Power Steering System: Specifications GMC Acadia I

Electronic Steering 2 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Frame Mounting Bolt
First Pass100 N.m74 lb ft
Second Pass90°
Front Frame Reinforcement Mounting Bolt50 N.m37 lb ft
Power Steering Fluid Cooler Nut30 N.m22 lb in
Power Steering Gear Inlet and Outlet Pipe Clip Bolt9 N.m80 lb in
Power Steering Gear Inlet Hose Bracket Nut8 N.m71 lb in
Power Steering Gear Inlet Hose Fitting34 N.m25 lb ft
Power Steering Gear Inlet Hose Retaining Plate Bolt12 N.m106 lb in
Power Steering Gear Outlet Hose Bracket Bolt8 N.m71 lb in
Power Steering Gear Outlet Hose Bracket Nut8 N.m71 lb in
Power Steering Pump Bolt50 N.m37 lb ft
Rear Front Frame Mounting Bolt100 N.m74 lb ft
Remote Power Steering Fluid Reservoir Bolt9 N.m80 lb in
Remote Power Steering Fluid Reservoir Bracket Bolt9 N.m80 lb in
Steering Gear Bolt at the right side100 N.m74 lb ft
Steering Gear Nut at the left side180 N.m133 lb ft
Steering Gear Heat Shield Bolt7 N.m62 lb in
Steering Gear Valve Solenoid Bolt8 N.m71 lb in
Steering Linkage Inner Tie Rod Housing100 N.m74 lb ft
Steering Linkage Inner Tie Rod Nut75 N.m55 lb ft
Steering Linkage Outer Tie Rod Nut
First Pass30 N.m22 lb ft
Second Pass120°

Power Steering Pump Specifications

Engine CodeEngine SizeHigh FlowPressure Relief
LPMGPMKPaPSI
LLTV6 - 3.6L12.723.369308/103421350/1500

Scheme 1

Scheme 1: Power Steering Schematics
Scheme 1: Power Steering Schematics

Scheme 2

Scheme 2: Power Steering Gear Disassembled View
Scheme 2: Power Steering Gear Disassembled View
CalloutComponent Name
1Steering Linkage Outer Tie Rod
2Steering Linkage Inner Tie Rod Nut
3Steering Linkage Inner Tie Rod
4Steering Gear Boot Clamp
5Steering Gear Boot
6Steering Gear Boot Clamp
7Steering Gear Pipe
8Steering Gear Pipe
9Steering Gear Valve Solenoid
10Steering Gear Valve Solenoid Bolt
11Steering Linkage Outer Tie Rod
12Steering Linkage Inner Tie Rod Nut
13Steering Linkage Inner Tie Rod
14Steering Gear Boot Clamp
15Steering Gear Boot
16Steering Gear Boot Clamp
17Steering Gear Assembly
