Contents Wiring diagrams Section: Mirrors All sections

Mirror System: Other GMC Acadia I facelift

Mirrors 9 illustrations ~3226 words

Reference Information

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON.
  2. Verify the Outside Rearview Mirror-Driver moves when commanding the Mirror Right/Left and Mirror Up/Down with a scan tool. If the Outside Rearview Mirror-Driver does not move RIGHT or LEFT or UP or DOWN Refer to «Circuit/System Testing»(ref-610085-S03020132112014042100000) - Outside Mirror Movement Malfunction With DNP. Refer to «Circuit/System Testing»(ref-610085-S03020132112014042100000) - Outside Mirror Movement Malfunction With W49 and DS3. If the Outside Rearview Mirror-Driver moves RIGHT, LEFT, UP and DOWN
  3. Verify the Outside Rearview Mirror-Passenger when commanding the Mirror Right/Left and Mirror Up/Down with a scan tool. If the Outside Rearview Mirror-Passenger does not move RIGHT or LEFT or UP or DOWN Refer to «Circuit/System Testing»(ref-610085-S03020132112014042100000) - Outside Mirror Movement Malfunction With DNP. Refer to «Circuit/System Testing»(ref-610085-S03020132112014042100000) - Outside Mirror Movement Malfunction With W49 and DS3. If the Outside Rearview Mirror-Passenger moves RIGHT, LEFT, UP and DOWN
  4. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Outside Rearview Mirror Motor Replacement»(ref-610085-S36240053342014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for driver door lock/window switch or passenger door lock/window switch replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, observe the scan tool Mirror Horizontal Position and Mirror Vertical Position parameters. The reading should be between 0.2-4.8 V and change as the mirror is moved, left, right, up and down.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Motor Replacement»(ref-610085-S36240053342014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, programming and setup

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

Ignition ON, press the rear window defogger switch. The rear window defogger and both heated mirrors should become warm.

  1. If the rear window defogger is inoperative, refer to «Rear Window Defogger Malfunction»(ref-610044-S15033764182014042100000) .

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool References

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the Outside Rearview Mirror-Driver moves when commanding the Mirror Fold with a scan tool. If the Outside Rearview Mirror-Driver does not FOLD Refer to «Circuit/System Testing»(ref-610085-S04651473452014042100000) . If the Outside Rearview Mirror-Driver does FOLD
  3. Verify the Outside Rearview Mirror-Passenger when commanding the Mirror Fold with a scan tool. If the Outside Rearview Mirror-Passenger does not FOLD Refer to «Circuit/System Testing»(ref-610085-S04651473452014042100000) If the Outside Rearview Mirror-Passenger does FOLD
  4. All OK.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Power Mirror Replacement»(ref-610085-S20511011512014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for driver door lock/window switch or passenger door lock/window switch replacement, setup and programming

Symptoms - Mirrors

Note. The following steps must be completed before using the symptom tables.

  1. Perform the «Diagnostic System Check - Vehicle»(ref-610038-S36414632882014042100000) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
  2. Review the system operation in order to familiarize yourself with the system functions. Refer to the following system descriptions: «Automatic Day-Night Mirror Description and Operation»(ref-610085-S08311359642014042100000) «OnStar Description and Operation»(ref-610055-S34609759942014042100000) «Outside Mirror Description and Operation (DNP)»(ref-610085-S21191277952014042100000) , «Outside Mirror Description and Operation (DL6 or DS3)»(ref-610085-S01298004572014042100000)

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger indicator illuminates. If the rear window defogger indicator does not illuminate, refer to «Rear Window Defogger Malfunction»(ref-610044-S15033764182014042100000) .
  2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger indicator illuminates. If the rear window defogger indicator does not illuminate, refer to «Rear Window Defogger Malfunction»(ref-610044-S15033764182014042100000) .
  2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON, press the rear window defogger switch. Verify the rear window defogger turns ON and the rear window becomes warm. If the rear window defogger does not turn on, refer to «Rear Window Defogger Malfunction»(ref-610044-S15033764182014042100000) .
  2. Press the rear window defogger switch. Verify both the left and right outside mirror glass become warm.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, setup and programming

Schematic Reference

  1. «Inside Rearview Mirror Schematics»(ref-610085-S04426581342014042100000)
  2. «Outside Rearview Mirror Schematics»(ref-610085-S15137578072014042100000)

