Scheme 1
Circuit/System Description
The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control set/coast and resume/accelerate switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied. The BCM sends a serial data message to the engine control module (ECM), indicating the status of the cruise control switches.
The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control on/off, set/coast, resume/accelerate and cancel switches via the cruise control switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied. The BCM sends a serial data message to the ECM indicating the status of the cruise control switches.
The brake applied signal circuit is a high voltage input from the body control module (BCM) to the engine control module (ECM) and transmission control module (TCM). The ECM monitors the stop lamp switch circuit to detect when the brake pedal has been applied. The BCM monitors the brake pedal position sensor to determine when the brake pedal is applied. When the brake pedal is applied, the BCM supplies a high voltage signal on the brake applied signal circuit and also sends a serial data message to the ECM indicating that the brake pedal has been applied. The ECM senses a high voltage signal on the brake applied signal circuit when the brake pedal has been applied.
When a cruise control function switch is activated, the body control module (BCM) detects a predetermined voltage signal. The BCM sends a serial data message to the engine control module (ECM) indicating the function that has been requested.
The instrument panel cluster (IPC) illuminates the cruise control engaged indicator based on serial data messages received from the body control module (BCM). The indicator is commanded ON when the cruise control system is controlling vehicle speed, and turned OFF with the system disengaged.
The body control module (BCM) monitors the cruise control indicator switch. When the cruise on/off switch is pressed ON, the cruise control switch is closed and the signal circuit is low. When the cruise on/off switch is pressed OFF, the cruise control switch is open and the signal circuit is high.
The cruise control switch is an input to the body control module (BCM). The BCM monitors the cruise control switch signal circuit in order to detect when the driver has requested to perform a cruise control function. The BCM detects a specific voltage signal on the cruise control switch signal circuit when a switch is applied.
Cruise Control Description and Operation
Cruise control is a speed control system that maintains a desired vehicle speed under normal driving conditions at vehicle speeds above 40 km/h (25 mph). Steep grades may cause variations in the selected vehicle speeds.
The following are the main components of the cruise control system
- The accelerator pedal
- The brake pedal position (BPP) sensor
- The body control module (BCM)
- The engine control module (ECM)
- The on/off switch
- The cancel switch
- The + RES switch, equivalent to resume/accel switch
- The - SET switch, equivalent to set/coast switch
- The vehicle speed sensor
The body control module (BCM) monitors the signal circuit of the cruise control switches, which are located on the steering wheel. The BCM relays the cruise control switch status to the engine control module (ECM) via the GMLAN serial data circuit. The ECM uses the status of the cruise control switch to determine when to capture and maintain the vehicle speed. The ECM monitors the vehicle speed signal circuit in order to determine the desired vehicle speed.
Voltage is supplied to the cruise control switch via the steering wheel control switch reference voltage circuit supplied by the BCM. The cruise control function switches are arranged in a resistive ladder design, with each cruise control function switch having a different resistance value. The BCM detects a specific voltage value that is associated with the cruise control function switch being activated. When the normally open cruise control on/off switch is turned ON, the switch closes and the BCM supplies a ground to the cruise control switch ON indicator circuit as it becomes illuminated. The BCM sends a GMLAN serial data message to the ECM indicating that the on/off switch is active. Similarly, when the normally open + RES switch or the normally open - SET switch are pressed, the switch closes and the BCM detects the predetermined voltage signal on the cruise control resume/accel and set/coast switch signal circuit. The BCM sends a GMLAN serial data message to the ECM indicating that the + RES switch or the - SET switch is active. The + RES switch or the - SET switch will remain inactive when the BCM has not received the predetermined voltage signal from the on/off switch.
