DESCRIPTION & OPERATION
Power mirrors are controlled by power mirror switch assembly located on left side of instrument panel. (Scheme 1) The selector switch directs current to desired mirror. The horizontal/vertical switch directs current to one of 2 motors located in mirror assembly. Mirror and motors are removed and serviced as an assembly.
Ignition switch must be in ON or ACCY position for power mirror operation. Power is supplied to control switch assembly from CIG-RADIO fuse, through audio alarm module and junction block No. 3. Power mirror switch is permanently grounded through junction block No. 3, junction connector No. 3 and junction connector No. 1 to ground connection G200 (located behind left kick panel).
