspension Compressor Assembly C1 (G67) |
| 14 | Backup Lamp - Right (Z88) |
| 15 | Backup Lamp - Left (Z88) |
| 16 | S408 (Z88) |
| 17 | G403 |
| 18 | Air Suspension Sensor - LR (G67) |
| 19 | Fuel Tank Pressure (FTP) Sensor |
| 20 | S359 (5.3L) |
| 21 | G305 |
| 22 | Propshaft Speed Sensor - Rear |
| 23 | Transfer Case Encoder Motor (4WD) |
| 24 | Propshaft Speed Sensor - Front |
| 25 | Secondary Air Injection (AIR) Pump Relay (4.2L w/K18) |
| 26 | G304 |
| 27 | Wheel Speed Sensor - LF |
| 28 | C101 |
| 29 | Fuse Block - Underhood C3 |
| 30 | Fuse Block - Underhood C7 |
| 31 | Electronic Frontal Sensor (EFS) - Left |
Scheme 175
| Callout | Component Name |
|---|
| 1 | Electronic Frontal Sensor (EFS) - Right |
| 2 | Front Axle Actuator (NP8) |
| 3 | Wheel Speed Sensor - RF |
| 4 | C310 (4WD) |
| 5 | Propshaft Speed Sensor - Front |
| 6 | Propshaft Speed Sensor - Rear |
| 7 | Vehicle Speed Sensor (VSS) (4WD) |
| 8 | Fuel Pump and Sender Assembly |
| 9 | Air Suspension Sensor - RR (G67) |
| 10 | S408 (Z88) |
| 11 | Backup Lamp - Right (Z88) |
| 12 | Backup Lamp - Left (Z88) |
| 13 | Trailer Connector |
| 14 | Air Suspension Compressor Assembly C1 (G67) |
| 15 | G403 |
| 16 | Air Suspension Sensor - LR (G67) |
| 17 | Fuel Tank Pressure (FTP) Sensor |
| 18 | S306 |
| 19 | S359 (5.3L) |
| 20 | G305 |
| 21 | Transfer Case Encoder Motor (4WD) |
| 22 | Electronic Brake Control Module (EBCM) C2 |
| 23 | Electronic Brake Control Module (EBCM) C1 |
| 24 | G304 |
| 25 | Wheel Speed Sensor - LF |
| 26 | Brake Fluid Level Switch |
| 27 | C101 |
| 28 | Fuse Block - Underhood C3 |
| 29 | Fuse Block - Underhood C7 |
| 30 | Electronic Frontal Sensor (EFS) - Left |
Scheme 176
| Callout | Component Name |
|---|
| 1 | C101 |
| 2 | G104 |
| 3 | G105 |
| 4 | G102 |
| 5 | C107 (5.3L) |
| 6 | C105 |
| 7 | Fuse Block - Underhood C2 |
| 8 | S117 |
| 9 | C100 |
| 10 | Powertrain Control Module (PCM) C1 (4.2L) |
Scheme 177
| Callout | Component Name |
|---|
| 1 | Speaker - RF I/P (UQA) |
| 2 | Recirculation Actuator |
| 3 | S216 |
| 4 | Radio C2 |
| 5 | Radio C1 |
| 6 | Ambient Light Sensor (CJ3)/Ambient Light/Sunload Sensor Assembly (CJ2) |
| 7 | Mode Actuator |
| 8 | Air Temperature Sensor - Lower Left (CJ2) |
| 9 | Defrost Actuator |
| 10 | Windshield Wiper motor |
| 11 | Speaker - LF I/P (UQA) |
| 12 | C225 (JF4) |
| 13 | Turn Signal/Hazard Flasher Module |
| 14 | Stop Lamp Switch |
| 15 | Accelerator Pedal Position (APP) Sensor |
| 16 | S239 |
| 17 | S202 |
| 18 | S217 |
| 19 | Air Temperature Actuator - Right |
| 20 | Splice Pack SP205 |
| 21 | S211 |
| 22 | S230 |
| 23 | Air Temperature Sensor - Lower Right (CJ2) |
| 24 | Splice Pack SP201 |
| 25 | Air Temperature Actuator - Right |
| 26 | S271 (CJ2) |
| 27 | Blower Motor Resistor Assembly (CJ3)/Blower Motor Control Module (CJ2) |
| 28 | S250 (CJ3) |
| 29 | S201 (CJ3) |
| 30 | Inflatable Restraint I/P Module |
Scheme 178
| Callout | Component Name |
|---|
