Fog Lamp Switch Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the driver knee bolster. Refer to Driver Knee Bolster Replacement (Acadia) or Driver Knee Bolster Replacement (Enclave) or Driver Knee Bolster Replacement (OUTLOOK) or Driver Knee Bolster Replacement (Traverse) . |
| 1 | Headlamp Switch Assembly |
Scheme 24
Scheme 24: Hazard Warning Switch Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Acadia) . |
| 1 | Hazard Warning Switch Assembly Procedure: Disconnect the electrical connector. |
Scheme 25
Scheme 25: Hazard Warning Switch Replacement (Enclave/Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Enclave) or Instrument Panel Accessory Trim Plate Replacement (Traverse) . |
| 1 | Hazard Warning Switch Assembly Procedure Release tab on top and bottom of switch to remove. Disconnect Electrical Connector. |
Scheme 26
Scheme 26: Hazard Warning Switch Replacement (OUTLOOK)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (OUTLOOK) . |
| 1 | Hazard Warning Switch Assembly Procedure: Disconnect the electrical connector. |
Scheme 27
Scheme 27: Daytime Running Lamp (DRL) Ambient Light Sensor Replacement (With UV6)
| Callout | Component Name |
|---|
| 1 | Instrument Panel Upper Trim Panel Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/RPO UV6) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (OUTLOOK) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Traverse) . |
| 2 | Headlamp Auto Control Ambient Light Sensor Assembly Procedure Twist and pull down to remove. Disconnect electrical connector. |
Scheme 28
Scheme 28: Daytime Running Lamp (DRL) Ambient Light Sensor Replacement (Without UV6)
| Callout | Component Name |
|---|
| 1 | Instrument Panel Upper Trim Panel Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/RPO UV6) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (OUTLOOK) or Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Traverse) . |
| 2 | Headlamp Auto Control Ambient Light Sensor Assembly Procedure Twist and pull down to remove. Disconnect electrical connector. |
Scheme 29
Scheme 29: Reading Lamp Bulb Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the reading lamp assembly. Refer to Reading Lamp Replacement . |
| 1 | Dome Lamp Housing Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m(18 lb in) |
| 2 | Dome Lamp Housing |
| 3 | Dome Reading Reflector (Qty: 2) |
| 4 | Reading Lamp Bulb (Qty: 2) |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 30
Scheme 30: Reading Lamp Replacement
| Callout | Component Name |
|---|
| 1 | Reading Lamp Assembly Procedure Carefully use a plastic flat bladed tool, and release the clips retaining the reading lamp assembly to the headliner. Grasp the reading lamp assembly and pull downward to disengage the retainers securing the reading lamp assembly to the vehicle. Disconnect the electrical connectors. |
Scheme 31
Scheme 31: Instrument Panel Courtesy Lamp Bulb Replacement - Left Side
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the instrument panel insulator panel. Refer to Instrument Panel Insulator Panel Replacement - Left Side (Acadia) or Instrument Panel Insulator Panel Replacement - Left Side (Enclave) or Instrument Panel Insulator Panel Replacement - Left Side (OUTLOOK) or Instrument Panel Insulator Panel Replacement - Left Side (Traverse) . |
| 1 | Courtesy Lamp Assembly Procedure: Carefully twist to release the bulb assembly. |
Scheme 32
Scheme 32: Instrument Panel Courtesy Lamp Bulb Replacement - Right Side
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the instrument panel insulator panel. Refer to Instrument Panel Insulator Panel Replacement - Right Side (Acadia) or Instrument Panel Insulator Panel Replacement - Right Side (Enclave) or Instrument Panel Insulator Panel Replacement - Right Side (OUTLOOK) or Instrument Panel Insulator Panel Replacement - Right Side (Traverse) . |
| 1 | Courtesy Lamp Assembly Procedure: Carefully twist to release the bulb assembly. |
Scheme 33
Scheme 33: Sunshade Illuminated Mirror Lamp Bulb Replacement
| Callout | Component Name |
|---|
| 1 | Sunshade Illuminated Mirror Lamp Lens Procedure: Carefully use a flat bladed tool, and release the tabs retaining the lamp lens to the sunshade assembly. |
| 2 | Sunshade Illuminated Mirror Lamp Bulb |
Scheme 34
Scheme 34: Outside Rearview Mirror Turn Signal Lamp Replacement (Except Buick Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the outside rear view mirror glass. Refer to Outside Rearview Mirror Glass Replacement . |
| 1 | Outside Rearview Mirror Turn Signal Lamp Screw (Qty: 2) |
| 2 | Outside Rearview Mirror Turn Signal Lamp Assembly Procedure Disconnect the electrical connector. Slide the turn signal assembly downward from the outside rearview mirror mounting holes. Remove the outside rearview mirror turn signal lamp from the mirror assembly housing. |
Scheme 35
Scheme 35: Headlamp Replacement (Traverse with TVP)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Traverse) . |
| 1 | Fender Brace Bolt to Headlamp CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) |
| 2 | Headlamp Bolt Tighten: 6 N.m (53 lb in) |
