Steering System - Manual: Specifications Geo Tracker I

Manual & Power Steering 1 illustration ~115 words

WORM SHAFT OPERATING TORQUE

Note. Perform worm shaft operating torque adjustment with steering gear removed from vehicle.

  1. Check worm shaft to ensure it is free of thrust play. Position pitman arm 11 degrees inward from parallel with worm shaft. (Scheme 1) This position is the sector gear high point.
  2. Connect Socket (J-34871-A) and INCH-pound torque wrench to worm shaft. Check operating torque in this position. Operating torque should be 9 INCH lbs. (1.0 N.m).
  3. If operating torque is not within specification, loosen or tighten adjusting nut as necessary. Recheck operating torque. If operating torque cannot be adjusted to within specification, replace steering gear assembly.

Scheme 1

Scheme 1

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Center Link Castle Nut41 (55)
Idler Arm Bushing Nut55 (75)
Pitman Arm-To-Sector Shaft Nut95 (129)
Skid Plate Bolt20 (27)
Steering Gear Attaching Bolt74 (100)
Tie Rod Castle Nut33 (45)
Tie Rod End Lock Nut48 (65)

TORQUE SPECIFICATIONS
