Interior Trim System and Paneling: Specifications GMC Acadia I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Center Pillar Assit Handle Screw	1.2 N.m	10 lb in
Coat Hook Screw	9 N.m	80 lb in
Front Side Door Trim Panel Bolts	2 N.m	18 lb in
Liftgate Trim Finish Panel Screws	2 N.m	18 lb in
Rear Quarter Upper Trim Panel Screws	3 N.m	27 lb in
Rear Quarter Lower Trim Panel Screws	3 N.m	27 lb in
Rear Side Door Trim Panel Screws	2 N.m	18 lb in
Sunshade Anchor Screws	3 N.m	25 lb in
Sunshade Screws	3 N.m	25 lb in
Windshield Pillar Garnish Molding Bolts	2 N.m	18 lb in

Scheme 59: Front Side Door Window Frame Front Cover Replacement (Traverse)

Callout	Component Name
Preliminary Procedure: Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Traverse) and Front Side Door Trim Panel Replacement - Right Side (Traverse) .
1	Front Side Door Trim Fastener CAUTION: Refer to Fastener Caution . Tighten: 1 N.m (9 lb in)
2	Front Side Door Window Frame Front Cover Assembly

CAUTION
Refer to Fastener Caution .

Scheme 60: Upper Extension Trim Panel Replacement (Acadia)

Callout	Component Name
Preliminary Procedure: Remove the rear side door trim panel. Refer to Rear Side Door Trim Panel Replacement (Acadia/OUTLOOK) .
1	Rear Side Door Upper Molding Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2	Rear Side Door Trim Bracket
3	Rear Side Door Upper Molding Procedure: Pull away from door to disengage the retainer clips.

CAUTION
Refer to Fastener Caution .

Scheme 61: Upper Extension Trim Panel Replacement (OUTLOOK or Traverse)

Callout	Component Name
1	Rear Side Door Upper Trim Panel Assembly
2	Rear Side Door Upper Trim Panel Retainer (Qty: 2)

Scheme 62: Front Side Door Trim Panel Replacement - Left Side (Enclave)

Callout	Component Name
1	Front Side Door Pull Handle Cover
2	Front Side Door Inside Handle Bezel Finish Cover
3	Front Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (18 lb in)
4	Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5	Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector.
6	Front Side Door Trim Panel Retainer (Qty: 9)

CAUTION
Refer to Fastener Caution .

Scheme 63: Front Side Door Trim Panel Replacement - Left Side (Acadia)

Callout	Component Name
1	Front Side Door Pull Handle Cover
2	Front Side Door Inside Handle Bezel Finish Cover
3	Front Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (18 lb in)
4	Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5	Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector.
6	Front Side Door Trim Panel Retainer (Qty: 9)

CAUTION
Refer to Fastener Caution .
