Exterior lights — Backup lamps circuit GMC Acadia II
All systems — 36 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering 2
- Electronic suspension
- Engine performance 2.5l vin a
- Engine performance 3.6l vin s
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 3
- Navigation 6
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 7
- Power top/sunroof
- Power windows 2
- Radio 2
- Shift interlock 2
- Starting/charging 2.5l vin a 2
- Starting/charging 3.6l vin s 2
- Supplemental restraints
- Transmission 2.5l vin a 2
- Transmission 3.6l vin s 2
- Trunk, tailgate, fuel door 2
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 28
Click a component to highlight it on every diagram it appears on.
