REMOVAL & INSTALLATION
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION section before disconnecting battery. |
- Disconnect negative battery cable. Remove power window switch. See WINDOW SWITCH. Remove door trim panel retaining screws. Using Trim Panel Remover (J-38778), pry retainers from door frame, and remove door trim panel. Remove armrest bracket. Remove water protection shield. Disconnect electrical connectors from motor.
- Lower window half-way down. Remove window run channels and weatherstrip. Remove outer weatherstrip. Move window forward to release sash channel from rear regulator roller. Tilt window forward to vertical position, pull upward and remove window from door. CAUTION: Sector gear must be locked into position. Regulator lift arm is under tension from counterbalance spring and could cause personal injury if sector gear is not locked in position.
- Drill out rivets that secure window regulator to door. Remove window regulator. Drill hole through regulator sector gear and backplate. Install bolt and nut, locking sector gear into position. Drill out window motor mounting rivets. Remove motor from window regulator. To install, reverse removal procedure. Use 3/16" (4.8 mm) rivets to install motor and regulator.
Disconnect negative battery cable. Using flat-blade screwdriver, pry power window switch from door trim panel. Disconnect electrical connector and remove power window switch. To install, reverse removal procedure.
