Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Brake Hose Bracket Bolt - Front | 9 N.m | 80 lb in |
| Brake Hose Bracket Bolt - Rear | 9 N.m | 80 lb in |
| Brake Hose Fitting Bolt - Front | 40 N.m | 30 lb ft |
| Brake Hose Fitting Bolt - Rear | 50 N.m | 37 lb ft |
| Brake Pedal Bracket Bolts | 22 N.m | 16 lb ft |
| Brake Pipe Fittings - Master Cylinder Outlet | 20 N.m | 15 lb ft |
| Brake Pipe Fittings - Front and Rear at Brake Hose | 17 N.m | 13 lb ft |
| Brake Pipe Fittings - Rear Crossover Brake Pipe Union | 20 N.m | 15 lb ft |
| Brake Pressure Modulator Valve (BPMV) Assembly Bracket Nuts | 20 N.m | 15 lb ft |
| Master Cylinder Nuts | 20 N.m | 15 lb ft |
| Power Brake Booster Auxiliary Pump Bracket Bolts | 10 N.m | 89 lb in |
| Power Brake Booster Auxiliary Pump Nuts | 10 N.m | 89 lb in |
| Vacuum Booster Nuts | 25 N.m | 18 lb ft |
Brake System Specifications
| Application | Specification |
|---|
| Metric | English |
| Brake Pedal Travel Maximum specification with 445 N (100 lbs) of force applied to the brake pedal with the ignition OFF and the booster power reserve depleted. | 45 mm | 1.77 in |
Scheme 1
Scheme 1: Hydraulic Brake Schematics