| 1 | Instrument Panel Cluster |
| 2 | Transfer Case Shift Control Switch (NP8) |
| 3 | Air Temperature Sensor - Upper Left (CJ2) |
| 4 | HVAC Control Module C2 |
| 5 | Air Temperature Sensor - Upper Right (CJ2) |
| 6 | HVAC Control Module C1 |
| 7 | C221 (U42/U2K) |
| 8 | C202 |
| 9 | C203 (ASF) |
| 10 | Auxiliary Power Outlet - Front |
| 11 | Cigar Lighter |
| 12 | C307 |
| 13 | Inflatable Restraint Sensing and Diagnostic Module (SDM) |
| 14 | S220 |
| 15 | Rollover Sensor |
| 16 | C304 |
| 17 | Fuse Block - Rear C1 |
| 18 | Body Control Module (BCM) C1 |
| 19 | Body Control Module (BCM) C2 |
| 20 | S203 |
| 21 | S320 |
| 22 | Rear Window Wiper/Washer Switch (CD6) |
| 23 | C201 |
| 24 | C275 |
| 25 | Data Link Connector (DLC) |
| 26 | Transfer Case Shift Control Module C2 (4WD) |
| 27 | Transfer Case Shift Control Module C3 (4WD) |
| 28 | Headlamp Switch C1 |
| 29 | Headlamp Switch C2 |
Scheme 179
| Callout | Component Name |
|---|
| 1 | Digital Radio Receiver (U2K) |
| 2 | C221 (U42/U2K) |
| 3 | C220 (U42) |
Scheme 180
| Callout | Component Name |
|---|
| 1 | Steering Wheel Control Switch Assembly - Upper Left |
| 2 | C277 |
| 3 | Steering Wheel Control Switch Assembly - Upper Right |
| 4 | Steering Wheel Control Switch Assembly - Lower Right |
| 5 | Steering Wheel Control Switch Assembly - Lower Left |
Scheme 181
| Callout | Component Name |
|---|
| 1 | Electronic Adjustable Pedals (EAP) Relay |
| 2 | C225 |
| 3 | Electronic Adjustable Pedals (EAP) Assembly |
Scheme 182
| Callout | Component Name |
|---|
| 1 | Splice Pack SP306 |
| 2 | S374 (BAE) |
| 3 | S362 (BAE) |
| 4 | Center High Mounted Stop Lamp (CHMSL) |
| 5 | C900 |
| 6 | S401 |
| 7 | G401 |
| 8 | Tail Lamp Circuit Board - Left |
| 9 | C304 |
| 10 | Inflatable Restraint Roof Rail Module - Left |
| 11 | Fuse Block - Rear C2 |
| 12 | C700 |
| 13 | Air Temperature Sensor Assembly - Inside (CJ2) |
| 14 | G302 |
| 15 | S302 |
| 16 | C317 |
| 17 | C500 |
| 18 | C311 |
| 19 | C306 |
| 20 | C314 |
| 21 | C318 |
| 22 | C203 (ASF) |
| 23 | C202 |
| 24 | C220 (U42) |
| 25 | C600 |
| 26 | S310 |
| 27 | S303 |
| 28 | G303 |
| 29 | C800 |
| 30 | Vehicle Communication Interface Module (VCIM) (UE1) C1 |
| 31 | Vehicle Communication Interface Module (VCIM) (UE1) C2 |
| 32 | Inflatable Restraint Roof Rail Module - Right |
| 33 | S402 |
| 34 | Audio Amplifier (UQA) C2 |
| 35 | Audio Amplifier (UQA) C1 |
| 36 | Tail Lamp Circuit Board - Right |
| 37 | G402 |
Scheme 183
| Callout | Component Name |
|---|
| 1 | Tail Lamp Circuit Board - Right |
| 2 | S402 |
| 3 | G402 |
| 4 | Inflatable Restraint Roof Rail Module - Right |
| 5 | Vehicle Communication Interface Module (VCIM) (UE1) C1 |
| 6 | Vehicle Communication Interface Module (VCIM) (UE1) C2 |
| 7 | Center High Mounted Stop Lamp (CHMSL) |
| 8 | C900 |
| 9 | G401 |
| 10 | Tail Lamp Circuit Board - Left |
| 11 | S401 |
| 12 | Audio Amplifier (UQA) C1 |
| 13 | Audio Amplifier (UQA) C2 |
| 14 | Splice Pack SP 306 |