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Automatic Day-Night Mirror Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Cover the windshield with a blanket or other suitable item.
  3. Verify the A10 Inside Rearview Mirror face dims when shining a bright light into the rear light sensor If the A10 Inside Rearview Mirror does not dim Refer to «Circuit/System Testing»(ref-610085-S38407338682014042100000) - Inside Review Mirror Dimming Inoperative If the A10 Inside Rearview Mirror dims
  4. Verify the A10 Inside Rearview Mirror face transitions from dim to bright while commanding the Backup Lamps Active and Inactive with a scan tool. If the A10 Inside Rearview Mirror does not transition between dim and bright. Refer to «Circuit/System Testing»(ref-610085-S38407338682014042100000) - Day-Night Disable Malfunction If the A10 Inside Rearview Mirror transitions between bright and dim states
  5. Verify the A9A Outside Rearview Mirror-Driver face dims when shining a bright light into the rear light sensor. If the A9A Outside Rearview Mirror-Driver does not dim Refer to «Circuit/System Testing»(ref-610085-S38407338682014042100000) - Outside Rearview Mirror Dimming Malfunction. If the A9A Outside Rearview Mirror-Driver dims
  6. Verify the A9A Outside Rearview Mirror-Driver face transitions from dim to bright while commanding the Backup Lamps On and Off with a scan tool. If the A9A Outside Rearview Mirror-Driver does not transition between bright and dim states Refer to «Circuit/System Testing»(ref-610085-S38407338682014042100000) - Outside Rearview Mirror Dimming Malfunction. If the A9A Outside Rearview Mirror-Driver transitions between bright and dim states
  7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Inside Rearview Mirror Replacement»(ref-610085-S08751864382014042100000)
  2. «Outside Rearview Mirror Glass Replacement»(ref-610085-S23310203702014042100000)

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool References

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the Outside Rearview Mirror-Driver moves when commanding the Mirror Fold with a scan tool. If the Outside Rearview Mirror-Driver does not FOLD Refer to «Circuit/System Testing»(ref-610085-S00911911302014042100000) . If the Outside Rearview Mirror-Driver does FOLD
  3. Verify the Outside Rearview Mirror-Passenger when commanding the Mirror Fold with a scan tool. If the Outside Rearview Mirror-Passenger does not FOLD Refer to «Circuit/System Testing»(ref-610085-S00911911302014042100000) If the Outside Rearview Mirror-Passenger does FOLD
  4. All OK.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Power Mirror Replacement»(ref-610085-S20511011512014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for driver door lock/window switch or passenger door lock/window switch replacement, setup and programming

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the scan tool Mirror Select Switch parameter changes from Idle to Left and Right when cycling the Driver Door Lock/Window Switch. If the parameter does not change Replace the Driver Door Lock/Window Switch. If the parameter changes
  3. Verify the scan tool Mirror Motor parameter changes from Idle to Up, Down, Right and Left when cycling the Driver Door Lock/Window Switch. If the parameter does not change Replace the Driver Door Lock/Window Switch. If the parameter changes
  4. Verify the A9D Outside Rearview Mirror-Driver and A9P Outside Rearview Mirror-Passenger moves when commanding the Mirror Right/Left and Mirror Up/Down with a scan tool. If the A9D Outside Rearview Mirror-Driver or A9P Outside Rearview Mirror-Passenger does not move RIGHT or LEFT or UP or DOWN Refer to «Circuit/System Testing»(ref-610085-S12052507642014042100000) - Outside Mirror Movement Malfunction. If the A9D Outside Rearview Mirror-Driver and A9P Outside Rearview Mirror-Passenger moves RIGHT, LEFT, UP and DOWN
  5. Verify the scan tool Mirror Vertical Position parameters are between 0.2-4.8 V and change when commanding the Mirror Vertical Movement Up/Down with a scan tool. If not between 0.2-4.8 V or does not change Refer to «Circuit/System Testing»(ref-610085-S12052507642014042100000) - Mirror Position Sensor Circuit Test. If between 0.2-4.8 V and changes
  6. Verify the scan tool Mirror Horizontal Position parameters are between 0.2-4.8 V and change when commanding the Mirror Horizontal Movement Right/Left with a scan tool. If not between 0.2-4.8 V or does not change Refer to «Circuit/System Testing»(ref-610085-S12052507642014042100000) - Mirror Position Sensor Circuit Test. If between 0.2-4.8 V and changes
  7. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Outside Rearview Mirror Motor Replacement»(ref-610085-S36240053342014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for the driver door lock/window switch or passenger door lock/window switch replacement, programming and setup

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON, observe the scan tool Mirror Select Switch parameter while cycling the mirror select switch between the left and right positions. The parameter should change between Idle, Right and Left. If the parameter does not cycle between the specified values, replace the DDS.
  2. Observe the scan tool Mirror Motor parameter while cycling the mirror directional switch between the up, down, left and right positions. The parameter should change between Idle, Up, Down, Left and Right. If the parameter does not cycle between the specified values, replace the DDS.
  3. Command the left and right outside mirror to move up, down, left and right using the mirror directional switch. The mirror should move in the commanded direction.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Outside Rearview Mirror Motor Replacement»(ref-610085-S36240053342014042100000)
  2. «Control Module References»(ref-610060-S10098619762014042100000) for DDS or PDS replacement, programming and setup

