Engine Mechanical - 3.6L - Component Locator: Overview GMC Acadia I

Mechanical 15 illustrations ~158 words

Scheme 63

Scheme 63: Disassembled Views

Callout	Component Name
1	Right Camshaft Cover Assembly
2	Ignition Coil Bolt
3	Ignition Coil
4	Spark Plug
5	Intake Manifold Assembly
6	Left Camshaft Cover Assembly
7	Fuel Rail Noise Shield
8	Fuel Pump Cover
9	Fuel Pump Cover Bolt
10	Engine Flywheel
11	Engine Flywheel Bolt
12	Left Exhaust Manifold Heat Shield Bolt
13	Left Exhaust Manifold Heat Shield
14	Left Exhaust Manifold
15	Cylinder Head Exhaust Manifold Bolt
16	Left Exhaust Manifold Gasket
17	Engine Assembly
18	Oil Pan Assembly
19	Engine Front Cover Assembly
20	Crankshaft Balancer
21	Crankshaft Balancer Bolt
22	Right Exhaust Manifold
23	Right Exhaust Manifold Gasket
24	Crankshaft Position Sensor Heat Shield Bolt - Large
25	Crankshaft Position Sensor Heat Shield
26	Crankshaft Position Sensor Heat Shield Bolt - Small

Scheme 64

Callout	Component Name
1	Water Outlet Bolt
2	Water Outlet
3	Water Outlet O-ring
4	Water Outlet Seal
5	Right Cylinder Head Assembly
6	Right Cylinder Head Gasket
7	Engine Cooling Thermostat Gasket
8	Engine Cooling Thermostat
9	Engine Cooling Thermostat Housing
10	Engine Cooling Thermostat Bolt - Short
11	Engine Cooling Thermostat Housing Bolt
12	Coolant Pipe Bracket Bolt
13	Fuel Feed Pipe Assembly
14	Fuel Feed Pipe Assembly Bolt
15	Fuel Feed Intermediate Pipe Assembly
16	Fuel Pump O-ring Seal
17	Fuel Pump Gasket
18	Fuel Pump Bolt
19	Fuel Pump
20	Left Cylinder Head Assembly
21	Left Cylinder Head Gasket
22	Oil Level Indicator
23	Oil Level Indicator Handle O-ring
24	Oil Level Indicator Tube Bolt
25	Oil Level Indicator Tube O-ring
26	Oil Level Indicator Tube
27	Knock Sensor
28	Knock Sensor Bolt
29	Oil Filter Adapter Assembly
30	Engine Short Block Assembly
31	Oil Pump Assembly
32	Timing Drive Assembly
33	Crankshaft Position Sensor Bolt
34	Crankshaft Position Sensor
35	Crankshaft Position Sensor O-ring

Scheme 65

Callout	Component Name
250	Left Camshaft Cover
251	Left Camshaft Cover Gasket
252	Right Camshaft Cover
253	Right Camshaft Cover Gasket
254	Camshaft Cover Spark Plug Port Seal
254	Camshaft Cover Spark Plug Port Seal
255	Camshaft Cover Bolt
255	Camshaft Cover Bolt
256	Camshaft Cover Bolt Insulator
256	Camshaft Cover Bolt Insulator
257	Ignition Coil Bolt Thread Insert
258	Oil Fill Cap
259	Oil Fill O-ring
259	Oil Fill O-ring
260	Left Camshaft Cover PCV Fitting
261	Right Camshaft Cover PCV Fitting Orifice
262	Oil Fill Tube
263	Left Camshaft Cover PCV Fitting O-ring
265	Left Camshaft Housing Cover Insulator
266	Right Camshaft Housing Cover Insulator
704	Ignition Coil
704	Ignition Coil
705	Ignition Coil Bolt
705	Ignition Coil Bolt
719	Spark Plug
719	Spark Plug

