DESCRIPTION
Ensure tires are correctly inflated, cargo compartment is empty and fuel tank is full. Bounce vehicle several times to noralize ride height.
Most vehicles provide front wheel alignment specifications which allow camber and caster adjustment for a large range of ride heights. Ride height for light trucks is listed as "RIDE HGT." in the alignment tables. Ride height measurement points are shown. (Scheme 1)- (Scheme 4)
RIDING HEIGHT SPECIFICATIONS
| Application | (mm) | |
|---|---|---|
| C/K Series | ||
| "Z" Heights | 73.6 +/- 6.0 | |
| "D" Heights | 182 +/- 6.0 | |
| R/V & G/P (10-30 Series) | (1) | |
| S/T Series | ||
| "Z" Heights (S Series) | 73.0 +/- 6.0 | |
| "Z" Heights (T Series) | 122.0 +/- 6.0 | |
| "D" Heights | 170/0 +/- 6.0 | |
| Astro/Safari | ||
| "Z" Heights | 80.0 +/- 6.0 | |
| "D" Heights (1988) | 150.0 +/- 15 | |
| "D" Heights (1989) | 135.0 +/- 6.0 | |
| (1) Information not available. | ||
| (1) | Information not available. |