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)
  1. Verify the mirror glass of the A9A Outside Rearview Mirror-Driver and the A9B Outside Rearview Mirror-Passenger move UP, DOWN, LEFT and RIGHT with the S52 Outside Rearview Mirror Switch. If both outside mirror glasses do not move Refer to «Circuit/System Testing»(ref-610085-S02227776722014042100000) - Both Outside Rearview Mirrors Inoperative. If the driver outside mirror glass does not move UP, DOWN, LEFT or RIGHT Refer to «Circuit/System Testing»(ref-610085-S02227776722014042100000) - Driver Outside Mirror Movement Malfunction. If the passenger outside mirror glass does not move UP, DOWN, LEFT or RIGHT Refer to «Circuit/System Testing»(ref-610085-S02227776722014042100000) - Passenger Outside Mirror Movement Malfunction. If the mirror glass of the A9A Outside Rearview Mirror-Driver and the A9B Outside Rearview Mirror-Passenger move UP, DOWN, LEFT and RIGHT
  2. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

  1. «Outside Rearview Mirror Motor Replacement»(ref-610085-S36240053342014042100000)
  2. «Outside Rearview Mirror Remote Control Switch Replacement (Traverse)»(ref-610085-S27532945772014042100000)

Schematic Reference

Outside Rearview Mirror Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Outside Mirror Description and Operation (DNP) , Outside Mirror Description and Operation (DL6 or DS3)

Electrical Information Reference

  1. «Circuit Testing»(ref-610066-S15766520632014042100000)
  2. «Connector Repairs»(ref-610066-S09830970062014042100000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
  4. «Wiring Repairs»(ref-610066-S23061455012014042100000)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON.
  2. Verify the park assist option is activated in the driver information center (DIC).
  3. Select the driver outside mirror on S52 Outside Rearview Mirror Switch.
  4. Verify mirror functions properly when operating the S52 Outside Rearview Mirror Switch in UP/DOWN and LEFT/RIGHT positions. If the mirror does not function properly Refer to «Power Mirror Malfunction (With DNP or DNT)»(ref-610085-S25449675732014042100000) , «Power Mirror Malfunction (With DS3 and W49)»(ref-610085-S34616082232014042100000) , «Power Mirror Malfunction (With DL6/DS3 or DM8 without W49)»(ref-610085-S22768994162014042100000) . If the mirror functions properly
  5. Select the passenger outside mirror on S52 Outside Rearview Mirror Switch.
  6. Verify mirror functions properly when operating the S52 Outside Rearview Mirror Switch in UP/DOWN and LEFT/RIGHT positions. If the mirror does not function properly Refer to «Power Mirror Malfunction (With DNP or DNT)»(ref-610085-S25449675732014042100000) , «Power Mirror Malfunction (With DS3 and W49)»(ref-610085-S34616082232014042100000) , «Power Mirror Malfunction (With DL6/DS3 or DM8 without W49)»(ref-610085-S22768994162014042100000) . If the mirror functions properly
  7. Operate the memory 1 and 2 recall switches on S47D Seat Memory Switch - Driver.
  8. Verify the outside rearview mirrors adjust to the stored memory positions. If the mirrors do not adjust to the stored positions Refer to «Power Mirror Malfunction (With DNP or DNT)»(ref-610085-S25449675732014042100000) , «Power Mirror Malfunction (With DS3 and W49)»(ref-610085-S34616082232014042100000) , «Power Mirror Malfunction (With DL6/DS3 or DM8 without W49)»(ref-610085-S22768994162014042100000) . If the mirrors adjust to the stored positions
  9. Park brake on, vehicle running, shift the vehicle in REVERSE.
  10. Verify that the outside rearview mirrors tilt. If the driver outside mirror does not tilt Ignition OFF. Replace the S52 Outside Rearview Mirror Switch. Park brake on, vehicle running, shift the vehicle in REVERSE. Verify the driver mirror tilts. If the mirror does not tilt, replace the K40 Memory Seat Module. If the mirror tilts All OK. If the passenger outside mirror does not tilt Ignition OFF. Replace the S79P Passenger Window Switch. Park brake on, vehicle running, shift the vehicle in REVERSE. Verify the driver mirror tilts. If the mirror does not tilt, replace the K40 Memory Seat Control Module. If the mirror tilts All OK. If the mirrors tilt
  11. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Control Module References for door lock/window switches and memory seat control module replacement, programming and setup

Scheme 7

Scheme 7: Outside Rearview Mirror Remote Control Switch Replacement (Traverse)
CalloutComponent Name
Preliminary Procedure Remove the driver side door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Acadia or Traverse) , Front Side Door Trim Panel Replacement - Left Side (Enclave) .
1Outside Remote Control Rearview Mirror Switch Assembly Procedure Release tabs on switch to remove from front side door trim panel. Refer to Control Module References for programming and set up procedures.

