Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Amplifier Screw | 9 N.m | 80 lb in |
| Antenna Assembly Screw | 5 N.m | 44 lb in |
| Antenna Mast | 6 N.m | 53 lb in |
| Antenna Module Bolt | 9 N.m | 80 lb in |
| Front Floor Console Screw | 9 N.m | 80 lb in |
| Front Floor Console Bracket Screw | 9 N.m | 80 lb in |
| Front Floor Console Speaker Nut | 9 N.m | 80 lb in |
| Front Speaker Screw | 6 N.m | 53 lb in |
| Front Door Speaker Screw | 3 N.m | 25 lb in |
| Mobile Telephone Antenna Bolt | 9 N.m | 80 lb in |
| Radio Retaining Screws | 2 N.m | 18 lb in |
| Rear Door Speaker Screw | 3 N.m | 25 lb in |
| Rear Pillar Speaker Screw | 3 N.m | 25 lb in |
| Rear Radio Control Screw | 1.5 N.m | 13 lb in |
| Roof Console Screw | 2 N.m | 18 lb in |
| Video Display Assembly Screw | 2 N.m | 18 lb in |
Scheme 1
Scheme 1: Radio/Navigation System Schematics
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 9: OnStar Schematics
Scheme 10
Scheme 11
Scheme 11: Video System Schematics
Scheme 12
Scheme 13