| 3 | Headlamp Horizontal and Vertical Adjusting Cam Nut Bolt (Qty: 2) Procedure Set the cam adjusting nuts to the nominal setting of 6 turns off fully seated prior to installing the new headlamp assembly. Check the front bumper fascia to headlamp finish fit and adjust the cam nuts accordingly to achieve an even fit. |
| 4 | Headlamp Assembly WARNING: Refer to Halogen Bulb Warning . Procedure Gently pull forward the headlamp assembly. Disconnect the forward lamp harness electrical connector from the headlamp assembly electrical connector. Remove the headlamp from vehicle. Transfer the headlamp electrical harness with bulb sockets as needed. Aim the headlamps. Refer to Headlamp Aiming . |
| CAUTION |
|---|
| Refer to Fastener Caution . |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 36
Scheme 36: Headlamp Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Acadia) . |
| 1 | Headlamp Screws (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in) |
| 2 | Fender Brace Screw to Headlamp Tighten: 2 N.m (18 lb in) |
| 3 | Headlamp Horizontal and Vertical Adjustment Nuts (Qty: 2) Procedure Set the cam adjusting nuts to the nominal setting of 6 turns off fully seated prior to installing the new headlamp assembly. Check the front bumper fascia to headlamp finish fit and adjust the cam nuts accordingly to achieve an even fit. |
| 4 | Headlamp Vertical Adjusting Bolt Bushing |
| 5 | Headlamp Assembly Procedure Gently pull forward the headlamp assembly. Disconnect the forward lamp harness from the headlamp assembly electrical connector. Remove the headlamp from vehicle. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 37
Scheme 37: Headlamp Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Enclave) . |
| 1 | Headlamp Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in) |
| 2 | Fender Brace Bolt to Headlamp Tighten: 2 N.m (18 lb in) |
| 3 | Headlamp Horizontal and Vertical Adjustment Nuts (Qty: 2) Procedure Set the cam adjusting nuts to the nominal setting of 6 turns off fully seated prior to installing the new assembly. Check the front bumper fascia to headlamp finish fit and adjust the cam nuts accordingly to achieve an even fit. |
| 4 | Headlamp Vertical Adjusting Bolt Bushing |
| 5 | Headlamp Assembly Procedure Gently pull forward the headlamp assembly. Disconnect the forward lamp harness from the headlamp assembly electrical connector. Remove the headlamp from vehicle. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 38
Scheme 38: Headlamp Replacement (OUTLOOK)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (OUTLOOK) . |
| 1 | Headlamp Assembly Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tip: Tighten the fasteners in sequence as shown. Tighten: 6 N.m (53 lb in) |
| 2 | Headlamp Assembly Nut Tighten: 6 N.m (53 lb in) |
| 3 | Headlamp Assembly Procedure: Pull outward on the housing in order to disconnect the electrical connection at the lower rear edge of the lamp. |
| 4 | Electrical Harness Connector Procedure: Disconnect the electrical connector from the headlamp assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 39
Scheme 39: High Intensity Discharge Headlamp Starter/Arc Tube Replacement (Acadia TVD)
| Callout | Component Name |
|---|
| WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedure: Remove the wheelhouse liner in order to access the backside of the headlamp capsule. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) . |
| 1 | Headlamp Accessory Bulb Cover Tip: Rotate the cover a quarter turn counter-clockwise and remove. Disconnect the wire clip securing the starter arc tube to the headlamp capsule assembly. |
| 2 | Headlamp Starter/Arc Tube WARNING: Refer to Halogen Bulb Warning . Procedure Pull the starter arc tube from the capsule assembly. Disconnect the electrical connector. Remove the arc tube from the capsule assembly. |
| 3 | Starter Arc Tube Electrical Connector Tip: Connect the electrical connector prior to installing the starter arc tube back into the headlamp capsule. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 40
Scheme 40: High Intensity Discharge Headlamp Starter/Arc Tube Replacement (Enclave TVC TSH)
| Callout | Component Name |
|---|
| WARNING: The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Capsule Replacement (Enclave TVC TSH) . |
| 1 | Headlamp Bulb and Ballast Locking Ring Procedure: Shown in the locked position, using your 2 fingers, rotate the locking ring counter-clockwise to unlock the bulb and ballast. |
| 2 | Headlamp Bulb and Ballast Locking Ring Procedure Position and secure the electrical wire harness connector to the headlamp bulb and ballast. Position and secure the headlamp ballast and bulb assembly to the headlamp. Rotate the locking ring in a clockwise position in order to secure the ballast and bulb assembly to the headlamp capsule. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. In order to reduce the risk of severe shocks and burns, the battery negative cable must be disconnected any time service work is being performed on or around the high intensity discharge system. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. |
Scheme 41
Scheme 41: Headlamp Ballast Replacement (Acadia TVD)
| Callout | Component Name |
|---|
| WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedure: Remove the wheelhouse liner. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) . |
| 1 | Headlamp Ballast Assembly Screws (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 3 N.m (27 lb in) |
| 2 | Headlamp Ballast Assembly Procedure Disconnect the electrical connector. Slide the ballast rearward from the headlamp composite assembly. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 42
Scheme 42: Headlamp Ballast Replacement (Enclave TVC TSH)
| Callout | Component Name |
|---|
| WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. Preliminary Procedure: Remove the wheelhouse liner. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) . |
| 1 | Headlamp Ballast Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 3 N.m (27 lb in) |
| 2 | Headlamp Ballast Assembly Procedure Disconnect the electrical connector. Slide the ballast rearward from the headlamp composite assembly. |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 43
Scheme 43: Headlamp Ballast Replacement (OUTLOOK)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp capsule. Refer to Headlamp Capsule Replacement (OUTLOOK) . |
| 1 | Headlamp Capsule Ballast Screw (Qty: 3) WARNING: The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. CAUTION: Refer to Fastener Caution . Tighten: 3 N.m (27 lb in) |
| 2 | Headlamp Ballast |
| WARNING |
|---|
| The high intensity discharge system produces high voltage and current. To reduce the risk of severe shocks and burns: Never open the high intensity discharge system ballast or the arc tube assembly starter. Never probe between the high intensity discharge system ballast output connector and the arc tube assembly. |
| CAUTION |
|---|
| Refer to Fastener Caution . |
Scheme 44
Scheme 44: Headlamp Bulb Replacement (OUTLOOK TVD and T96)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Replacement (OUTLOOK) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate the cover counter-clockwise and remove. |
| 2 | Headlamp Bulb Procedure: Release the wire clip from the bulb and disconnect the electrical connector in order to remove the bulb from the lamp assembly. |
Scheme 45
Scheme 45: Headlamp Bulb Replacement (OUTLOOK Non HID)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Replacement (OUTLOOK) . |
| 1 | Headlamp Bulb Accessory Covers (Qty: 2) |
| 2 | Headlamp Bulb Assembly (High Beam) WARNING: Refer to Halogen Bulb Warning . Tip: Disconnect the electrical connectors and remove the bulbs. |
| 3 | Headlamp Bulb Assembly (Low Beam) |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 46
Scheme 46: Headlamp Bulb Replacement (Traverse without TVP High Beam)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Replacement (Traverse with TVP) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate counterclockwise and remove. |
| 2 | High Beam Bulb WARNING: Refer to Halogen Bulb Warning . Tip: Disconnect the electrical connector in order to remove the bulb. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 47
Scheme 47: Headlamp Bulb Replacement (Traverse with TVP Lo Beam)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Replacement (Traverse with TVP) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate counterclockwise and remove. |
| 2 | Low Beam / DRL Bulb WARNING: Refer to Halogen Bulb Warning . Tip: Disconnect the electrical connector in order to remove the low beam / DRL bulb. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 48
Scheme 48: Headlamp Bulb Replacement (Traverse without TVP Lo Beam)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the headlamp assembly. Refer to Headlamp Replacement (Traverse with TVP) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate counterclockwise and remove. |
| 2 | Low Beam Bulb WARNING: Refer to Halogen Bulb Warning . Tip: Disconnect the electrical connector in order to remove the low beam bulb socket. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 49
Scheme 49: Headlamp Bulb Replacement (High Beam without T96)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front wheelhouse liner. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) or Front Wheelhouse Front Liner Replacement (OUTLOOK - Traverse) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate the cover counterclockwise and remove. |
| 2 | Headlamp Bulb (High Beam) WARNING: Refer to Halogen Bulb Warning . Procedure Disconnect the electrical connector from the bulb socket. Disconnect the bulb socket from the headlamp assembly. Discard the bulb. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
Scheme 50
Scheme 50: Headlamp Bulb Replacement (Low Beam without T96)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the front wheelhouse liner. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) or Front Wheelhouse Front Liner Replacement (OUTLOOK - Traverse) . |
| 1 | Headlamp Bulb Accessory Cover Tip: Rotate the cover counterclockwise and remove. |
| 2 | Headlamp Bulb (Low Beam) WARNING: Refer to Halogen Bulb Warning . Procedure Disconnect the electrical connector from the bulb socket. Release the bulb from the headlamp assembly. Discard the bulb. |
| WARNING |
|---|
| Refer to Halogen Bulb Warning . |