Outside Rearview Mirror Remote Control Switch Replacement (Traverse)

Scheme 8

Scheme 8: Power Mirror Replacement
CalloutComponent Name
Preliminary Procedures Remove the door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Acadia or Traverse) , Front Side Door Trim Panel Replacement - Left Side (Enclave) or Front Side Door Trim Panel Replacement - Right Side (Enclave) , Front Side Door Trim Panel Replacement - Right Side (Acadia or Traverse) . Remove the front side door upper garnish molding, if equipped. Refer to Front Side Door Garnish Molding Replacement (Enclave) .
1Outside Rearview Mirror Nut (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 10 N.m (89 lb in)
2Outside Rearview Mirror Procedure Remove the retainer holding the window reveal molding at the lower corner of the door in three positions.
CAUTION
Refer to Fastener Caution .

Power Mirror Replacement

Scheme 9

Scheme 9: Outside Rearview Mirror Motor Replacement
CalloutComponent Name
Preliminary Procedure Remove the outside rearview mirror glass. Refer to Outside Rearview Mirror Glass Replacement .
1Outside Rearview Mirror Motor Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Disconnect the electrical connector. Tighten 2 N.m (18 lb in)
2Outside Rearview Mirror Motor
CAUTION
Refer to Fastener Caution .

Outside Rearview Mirror Motor Replacement

Scheme 10

Scheme 10: Removal Procedure

Scheme 11

Scheme 11
  1. Place the front side door window in the full down position.
  2. Apply several layers of masking tape (2) to the bottom and inner edge of the outside rearview mirror housing (3) in order to protect the painted finish. WARNING: When working with any type of glass or sheet metal with exposed or rough edges, wear approved safety glasses and gloves in order to reduce the chance of personal injury.
  3. Push the mirror glass (1) inward at the top outer corner until full travel is reached.
  4. Remove the mirror glass do the following: NOTE: Do not use the suitable tool (flat plastic) to pry with. It must be used in a twisting motion only to release the mirror glass from the motor. Retain pressure on the top outer corner of the mirror glass (4). Insert a flat plastic suitable tool (1) between the two tabs (2) located behind the glass. Twist the flat plastic suitable tool (1) between the tabs (2) until the mirror glass releases from the motor.
  5. Disconnect the electrical connectors.
  6. Remove the mirror glass.

Scheme 12

Scheme 12: Installation Procedure
  1. Connect the electrical connectors.
  2. Install the mirror glass to the house.
  3. Align the mirror glass retaining tabs with the motor.
  4. Place your hand on the back of the mirror housing.
  5. Using the flat part of your hand press inward until the mirror glass fully seats onto the motor retaining tabs.
  6. Inspect the power mirror for proper operation.
  7. Remove the masking tape.
  8. Place the front side door window in the full up position.

Scheme 13

Scheme 13: Inside Rearview Mirror Replacement
CalloutComponent Name
1Inside Rearview Mirror Screw CAUTION: Refer to Fastener Caution . Procedure Remove the inside rearview mirror cover, if equipped. Tighten 2 (18 lb in)
2Inside Rearview Mirror Procedure Disconnect the electrical connector, if equipped. Adjust the mirror to the full upward position. Slide the mirror upward off of the rearview mirror button. Refer to Control Module References for programming and setup information.
CAUTION
Refer to Fastener Caution .

Inside Rearview Mirror Replacement

Scheme 14

Scheme 14: Inside Rearview Mirror Mount Plate Replacement
CalloutComponent Name
1Inside Rearview Mirror Mount Plate Procedure Grasp the mount plate on both sides and gently pull downward from window.

Inside Rearview Mirror Mount Plate Replacement

Scheme 15

Scheme 15: Inside Rearview Mirror Wiring Harness Cover Replacement
CalloutComponent Name
1Inside Rearview Mirror Wiring Harness Cover Procedures Pull downward to completely remove cover from window. Remove the inside rearview mirror mount plate. Refer to Inside Rearview Mirror Mount Plate Replacement .

Inside Rearview Mirror Wiring Harness Cover Replacement

Folding Mirrors (If Equipped)

The folding mirror system is controlled through an electronic switch that can be activated when the mirror select switch is in the neutral position. When the mirror select switch is in the neutral position, the fold/retract function is activated by pressing the down arrow. The fold/retract switch will fold or retract the mirrors depending on their current state. When a power fold or retract function is activated, battery voltage is supplied to the fold motor by the appropriate fold or retract control circuit and the motor will be grounded by the opposite control circuit.

Heated Mirrors (If Equipped)

The heated mirrors are controlled through the rear defog relay. Whenever the rear window defogger is turned on battery voltage is supplied to the mirror heater elements through the left and right mirror heater element control circuits.
