Removal & Installation
Disconnect negative battery cable. Remove center and left sound insulator. Disconnect TBF module harness connectors as specified. Remove TBC module. To install, reverse removal procedure, reconnecting connectors as specified. To reprogram TBC module, see procedures in TBC MODULE PROGRAMMING/RPO CONFIGURATION .
Scheme 1: Body Control Module (BCM) Wiring Diagram
Data Link Connector Wiring Diagram. Scheme 1
Scheme 1: Data Link Connector Wiring Diagram
Power Distribution Wiring Diagram (1 Of 5). Scheme 2
Scheme 2: Power Distribution Wiring Diagram (1 Of 5)
Power Distribution Wiring Diagram (2 Of 5). Scheme 3
Scheme 3: Power Distribution Wiring Diagram (2 Of 5)
Power Distribution Wiring Diagram (3 Of 5). Scheme 4
Scheme 4: Power Distribution Wiring Diagram (3 Of 5)
Power Distribution Wiring Diagram (4 Of 5). Scheme 5
Scheme 5: Power Distribution Wiring Diagram (4 Of 5)
Power Distribution Wiring Diagram (5 Of 5). Scheme 6
Scheme 6: Power Distribution Wiring Diagram (5 Of 5)
