Lighting System: Specifications GMC Acadia I

Exterior Lights 21 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Back Up Lamp Applique Nuts - Acadia5 N.m44 lb in
Back Up Lamp Applique Nuts - Enclave6 N.m53 lb in
Back Up Lamp Bracket Screw - Acadia2 N.m18 lb in
Back Up Lamp Bracket Screw - Traverse6 N.m53 lb in
Back Up Lamp Screws2 N.m18 lb in
Dome Lamp Housing Screws2 N.m18 lb in
DRL Lamp Assembly Screws2 N.m18 lb in
Front Bumper Fender Brace to Headlamp Assembly Screws2 N.m18 lb in
Front Fog Lamp Bracket Screw2.5 N.m22 lb in
Front Turn Signal Lamp Assembly Nuts9 N.m80 lb in
Headlamp Assembly Screws6 N.m53 lb in
Headlamp Capsule Ballast Screws3 N.m27 lb in
Headlamp Vertical Adjusting Nut6 N.m53 lb in
High Mounted Stop Lamp to Rear Spoiler Screws2 N.m18 lb in
License Lamp Screws2 N.m18 lb in
Parking and Front Fog Lamp Bracket Screws2.5 N.m22 lb in
Park and Turn Signal Lamp Screw2.5 N.m22 lb in
Sunroof DVD Lamp Housing Screws2 N.m18 lb in
Tail Lamp Assembly Screws3 N.m27 lb in
Tail Lamp Screw2.5 N.m22 lb in

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6: Fog Lights Schematics
Scheme 6: Fog Lights Schematics

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8: Exterior Lights Schematics
Scheme 8: Exterior Lights Schematics

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15: Interior Lights Schematics
Scheme 15: Interior Lights Schematics

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18: Interior Lights Dimming Schematics
Scheme 18: Interior Lights Dimming Schematics

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
