Adhesives, Fluids, Lubricants and Sealers
| Application | Type of Material | GM Part Number |
|---|
| United States | Canada |
| Rear Output Shaft Nut | Threadlocker | 12345382 | 10953489 |
| Transfer Case Fill | SAE 75W-90 Synthetic | 88900401 | 89021678 |
Adhesives, Fluids, Lubricants and Sealers
Scheme 29
Scheme 29: Transfer Case Disassembled View
| Callout | Component Name |
|---|
| 1 | Transfer Case Input Shaft Seal - Left |
| 2 | Transfer Case O-ring Seal |
| 3 | Transfer Case - Left |
| 4 | Transfer Case Half Locating Pin (Qty: 2) |
| 5 | Transfer Case Rear Output Drive Shaft |
| 6 | Transfer Case Input Shaft |
| 7 | Front Drive Axle Intermediate Shaft Seal Assembly |
| 8 | Transfer Case Input Shaft Seal - Right |
| 9 | Transfer Case Seal |
| 10 | Transfer Case Vent Assembly |
| 11 | Transfer Case - Right |
| 12 | Transfer Case Fill Plug |
| 13 | Transfer Case Drain Plug |
| 14 | Transfer Case Half Bolt (Qty: 11) |
| 15 | Half Shaft Retainer |
| 16 | Front Wheel Drive Retainer |
| 17 | O-ring |
| 18 | Front Wheel Drive Intermediate Shaft Bearing Retainer (Qty: 2) |
| 19 | Front Wheel Drive Intermediate Shaft Bearing Assembly |
| 20 | Front Wheel Drive Intermediate Shaft |
| 21 | Transfer Case Rear Output Shaft |
| 22 | Transfer Case Rear Output Shaft Bearing Assembly (Qty: 2) |
| 23 | Transfer Case Rear Output Shaft Bearing Spacer |
| 24 | Transfer Case Rear Output Shaft Housing Seal O-ring |
| 25 | Transfer Case Rear Output Shim |
| 26 | Transfer Case Rear Output Shaft Housing |
| 27 | Transfer Case Rear Output Shaft Housing Bolt (Qty: 6) |
| 28 | Transfer Case Rear Output Shaft Seal |
| 29 | Transfer Case Rear Output Shaft Oil Slinger |
| 30 | Transfer Case Rear Output Shaft Flange |
| 31 | Transfer Case Rear Output Shaft Nut |