Scheme 66

Callout	Component Name
1	Primary Timing Chain Tensioner Bolt
2	Left Secondary Timing Chain Shoe Bolt
3	Right Secondary Timing Chain Tensioner
4	Right Secondary Timing Chain Tensioner Gasket
5	Right Secondary Timing Chain Shoe
6	Secondary Timing Chain
7	Camshaft Position Actuator Bolt
8	Exhaust Camshaft Position Actuator
9	Camshaft Position Actuator Thrust Washer
10	Intake Camshaft Position Actuator
11	Right Secondary Timing Chain Guide
12	Left Camshaft Intermediate Drive Shaft Sprocket
13	Camshaft Intermediate Drive Shaft Sprocket Bolt
14	Left Secondary Timing Chain Shoe
15	Left Secondary Timing Chain Tensioner Gasket
16	Left Secondary Timing Chain Tensioner
17	Left Secondary Timing Chain Guide
18	Lower Primary Timing Chain Guide
19	Lower Primary Timing Chain Guide Bolt
20	Crankshaft Sprocket
21	Primary Timing Chain
22	Right Camshaft Intermediate Drive Shaft Sprocket
23	Upper Primary Timing Chain Guide
24	Primary Timing Chain Tensioner Gasket
25	Primary Timing Chain Tensioner

Scheme 67

Callout	Component Name
1	Intake Manifold
2	Intake Manifold Bolt - Long
3	Sight Shield Ball Stud
4	PCV Tube
5	Intake Manifold Bolt - Short
6	Throttle Body Gasket
7	Throttle Body
8	Throttle Body Bolt
9	EVAP Solenoid Bolt
10	EVAP Solenoid
11	EVAP Solenoid Bolt
12	EVAP Solenoid O-ring Seal
13	Intake Manifold Gasket

Scheme 68

Callout	Component Name
1	Fuel Pressure Sensor
2	Fuel Rail Bolt
3	Fuel Injector Retainer
4	Fuel Injector O-ring Seal
5	Fuel Injector Spacer
6	Fuel Injector
7	Fuel Injector Teflon Seal
8	Fuel Injector Isolator Cup
9	Fuel Injector Isolator Cup Retaining Ring
10	Fuel Rail

Scheme 69

Callout	Component Name
1	Fuel Injector Wiring Harness
2	Fuel Rail
3	Fuel Pressure Sensor
4	Fuel Rail Bolt
5	Fuel Rail Crossover Pipe
6	Fuel Injector Retainer
7	Fuel Injector O-ring Seal
8	Fuel Injector Spacer
9	Fuel Injector
10	Fuel Injector Teflon Seal
11	Fuel Injector Isolator Cup
12	Fuel Injector Isolator Cup Retaining Ring
13	Cylinder Head Front Bolt
14	Cylinder Head Bolt
15	Valve Stem Oil Seal
16	Valve Spring
17	Valve Spring Cap
18	Valve Stem Key
19	Valve Rocker Arm Assembly
20	Cylinder Head Camshaft Front Thrust Bearing Cap
21	Cylinder Head Camshaft Cap - Intermediate
22	Cylinder Head Camshaft Cap Bolt
23	Left Intake Camshaft
24	Left Exhaust Camshaft
25	Cylinder Head Coolant Hole Threaded Plug
26	Spark Plug Sleeve
27	Hydraulic Valve Lash Adjuster Assembly
28	Engine Coolant Temperature Sensor
29	Left Cylinder Head
30	Intake Valve
31	Left Cylinder Head Gasket
32	Exhaust Valve
33	Cylinder Head Oil Gallery Expansion Plug - 14 mm
34	Right Cylinder Head Gasket
35	Cylinder Head Oil Gallery Check Valve
36	Right Cylinder Head
37	Right Exhaust Camshaft
38	Right Intake Camshaft
39	Camshaft Oil Seal Ring

Scheme 70

Callout	Component Name
1	Water Pump Pulley Bolt
2	Water Pump Pulley
3	Water Pump Assembly
4	Water Pump Pulley Gasket
5	Camshaft Position Actuator Solenoid Valve Seal
6	Camshaft Position Sensor Bolt
7	Camshaft Position Sensor
8	Camshaft Position Sensor O-ring Seal
9	Camshaft Position Actuator Solenoid Valve Bolt
10	Camshaft Position Actuator Solenoid Valve
11	Engine Front Cover Gasket
12	Engine Front Cover Locating Pin
13	Engine Front Cover
14	Engine Front Cover Bolt
15	Engine Front Cover Seal
16	Crankshaft Balancer
17	Crankshaft Balancer Bolt
18	Engine Front Cover Bolt
19	Water Pump Bolt

