Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Intermediate Steering Shaft Lower Bolt (1) | 25 N.m | 18 lb ft |
| Intermediate Steering Shaft Upper Bolt (1) | 22 N.m | 16 lb ft |
| Steering Column Bolt | 27 N.m | 20 lb ft |
| Steering Column Lower Support Brace Bolt | 10 N.m | 89 lb in |
| Steering Column Nut | 27 N.m | 20 lb ft |
| Steering Column Tilt Wheel Position Sensor Bolt | 0.5 N.m | 4 lb in |
| Steering Wheel Bolt | 50 N.m | 37 lb ft |
| Turn Signal Switch Bracket Bolt | 9 N.m | 80 lb in |
| 1. Use NEW fastener. | ||
Fastener Tightening Specifications
Scheme 1
Scheme 2
