Fastener Tightening Specifications
| Application | Specifications | |
|---|---|---|
| Metric | English | |
| Sunroof Actuator/Motor Screws | 3 N.m | 27 lb in |
| Sunroof Module Bolts | 10 N.m | 89 lb in |
| Sunroof Sunshade Actuator/Motor Screws | 3 N.m | 27 lb in |
| Sunroof Water Trough to Sunroof Module Screws | 1 N.m | 9 lb in |
| Sunroof Window to Module Screws | 4 N.m | 35 lb in |
Scheme 1
Symptoms - Roof
Note. Complete the following procedures before using the symptom tables.
- Perform the «Diagnostic System Check - Vehicle»(ref-365273-S03182733772010070600000) in order to verify that all of the following conditions are true: No DTCs are set. The control modules can communicate via the serial data link.
- Review the system description and operation in order to learn the system functions. Refer to «Sunroof Description and Operation»(ref-365300-S03184968842010070600000) .
