Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Circuit/System Description
The internal fault detection is handled inside the control module. No external circuits are involved.
Some control modules must be configured with serial numbers, vehicle options, or other information. If a control module was not properly configured after installation, that module may set DTC B1001.
The internal fault detection is handled inside the control module.
The internal fault detection is handled inside the control module. No external circuits are involved.
The internal fault detection is handled inside the control module. The symptom byte listed in the DTC Descriptor is for engineering reference only. No external circuit diagnosis is involved.
Modules connected to the GMLAN serial data circuits monitor for serial data communications during normal vehicle operation. Operating information and commands are exchanged among the modules. The modules have programmed information about what messages are needed to be exchanged on the serial data circuits. The messages are also supervised and some periodic messages are used by the receiver module as an availability indication of the transmitter module.
DTC U0020 will set when fewer modules are detected on the bus before the modules can learn the other modules IDs. If the communication bus is opened, or if the modules power supply is lost when the vehicle is in the OFF power mode, and then placed in the RUN power mode, U0020 will set in specific modules.
The serial data circuits are serial data buses are used to communicate information between the control modules. The serial data circuits also connect directly to the data link connector (DLC).
The serial data is transmitted on two twisted wires that allow speeds up to 500 Kb/s. The twisted pair is terminated with two 120 ohms resistors, one is internal to the engine control module (ECM) and the other can be a separate resistor in a connector assembly or in another control module. The resistors are used as the load for the Powertrain high speed GMLAN bus during normal vehicle operation. The Powertrain high speed GMLAN is a differential bus. The Powertrain high speed GMLAN serial data bus (+) and Powertrain high speed GMLAN serial data (-) are driven to opposite extremes from a rest or idle level of approximately 2.5 V. Driving the lines to their extremes, adds 1 V to the Powertrain high speed GMLAN serial data bus (+) circuit and subtracts 1 V from the Powertrain high speed GMLAN serial data bus (-) circuit. If serial data is lost, control modules will set a no communication code against the non-communicating control module. Note that a loss of serial data DTC does not represent a failure of the control module that set it.
The serial data circuit is the means by which the control modules in the vehicle communicate with each other. Once the scan tool is connected to the serial data circuit through the data link connector (DLC), the scan tool can be used to monitor each control module for diagnostic purposes and to check for diagnostic trouble codes (DTCs). When the ignition switch is in RUN, each control module communicating on the serial data circuit sends a state of health (SOH) message to ensure that the control module is operating properly. When a control module stops communicating on the serial data circuit, for example if the control module loses power or ground, the SOH message it normally sends on the serial data circuit disappears. Other control modules on the serial data circuit, which expect to receive that SOH message, detect its absence; those control modules in turn set a DTC associated with the loss of SOH of the non-communicating control module. The DTC is unique to the control module which is not communicating and one or more control modules may set the same exact code. A loss of serial data communications DTC does not represent a failure of the control modules that contain the stored code.
The remote compass module (RCM) communicates with the body control module (BCM) utilizing a single wire LIN communication link. The BCM is the gateway for the GMLAN network. All data is communicated on the LIN bus, therefore there are only 3 circuits to the module as follows
- Ground
- LIN bus
- Voltage
The accessory wake up serial data circuit is a voltage wake up signal from the body control module (BCM) to the engine control module (ECM) and the transmission control module (TCM). The signal is activated in 2 ways; any time the ignition switch is in the ACC or RUN position, or anytime the BCM determines that communication is needed from the powertrain. When the ignition switch is in the ACC or RUN position, the accessory voltage circuit input to the BCM is internally connected to the accessory wake up serial data circuit output, and voltage is supplied to the modules. The BCM also supplies voltage to the accessory wake up serial data circuit when it determines that communication is necessary with the powertrain and the ignition is not in the ACC or RUN position such as during remote start.
The yaw rate and the lateral accelerometer sensors are combined into one sensor, external to the electronic brake control module (EBCM). The vehicle stability enhancement system (VSES) uses the lateral accelerometer input when calculating the desired yaw rate. The yaw rate/lat sensor communicates with the EBCM via discrete CAN Bus High and CAN Bus Low serial data circuits.
Control modules connected to the serial data circuits monitor for serial data communications during normal vehicle operation. Operating information and commands are exchanged among the control modules. The control modules have prerecorded information about what messages are needed to be exchanged on the serial data circuits, for each virtual network. The messages are supervised and also, some periodic messages are used by the receiver module as an availability indication of the transmitter module. Each message contains the identification number of the transmitter module.
The body control module (BCM) applies voltage to the high speed GMLAN serial data wake up circuit, when the ignition key is in ACC, ON or START to enable several modules for bus communication.
Depending on option content, modules that may receive the signal are as follows
- Electronic brake control module (EBCM)
- Electronic suspension control (ESC) module
- Distance sensing cruise control (DSCC) module
- Trailer brake control module
- Fuel pump flow control module
- Power take off module
The data link connector (DLC) is a standardized 16 cavity connector. Connector design and location is dictated by an industry wide standard, and is required to provide the following
- Scan tool B+ voltage at terminal 16
- Scan tool ground at terminal 4
- Common ground at terminal 5
The serial data is transmitted on two twisted wires that allow speeds up to 500 Kb/s. The twisted pair is terminated with two 120 ohms resistors, one is internal to the engine control module (ECM) and the other can be a separate resistor in a connector assembly or in another control module. The resistors are used as the load for the high speed GMLAN bus during normal vehicle operation. The high speed GMLAN is a differential bus. The high speed GMLAN serial data bus (+) and high speed GMLAN serial data (-) are driven to opposite extremes from a rest or idle level of approximately 2.5 V. Driving the lines to their extremes, adds one volt to the high speed GMLAN serial data bus (+) circuit and subtracts one volt from the high speed GMLAN serial data bus (-) circuit. If serial data is lost, control modules will set a no communication code against the non-communicating control module. Note that a loss of serial data DTC does not represent a failure of the control module that set it.
The serial data is transmitted over a single wire to the appropriate control modules. The transmission speed for GMLAN low speed is up to 83.33 Kb/s. Under normal vehicle operating conditions, the speed of the buss is 33.33 Kb/s. The control modules toggle the serial data circuit between 0-5 V during normal communications. To wake the control modules connected to the GMLAN low speed serial data circuit, a voltage wake up pulse of 10 V is sent out. If serial data is lost, control modules will set a no communication code against the non-communicating control module. Note: a loss of serial data communications DTC does not represent a failure of the module that set it.
Body Control System Description and Operation
The body control system consists of the body control module (BCM), communications, and various input and outputs. Some inputs, outputs and messages require other modules to interact with the BCM. The BCM also has discrete input and output terminals to control the vehicle's body functions. The BCM is wired to the GMLAN High speed serial data bus and the GMLAN Low speed serial data bus and acts as a gateway between them. If the BCM does not communicate the vehicle will not start due to the inability of the Engine/Powertrain Control Module (ECM/PCM) and Vehicle Theft Deterrent (VTD) Control Module to communicate without the BCM providing the gateway function.
Local Interconnect Network (LIN) Description
The remote compass module (RCM) communicates with the BCM utilizing a single wire LIN communication link. The BCM is the gateway for the GMLAN network. All data is communicated on the LIN bus, therefore there are only 3 circuits to the RCM as follows
- Ground
- LIN bus
- Voltage
