DESCRIPTION
The ignition lock cylinder is typically mounted below turn signal switch and is actuated by ignition key. The ignition switch is typically mounted at base of steering column, inside channel section of brake pedal support.
The ignition switch is actuated by a rod and rack assembly. A portion of rack is toothed and engages a gear on end of lock cylinder. This enables the rod and rack to be moved axially, with respect to column, to actuate ignition switch when lock cylinder is rotated.
STEERING WHEEL
Removal & Installation
Disconnect negative battery cable. Remove horn button cap. Remove retainer and steering wheel nut. Disconnect horn lead (if equipped). Mark relationship of steering wheel to shaft. Use Steering Wheel Puller (J-1859-03) to remove steering wheel. To install, reverse removal procedure.
TURN SIGNAL SWITCH
Removal
1) Remove steering wheel. Remove instrument panel trim cover. Position screwdriver blade into steering shaft lock plate cover slot. Pry up and out to free cover from lock plate.
2) Screw center post of Lock Plate Compressor (J-23653-A or J-23653-B) onto steering shaft as far as it will go. Compress lock plate by turning center post nut clockwise. Pry retaining ring out of steering shaft. Remove compressor and lock plate.
3) Remove turn signal lever screw and lever. Remove hazard warning knob. Press knob inward and then unscrew. Remove turn signal switch mounting screws. Position turn signal switch and shifter housing in low gear position. Remove wiring harness cover by carefully pulling downward on tab provided.
4) Pull switch connector out of bracket and feed connector through column support bracket. Pull turn signal switch straight up, guiding the wiring harness and cover through column housing.
Installation
To install, reverse removal procedure. On non-tilt steering columns, ensure wiring harness is on protector. Feed connector and cover down through housing and under mounting screw. On tilt columns, feed connector down through housing and under mounting bracket. Install cover on harness.
Removal
Turn ignition key to "RUN" position. Remove steering wheel and turn signal switch. It is not necessary to completely remove switch from column. Pull switch out far enough to slip it over end of shaft. DO NOT pull harness out of column. Carefully remove retaining screw and lock cylinder.
Installation
Turn ignition key clockwise against stop while holding lock cylinder. (Scheme 1) Align lock cylinder with keyway in housing. Push lock cylinder in and install retaining screw. To complete installation, reverse removal procedure.
Scheme 1
Note. "P" series ignition switch removal and installation procedures not available from manufacturer.
Removal
1) Lower steering column and support column to avoid causing damage. Place ignition switch in "LOCK" position (one detent down from full up position). (Scheme 2) Remove 2 screws and switch assembly from vehicle.
2) If lock cylinder was removed, the actuating rod should be pull up until there is a definite stop, then move rod down one detent (into "LOCK" position). Remove 2 screws and switch assembly from vehicle.
Installation
Place lock and switch in "LOCK" position (one detent down from full up position). Insert actuating rod into switch and install switch using mounting screws. To complete installation, reverse removal procedure.
Scheme 2
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Steering Column Support Bracket Screws | 22 (30) |
| Steering Wheel Nut | 30 (40) |
| INCH Lbs. (N.m) | |
| Ignition Switch Screws | 35 (4.0) |
| Lock Cylinder Retaining Screw | 40 (4.5) |
| Turn Signal Switch Screws | 35 (4.0) |
TORQUE SPECIFICATIONS
