DESCRIPTION & OPERATION
Wiper system consists of a 2-speed permanent magnet-type motor. Wiper motor consists of field magnets, and armature and drive gear within upper and lower housings. The washer motor is assembled on bottom of washer fluid reservoir. (Scheme 1) Wiper motor is protected by an automatic reset circuit breaker. Vehicle wiring is protected by fuse in fuse block.
Washer motor is controlled by a washer switch, located on turn signal and multi-functional lever. Two wires go to washer motor. White wire has power from fuse box. Pink wire is the ground circuit that goes through washer switch to ground.
Scheme 1
* PLEASE READ FIRST *
Before proceding to any Diagnostic Procedures the following must be checked
- Continuity of all wires
- Wiper motor-to-dash mounting screws tight
- Fuses
- Washer hoses clear
Scheme 2
Scheme 3
WIPER MOTOR
- If wiper motor functions in all modes (Scheme 4)or (Scheme 5).
- If motor does not function in any of checks see DIAGNOSIS CHART.
WASHER PUMP
- If motor does not run or pump water, replace washer pump.
- If motor runs and pumps water, problem is in circuit board, motor park switch or wiper switch. (Scheme 4)or (Scheme 5)
WIPER-WASHER SWITCH
Disconnect wiring harness from wiper motor and perform switch test in either (Scheme 4) or (Scheme 5) using a digital voltmeter and with the ignition switch on.
Scheme 4
Scheme 5
DIAGNOSIS PROCEDURES CHART
| Symptom | Procedure |
|---|---|
| Pump Inoperative - Wiper Motor Operates | 1 |
| Washer Pumps Continuously | 2 |
| Wiper Motor Inoperative (All Modes) | 3 |
| Lo Speed Only - Inoperative Hi | 4 |
| Hi Speed Only - Inoperative Lo | 5 |
| One Speed Only - Runs The Same In Both Speeds | 6 |
| Wiper Shuts Off But Blades Don't Park | 7 |
| Wiper Will Not Shut Off | 8 |
| Intermittent Inoperative | 9 |
| Wiper Motor Runs But Blades Don't Move | 10 |
| Wiper Parks Above Park Position | 11 |
DIAGNOSIS CHART
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
Removal ("C" & "K" Series)
- Ensure wiper motor is in park position and negative battery cable is disconnected. Disconnect electrical harness at motor. Disconnect hoses at washer pump. Reach through access hole in cowl grille and loosen wiper drive rod attaching screws.
- Remove drive rod from wiper motor crank arm. Remove screws attaching wiper motor to instrument panel and remove motor assembly.
Installation ("C" & "K" Series)
To install, reverse removal procedure. Lubricate crank arm pivot prior to installation.
OVERHAUL
Repairs to motor/gear box section of wiper assembly are limited to switch, armature, cap and brush holder assembly, plus external parts, crankarm, spacer and seal (plastic) and output shaft seal.
WIRING DIAGRAMS
For wiring diagrams, refer to appropriate chassis wiring diagram in WIRING DIAGRAMS section.
