Supplemental Inflatable Restraint System: Specifications GMC Cutaway G3500

Airbag 5 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Inflatable Restraint Front End Discriminating Sensor Nut10 N.m89 lb in
Inflatable Restraint I/P Module Bolts10 N.m89 lb in
Inflatable Restraint Sensing and Diagnostic Module Nut10 N.m89 lb in
Pretensioner Bolt40 N.m30 lb ft
Pretensioner Trim Cover Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Module Power, Ground, Serial Data, Vehicle Rollover Sensor (ASF) and Disable Switch
Scheme 1: Module Power, Ground, Serial Data, Vehicle Rollover Sensor (ASF) and Disable Switch

Scheme 2

Scheme 2: Steering Wheel and I/P Modules
Scheme 2: Steering Wheel and I/P Modules

Scheme 3

Scheme 3: Passenger Presence System Light Duty (without C99 without YF7)
Scheme 3: Passenger Presence System Light Duty (without C99 without YF7)

Scheme 4

Scheme 4: Inflatable Restraint Sensors
Scheme 4: Inflatable Restraint Sensors

Scheme 5

Scheme 5: Inflatable Restraint Side Impact Sensors and Modules (ASF)
Scheme 5: Inflatable Restraint Side Impact Sensors and Modules (ASF)