| 15 | C304 |
| 16 | C306 |
| 17 | Fuse Block - Rear C2 |
| 18 | C309 |
| 19 | Inflatable Restraint Roof Rail Module - Left |
| 20 | C700 |
| 21 | Air Temperature Sensor Assembly - Inside (CJ2) |
| 22 | G302 |
| 23 | S302 |
| 24 | C311 |
| 25 | C317 |
| 26 | C500 |
| 27 | C202 |
| 28 | C203 |
| 29 | C220 (U42) |
| 30 | C600 |
| 31 | C318 |
| 32 | S310 |
| 33 | C314 |
| 34 | S303 |
| 35 | G303 |
| 36 | C800 |
| 37 | C401 |
Scheme 184
| Callout | Component Name |
|---|
| 1 | Cargo Lamp |
| 2 | C308 (CF5) |
| 3 | Courtesy/Reading Lamp - Center |
| 4 | S390 |
| 5 | S331 |
| 6 | C305 |
| 7 | S322 |
| 8 | Vanity Mirror Lamp - Right (DH2) |
| 9 | Outside Moisture Sensor (CE1) |
| 10 | Inside Rearview Mirror |
| 11 | Vanity Mirror Lamp - Left (DH2) |
| 12 | S312 |
| 13 | C306 |
| 14 | Fuse Block - Underhood C3 |
Scheme 185
| Callout | Component Name |
|---|
| 1 | Cargo Lamp (Except XUV) |
| 2 | Quarterglass Actuator - Right (A34) |
| 3 | Courtesy/Reading Lamp (3rd Row) - Right (Except XUV) |
| 4 | S312 |
| 5 | Courtesy/Reading Lamp (3rd Row) - Center |
| 6 | S390 |
| 7 | S331 |
| 8 | C305 |
| 9 | S322 |
| 10 | Vanity Mirror Lamp - Right (DH2) |
| 11 | Outside Moisture Sensor (CE1) |
| 12 | Inside Rearview Mirror |
| 13 | Vanity Mirror Lamp - Left (DH2) |
| 14 | C306 |
| 15 | Fuse Block - Underhood C3 |
| 16 | C308 (CF5) |
| 17 | G306 |
| 18 | Courtesy/Reading Lamp (3rd Row) - Left (Except XUV) |
| 19 | Quarterglass Actuator - Left (A34) |
| 20 | S350 (Except XUV) |
| 21 | S391 (Except XUV) |
| 22 | S333 (Except XUV) |
Scheme 186
| Callout | Component Name |
|---|
| 1 | Seat Belt Pretensioner - Left |
| 2 | C317 |
Scheme 187
| Callout | Component Name |
|---|
| 1 | Seat Belt Pretensioner - Right |
| 2 | C318 |
Scheme 188
| Callout | Component Name |
|---|
| 1 | Auxiliary Power Outlet - Console |
| 2 | HVAC Control Module - Auxiliary |
| 3 | S307 |
| 4 | C307 |
| 5 | Mode Actuator - Auxiliary (Long Wheel Base Except XUV) |
| Callout | Component Name |
|---|
| 1 | HVAC Control Module - Auxiliary |
| 2 | Auxiliary Power Outlet - Console |
| 3 | S324 (Long Wheel Base Except XUV) |
| 4 | Blower Motor Switch - Front Auxiliary |
| 5 | S323 (Long Wheel Base Except XUV) |
| 6 | C307 |
| 7 | C309 (Long Wheel Base Except XUV) |
| 8 | S307 |
| 9 | S325 (Long Wheel Base Except XUV) |
| 10 | Console Mode Actuator - Auxiliary |
| 11 | S326 (Long Wheel Base Except XUV) |
Scheme 189
| Callout | Component Name |
|---|
| 1 | HVAC Control Module - Auxiliary |
| 2 | Auxiliary Power Outlet - Console |
| 3 | Traction Control Switch (NW7) |
| 4 | C307 |
| 5 | C303 (NW7) |
| 6 | Mode Actuator - Auxiliary |
| 7 | S307 |
| 8 | Inverting Driver Module (NW7) |
Scheme 190
| Callout | Component Name |
|---|
| 1 | C500 |
| 2 | Driver Door Module (DDM) C2 |
| 3 | Door Latch Assembly - Driver C1 |
| 4 | Door Latch Assembly - Driver C3 |
| 5 | Door Latch Assembly - Driver C2 |
| 6 | Inflatable Restraint Side Impact Sensor (SIS) - Left (ASF) |
