Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake Pipe Fittings - Brake Pressure Modulator Valve Inlet | 25 N.m | 18 lb ft |
| Brake Pipe Fittings - Brake Pressure Modulator Valve Outlet | 17 N.m | 13 lb ft |
| Brake Pressure Modulator Valve Bracket Nuts | 20 N.m | 15 lb ft |
| Brake Pressure Modulator Valve Insulator Nuts | 8 N.m | 71 lb in |
| Electronic Brake Control Module (EBCM) Bolts | 3 N.m | 27 lb in |
| Vehicle Yaw Sensor and Lateral Accelerometer Nuts | 9 N.m | 80 lb in |
| Wheel Speed Sensor Bolt - Front | 9 N.m | 80 lb in |
| Wheel Speed Sensor Bolt - Rear | 9 N.m | 80 lb in |
Scheme 1
Scheme 2
Scheme 3
