Genesis GV70 I (2020-2024) Front climate control seats circuit, driver w/ memory & passenger w/ walk-in

A/C CONTROL MODULE B-CAN HIGH B-CAN LOW BLK WIRE BLOWER BLOWER (+) GND BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE CLIMATE CAN HIGH CLIMATE CAN LOW COMPUTER DATA LINES SYSTEM CUSHION HEATER CUSHION MAT CUSHION MAT NTC (+) CUSHION) DRIVER CCS BLOWER MOTOR (CUSHION) DRIVER CCS BLOWER MOTOR (RECLINING) DRIVER POWER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SEAT HEATER FRONT A/C CONTROLLER GRN/BLK WIRE GRN/ORG WIRE GRY/BLK WIRE HEATER HOT AT ALL TIMES ICU JUNCTION BLOCK ICU-A MAT NTC (-) NCA WIRE NTC- ORG/ WIRE PNK WIRE PNK/BLK WIRE RECLINING RECLINING HEATER RECLINING HEATER (+) MEMORY POWER RECLINING MAT NTC (+) SPEED CONTROL RECLINING MAT NTC (-) RED WIRE S/HEATER DRV FUSE S/HEATER PASS 1 FUSE SPEED CONTROL VENT WHT WIRE YEL WIRE YEL/BLK WIRE

B-CAN HIGH B-CAN LOW BLK WIRE BLOWER BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM CUSHION HEATER CUSHION MAT CUSHION MAT NTC (+) CUSHION) GRN/BLK WIRE GRN/ORG WIRE GRY/BLK WIRE HEATER MAT NTC (-) NCA WIRE NTC- ORG/ WIRE PASSENGER CCS BLOWER MOTOR (CUSHION) PASSENGER CCS BLOWER MOTOR (RECLINING) PASSENGER POWER SEAT MODULE (UNDER FRONT PASSENGER'S SEAT) PASSENGER SEAT HEATER PNK/BLK WIRE RECLINING RECLINING HEATER RECLINING HEATER (+) MEMORY POWER RECLINING MAT NTC (+) SPEED CONTROL RECLINING MAT NTC (-) RED WIRE SPEED CONTROL WHT WIRE YEL/BLK WIRE
