Reference Information
Schematic Reference
Steering Wheel Secondary/Configurable Control Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Steering Wheel Controls Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-610066-S15766520632014042100000)
- «Connector Repairs»(ref-610066-S09830970062014042100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
- «Wiring Repairs»(ref-610066-S23061455012014042100000)
Scan Tool Reference
Control Module References for scan tool information
Circuit/System Verification
Ignition ON, observe the scan tool SWC Bank 2 status while pressing and releasing the switches. The reading should be SW1-SW8 identifying the switch pressed and Idle when released.
Repair Instructions
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Steering Wheel Control Switch Assembly Replacement (Traverse)»(ref-610112-S15297426372014042100000) and «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(ref-610112-S29093321872014042100000)
- «Control Module References»(ref-610060-S10098619762014042100000) for BCM replacement, setup and programming
Schematic Reference
Steering Wheel Secondary/Configurable Control Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Steering Wheel Controls Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-610066-S15766520632014042100000)
- «Connector Repairs»(ref-610066-S09830970062014042100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
- «Wiring Repairs»(ref-610066-S23061455012014042100000)
Scan Tool Reference
Control Module References for scan tool information
Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.
Perform the Diagnostic Repair Verification after completing the repair.
Control Module References for BCM replacement, programming and setup
Schematic Reference
Steering Wheel Secondary/Configurable Control Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Steering Wheel Controls Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-610066-S15766520632014042100000)
- «Connector Repairs»(ref-610066-S09830970062014042100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
- «Wiring Repairs»(ref-610066-S23061455012014042100000)
Scan Tool Reference
Control Module References for scan tool information
Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Steering Wheel Control Switch Assembly Replacement (Traverse)»(ref-610112-S15297426372014042100000) and «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(ref-610112-S29093321872014042100000)
- «Control Module References»(ref-610060-S10098619762014042100000) for BCM replacement, setup and programming
Symptoms - Secondary and Configurable Customer Controls
Note. The following steps must be completed before using the symptom tables.
- Perform the «Diagnostic System Check - Vehicle»(ref-610038-S36414632882014042100000) before using the symptom tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
- Review the system description and operation in order to familiarize yourself with the system functions. Refer to «Steering Wheel Controls Description and Operation»(ref-610112-S28588254442014042100000) .
Intermittent
Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .
Schematic Reference
Steering Wheel Secondary/Configurable Control Schematics
Connector End View Reference
COMPONENT CONNECTOR END VIEWS - INDEX
Description and Operation
Steering Wheel Controls Description and Operation
Electrical Information Reference
- «Circuit Testing»(ref-610066-S15766520632014042100000)
- «Connector Repairs»(ref-610066-S09830970062014042100000)
- «Testing for Intermittent Conditions and Poor Connections»(ref-610066-S03531120952014042100000)
- «Wiring Repairs»(ref-610066-S23061455012014042100000)
Scan Tool Reference
Control Module References for scan tool information
Ignition ON, observe the scan tool BCM SWC Bank 1 Status parameter. The reading should be idle and change between SW1-SW7 when pushing the appropriate switch.
Perform the Diagnostic Repair Verification after completing the diagnostic procedure.
- «Steering Wheel Control Switch Assembly Replacement (Traverse)»(ref-610112-S15297426372014042100000) and «Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)»(ref-610112-S29093321872014042100000)
- «Control Module References»(ref-610060-S10098619762014042100000) for BCM replacement, setup and programming
Scheme 2
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the inflatable restraint steering wheel module. Refer to Airbag Steering Wheel Module Replacement . Remove the steering wheel. Refer to Steering Wheel Replacement | |
| 1 | Steering Wheel Rear Cover Screw (Qty: 3) CAUTION: Refer to Fastener Caution . |
| 2 | Steering Wheel Rear Cover |
| 3 | Steering Wheel Spoke Cover Screw (Qty: 4) CAUTION: Refer to Fastener Caution . |
| 4 | Steering Wheel Spoke Cover (Qty: 2) TIP: Use a flat-bladed plastic tool to disengage the 2 detent tabs and carefully pull cover from the 2 retainers. |
| 5 | Steering Wheel Control Switch Screw (Qty: 4) CAUTION: Refer to Fastener Caution . |
| 6 | Steering Wheel Control Switch Assembly (Qty: 2) Procedure Radio control switch assembly is shown. Cruise control switch assembly is similar. Disconnect the electrical connector. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Steering Wheel Control Switch Assembly Replacement (Traverse)
Scheme 3
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the inflatable restraint steering wheel module. Refer to Airbag Steering Wheel Module Replacement . | |
| 1 | Steering Wheel Spoke Cover (Qty: 2) TIP: Use a flat-bladed plastic tool to disengage the 2 detent tabs and carefully pull cover from the 2 retainers. |
| 2 | Steering Wheel Control Switch Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in) |
| 3 | Steering Wheel Control Switch Assembly (Qty: 2) Procedure Radio control switch assembly is shown. Cruise control switch assembly is similar. Disconnect the electrical connector. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Steering Wheel Control Switch Assembly Replacement (Acadia/Enclave)
Scheme 4
| Callout | Component Name |
|---|---|
| DA | Serial Data |
| HW | Hard-Wired |
| S70R | S70R Steering Wheel Controls Switch - Right |
| K9 | K9 Body Control Module |
| A11 | A11 Radio |
The steering wheel control switches duplicate the function of the primary controls of the associated component, through a network of momentary contact switches and a series of resistors. The body control module (BCM) supplies voltage to the switches and monitors the return signal. When a switch is pressed, a specific voltage drops across the resistor unique to that switch. The BCM identifies the switch selected and sends a serial data message to the component controlled by the switch, activating the feature.
This section is intended to diagnose the circuits between the BCM and the steering wheel control switches. If the primary control for the device is inoperative, refer to the appropriate section for the component the steering wheel control switch is used for.
