OVERHAUL
Note. Use illustration for exploded view of starters. (Scheme 5)
Scheme 5
| Application | Specification | |
|---|---|---|
| Brush Length | .39-.61" (10-15 mm) | |
| Commutator Insulation Depth | ||
| Minimum Depth | .008" (.2 mm) | |
| Standard Depth | .024" (.6 mm) | |
| Commutator Outside Diameter | 1.14-1.18" (28.9-30.0 mm) | |
| Commutator Runout | .002-.016" (.05-.41 mm) | |
| Starter Current Draw No-Load | 60-90 Amps At 11.0 Volts | |
STARTER SPECIFICATIONS