Scheme 71

Callout	Component Name
151	Lower Primary Timing Chain Guide
154	Lower Primary Timing Chain Guide Bolt
463	Oil Pump Housing
464	Oil Pump Cover
465	Oil Pump Driven Gear
466	Oil Pump Drive Gear
468	Oil Pump Cover Bolt
470	Oil Pressure Relief Valve Bore Plug
471	Oil Pressure Relief Valve Spring
472	Oil Pressure Relief Valve
474	Oil Pressure Relief Valve Bore Plug Retainer Clip
475	Oil Pump Bolt

Scheme 72

Callout	Component Name
1	Crankshaft
2	Crankshaft Key
3	Crankshaft Lower Bearing
4	Crankshaft Bearing Cap
5	Crankshaft Bearing Cap Outboard Bolt
6	Crankshaft Bearing Cap Inboard Bolt
7	Crankshaft Bearing Thrust Cap
8	Piston Oil Nozzle Bolt
9	Piston Oil Nozzle
10	Oil Pan Locating Pin
11	Crankshaft Bearing Cap Side Bolt - Long
12	Engine Block Oil Gallery Threaded Plug - 14 mm
13	Crankshaft Rear Oil Seal Housing Assembly
14	Crankshaft Rear Oil Seal Housing Assembly Bolt
15	Transaxle Locating Pin
16	Piston and Connecting Rod Assembly
17	Engine Block Coolant Drain Threaded Plug - 14 mm
18	Engine Block Core Coolant Expansion Plug - 34.3 mm
19	Cylinder Head Locating Pin
20	Engine Block
21	Engine Block Oil Gallery Expansion Plug - 14
22	Engine Front Cover Stud
23	Engine Block Oil Gallery Threaded Plug - 20 mm
24	Engine Block Oil Gallery Expansion Plug - 10 mm
25	Crankshaft Bearing Cap Side Bolt - Short
26	Crankshaft Upper Thrust Bearing #3
27	Crankshaft Upper Bearing

Scheme 73

Callout	Component Name
200	Connecting Rod
201	Connecting Rod Bolt
202	Connecting Rod Bushing
203	Connecting Rod Bearing
210	Piston
211	Piston Pin
212	Piston Pin Retainer
212	Piston Pin Retainer
213	Piston Upper Compression Ring
214	Piston Lower Compression Ring
215	Piston Oil Control Rail Ring
216	Piston Oil Control Ring Spacer

Scheme 74

Callout	Component Name
400	Oil Pan
405	Oil Pump Suction Pipe
406	Oil Pump Suction Pipe Gasket
407	Oil Pump Suction Pipe Bolt
407	Oil Pump Suction Pipe Bolt
410	Oil Pan Baffle Scraper
411	Oil Pan Baffle Scraper Bolt
412	Oil Pan Drain Plug
413	Oil Pan Drain Plug O-ring
420	Oil Pan Bolt
422	Oil Pan Bolt - Long

Scheme 75

Callout	Component Name
440	Oil Filter Adapter
441	Oil Filter Adapter Gasket
442	Oil Filter Adapter Bolt
443	Oil Filter Adapter Bolt - Long
445	Oil Filter Fitting
449	Oil Filter
728	Engine Oil Pressure Sensor
729	Engine Oil Pressure Sensor O-ring

Vehicle Identification Number

The Vehicle Identification Number (VIN) Derivative is located in two places on the engine and is a nine digit number stamped or laser etched onto the block at the vehicle assembly plant. If reading the identification number the following information can be obtained

The first digit identifies the vehicle division.
The second digit is the model year.
The third digit identifies the assembly plant.
The fourth through ninth digits are the last six digits of the Vehicle Identification Number (VIN).

Scheme 76

The engine block is marked with the VIN on a pad area on the left rear side (1).

Scheme 77

The engine block is marked with the VIN on a pad area on the center lower right side (1).
