Fuse & Circuit Breaker Identification
- 1 - 10 Amp (Red) - Right Headlight
- 2 - 10 Amp (Red) - Left Headlight/Hi Beam
- 3 - 15 Amp (Blue) - Taillights, Interior Light, Side Marker/Instrument Cluster Lights
- 4 - 15 Amp (Blue)p Stoplights, Horn
- 5 - 15 Amp (Blue)p Hazard Lights
- 6 - 20 Amp - Cigarette Lighter
- 7 - Not Used
- 8 - 15 Amp (Blue) - Ignition System, Indicator Lights, EFI Controller, Fuel/Temp Gauges
- 9 - 10 Amp (Red) - Turn Signal/Back-Up Lights
- 10 - 15 Amp (Blue) - Wiper/Washer
- 11 - 15 Amp (Blue) - Rear Defogger
- 12 - 25 Amp - Heater
- 13 - Not Used
- 14 - Not Used
Scheme 1
Scheme 1: UNDERHOOD FUSIBLE LINK BOX ID (1989-90)
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
Fusible Link Identification
- A - 60 Amp - Alternator
- B - 40 Amp - Main Switch
- C - 30 Amp - Fuse Box
Scheme 2
Scheme 2: INSTRUMENT PANEL FUSE IDENTIFICATION (1991-96)
- 1 - 15 Amp HEAD R (Blue) - Right Headlight
- 2 - 15 Amp HEAD L (Blue) - Left Headlight/Hi Beam
- 3 - 15 Amp TAIL/DOME (Blue) - Taillights, Interior Light, Side Marker/Instrument Cluster Lights, Radio Clock, Radio Illumination, Radio Memory, Spot Lamp, Engine Control Module (ECM), License Plate Light, Ignition Key Warning Switch, Electronic Brake Control Module, (EBCM) (W/ABS), Rear Wheel Antilock (RWAL) Brake Data Link Connector (DLC) (W/ABS)
- 4 - 15 Amp STOP/HORN (Blue) - Stoplights, Horn Relay
- 5 - 15 Amp HAZARD (Blue) - Hazard Lights
- 6 - 20 Amp DOOR LOCK (Yelllow) - Door Lock
- 7 - 20 Amp CIGAR/RADIO (Yellow) - Cigarette Lighter, Radio Power Input
- 8 - 15 Amp IG-COIL (Blue) - Ignition System, Indicator Lights, EFI Controller, Generator, Fuel/Temp Gauges, Audio Alarm Module, MAIN Relay, Daytime Running Lights (DRL) Controller, Fuel Pump Relay, Heated Oxygen Sensor (HO2S), Stoplamp Switch (Auto Trans), Noise Suppressor Condenser (1.6L VIN U) (1991-96), Noise Suppressor Filter (1.6L VIN 6) (1994-96)
- 9 - 15 Amp TURN/BACK (Blue) - Turn Signal, Back-Up Lights
- 10 - 15 Amp WIP (Blue) - Front Wiper/Washer, Rear Wiper/Washer (Hardtop), Shift Lock Relay (Automatic Transmission)
- 11 - 15 Amp DFOG (Blue) - Rear Defogger, Rear Wheel Antilock Brake Relay (RWAL)
- 12 - 25 Amp HTR A/C Amplifier, Blower Speed Selector Switch, Dual Pressure Switch
- 13 - 20 Amp RWAL (Yellow) - Rear Wheel Anti-Lock Main Relay (RWAL)
- 14 - 15 Amp FI (Blue) - Electronic Fuel Injection Main Relay
Scheme 3
Scheme 3: UNDERHOOD FUSIBLE LINK BOX ID (1991-93)
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- A - 60 Amp (Blue) - Battery (Main Circuit)
- B - 50 Amp (Red) - Ignition Switch, Fuse Block
- C - 40 Amp (Amber) - Lamps Fuse - Tail, Stop, Headlight, Hazard, Door Lock
- D - 30 Amp (Green) - ABS System Relay (If Equipped)
- 1 - Generator to Battery Circuit
- 2 - Circuits Only Active When Ignition Switch Is In ACC, ON, or START
- 3 - Circuits Always Active
- 4 - Circuits Always Active
Scheme 4
Scheme 4: MAIN FUSE BLOCK INDENTIFICATION (1996)
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- BATT - All Electrical Load
- ABS - Anti-Lock Brake System
- IG - Ignition, Lighter, Radio, Wiper/Washer, Rear Defogger, Turn Signals, Backup Lamps, Heater
- Lamp - Taillamps, Dome Lamps, Stop Lamps, Horn, Hazard Lamps
- H/L, R - Right Side Headlamp
- H/L, L - Left Side Headlamp
- FI - Fuel Injection System
- A/C - Air Conditioning