| 7 | Window Motor - Driver |
Scheme 191
| Callout | Component Name |
|---|
| 1 | Door Latch Assembly - Passenger C1 |
| 2 | Door Latch Assembly - Passenger C2 |
| 3 | Inflatable Restraint Side Impact Sensor (SIS) - Right (ASF) |
| 4 | Window Motor - Front Passenger |
| 5 | Front Passenger Door Module (FPDM) C1 |
| 6 | C600 |
Scheme 192
| Callout | Component Name |
|---|
| 1 | C700 |
| 2 | Window Switch - LR |
| 3 | Door Latch Assembly - LR C1 |
| 4 | Door Latch Assembly - LR C2 |
| 5 | Speaker - LR Door |
| 6 | Window Motor - LR |
Scheme 193
| Callout | Component Name |
|---|
| 1 | Door Latch Assembly - RR C1 |
| 2 | Window Switch - RR |
| 3 | Window Motor - RR |
| 4 | C800 |
| 5 | Speaker - RR Door |
| 6 | Door Latch Assembly - RR C2 |
Scheme 194
| Callout | Component Name |
|---|
| 1 | Midgate Glass Motor |
| 2 | Midgate Latch - Left |
| 3 | Midgate Latch Release Switch |
| 4 | S357 |
| 5 | C320 |
| 6 | S356 |
| 7 | S355 |
| 8 | Diode Assembly |
| 9 | Glass Full Down Switch |
Scheme 195
| Callout | Component Name |
|---|
| 1 | Power Roof Module C1 |
| 2 | Power Roof Module C2 |
| 3 | Power Roof Motor |
| 4 | C321 |
| 5 | C322 |
Scheme 196
| Callout | Component Name |
|---|
| 1 | Mode Actuator - Auxiliary |
| 2 | Blower Motor - Auxiliary |
| 3 | Air Temperature Actuator - Auxiliary |
| 4 | C401 |
| 5 | Blower Motor Fuse - Auxiliary |
Scheme 197
| Callout | Component Name |
|---|
| 1 | Rear Window Wiper Motor (CD6) |
| 2 | C905 (C49) |
| 3 | Liftglass Ajar Switch |
| 4 | C902 (Y92) |
| 5 | C900 |
| 6 | C904 (C49) |
| 7 | S901 |
| 8 | Liftgate Module (LGM) C3 |
| 9 | Liftgate Module (LGM) C2 |
| 10 | Liftgate Module (LGM) C1 |
| 11 | C901 |
| 12 | Liftgate Latch Assembly C2 |
| 13 | Liftgate Latch Assembly C1 |
| 14 | Cargo Lamp |
Scheme 198
| Callout | Component Name |
|---|
| 1 | C901 |
| 2 | Center High Mounted Stop Lamp (CHMSL) |
| 3 | Rear Window Wiper Motor (CD6) |
| 4 | Endgate Window Regulator |
| 5 | Endgate Actuator - Upper Right |
| 6 | C900 |
| 7 | S905 (C49) |
| 8 | Rear Window Defogger Grid C2 (C49) |
| 9 | S910 |
| 10 | S911 |
| 11 | S913 |
| 12 | S912 |
| 13 | Rear Window Defogger Grid C1 (C49) |
| 14 | Endgate Actuator - Lower Left |
| 15 | S904 (C49) |
| 16 | Endgate Latch Relay |
| 17 | S914 |
| 18 | Endgate Actuator - Upper Left |
Scheme 199
| Callout | Component Name |
|---|
| 1 | Rear Window Defogger Grid C1 |
| 2 | C905 |
| 3 | C904 |
| 4 | Rear Window Defogger Grid C2 |
Scheme 200
| Callout | Component Name |
|---|
| 1 | License Lamp - Right |
| 2 | S902 |
| 3 | S909 |
| 4 | License Lamp - Left |
| 5 | C901 |
Scheme 201
| Callout | Component Name |
|---|
| 1 | Endgate Key Cylinder |
| 2 | License Lamp - Right |
| 3 | Endgate Drop Handle Switch |
| 4 | S902 |
| 5 | License Lamp - Left |
| 6 | S915 |
| 7 | S909 |
| 8 | Endgate Swing Handle Switch |
| 9 | C901 |
Electrical Center Identification Views
See ELECTRICAL CENTER IDENTIFICATION VIEWS
